Kawasaki Z 800 Specs

2013 - 2017 • 4 variants

Kawasaki has built the Z 800, a naked bike, across 4 variants since 2013, most recently updated for 2017. Under the tank sits a four stroke, transverse four cylinder, DOHC, 4 valve per cylinder, 806.00 cc in capacity. It makes 113 hp at peak. Torque tops out at 83 Nm.

About the Kawasaki Z 800

Documented here are the full technical specifications for the Kawasaki Z 800, a Naked bike motorcycle with a production run from 2013 to 2017. Specification data includes engine type and displacement, maximum power and torque output, transmission details, frame construction, suspension travel front and rear, brake types and rotor dimensions, tyre sizes, and overall weight and dimension figures. Select a year above to view the complete spec sheet for that model year.

Kawasaki Z 800 by Year

2017 Kawasaki Z 800 View specs →

2016 Kawasaki Z 800 View specs →

2014 Kawasaki Z 800 View specs →

2013 Kawasaki Z 800 View specs →

Spec Evolution

How key specs changed across production years.

Specification	2013	2014	2016	2017
Fuel Control	OHV	DOHC	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)
Engine Type	V2, four-stroke	V2, four-stroke	V2, four-stroke	In-line four, four-stroke
Seat Height	834 mm / 32.8 in	834 mm / 32.8 in	834 mm / 32.8 in	834 mm / 32.8 in.
Brakes - Front	2x semi-floating 310 mm discs 4 piston calipers	2x semi-floating 310 mm discs 4 piston calipers	2x semi-floating 310 mm discs 4 piston calipers	Double disc. Floating discs.
Wheelbase	1445 mm / 56.8 in	1445 mm / 56.8 in	1445 mm / 56.8 in	1,445 mm / 56.9 in. ↓
Brakes - Rear	Single 220mm disc 1 piston caliper	Single 220mm disc 1 piston caliper	Single 220mm disc 1 piston caliper	Single disc. Single-piston caliper.
Fuel Capacity	17 Litres / 4.5 US gal	17 Litres / 4.5 US gal	17 Litres / 4.5 US gal	17.00 litres / 4.49 gallons
Suspension - Front	41 mm inverted fork with rebound damping and spring preload adjustability,	41 mm inverted fork with rebound damping and spring preload adjustability,	41 mm inverted fork with rebound damping and spring preload adjustability,	41 mm inverted fork with rebound damping and spring preload adjustability
Suspension - Rear	Bottom-Link Uni-Trak, gas-charged shock with piggyback reservoir and stepless rebound damping and preload adjustability,	Bottom-Link Uni-Trak, gas-charged shock with piggyback reservoir and stepless rebound damping and preload adjustability,	Bottom-Link Uni-Trak, gas-charged shock with piggyback reservoir and stepless rebound damping and preload adjustability,	Bottom-Link Uni-Trak, gas-charged shock with piggyback reservoir and stepless rebound damping and preload adjustability
Fuel System	Injection	Injection	Injection. 34 mm x 4 (Mikuni), with dual throttle valves	Injection. 34 mm x 4 Mikuni with dual throttle valves
Colours	Scout Green, Aztec Red	Scout Green, Aztec Red	Green/Black, Black/grey, White/gray	Metallic Spark Black/Flat Ebony, Metallic Spark Black/Pearl Stardust White
Height	1050 mm / 41.3 ib	1050 mm / 41.3 ib	1050 mm / 41.3 ib	1,050 mm / 41.3 in. ↓
Length	2100 mm / 82.6	2100 mm / 82.6	2100 mm / 82.6	2,100 mm / 82.7 in. ↓
Wet Weight	229 kg / 504.8 lbs ABS 231 kg / 509.2 lbs	229 kg / 504.8 lbs ABS 231 kg / 509.2 lbs	229 kg / 504.8 lbs ABS 231 kg / 509.2 lbs	227.0 kg / 500.4 lbs ↓
Tyres - Front	120/70 ZR17	120/70 ZR17	120/70 ZR17	120/70-ZR17
Gearbox	2-speed	2-speed	6-speed ↑	6-speed
Width	800 mm / 31.4 in	800 mm / 31.4 in	800 mm / 31.4 in	800 mm / 31.5 in.
Tyres - Rear	180/55ZR17	180/55ZR17	180/55ZR17	180/55-ZR17
Lighting system	30W x 2 halogen	30W halogen headlights / 5W taillight / 18W stoplight	-	-
Max Torque	83.0 Nm / 8.5 kg-fm @ 8000 rpm	83.0 Nm / 8.5 kg-fm @ 8000 rpm	83.0 Nm / 8.5 kg-fm @ 8000 rpm	83.00 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 8500 Revolutions
