Key Specifications
Engine
Four stroke, transverse six cylinder, DOHC, 2 valve per cylinder.
Power
87.5 kW / 120 hp @ 8000 rpm
Torque
116 Nm / 11.8 kgf-m / 85.6 ft. lbs @ 6500 rpm
Top Speed
223.6 km/h / 139 mph
Fuel Capacity
27 Litres / US 7.1 gal
Advertisement
Full 1982 Kawasaki Z 1300 Specifications
Year
1981 - 82
Make Model
Kawasaki Z 1300
Wheelbase
1580 mm / 62.2 in
Ground Clearance
145 mm / 5.7 in
Dry Weight
297 kg / 654.8 lbs
Fuel Capacity
27 Litres / US 7.1 gal
Oil Capacity
4.5 L / 1.2 US gal
Wet Weight
322 kg / 709 lbs
Displacement
1286 cc / 78.5 cu in
Engine Detail
Four stroke, transverse six cylinder, DOHC, 2 valve per cylinder.
Bore x Stroke
62 x 71 mm
Compression Ratio
9.9:1
Cooling System
Liquid cooled
Engine Oil Specification
Mineral, 10W/40
Fuel Consumption
6.5 L/100 km / 15.3 km/l / 36 US mpg
Fuel Induction
3x 32mm twin choke Mikuni BSW carburetors
Ignition
Analogue CDI (Capacitive Discharge Ign.)
Lubrication
Wet sump
Spark Plug
NGK, CR9E
Starter
Electric
Clutch
Wet multi disc
Final Drive
Shaft
Gear Ratios
1st 2.29 (39/17) / 2nd 1.67 (35/21) / 3rd 1.28 (32/25) / 4th 1.07 (29/27) 5th 0.93 (27/29):1
Transmission / Drive
5 Speed
Frame Type
Double Cradle
Suspension - Front
Telescopic forks
Suspension - Rear
Dual shocks preload adjustable
Rake
28.5°
Trail
102 mm / 4.0 in.
Wheel Travel - Front
200 mm / 7.9 in.
Brakes - Front
2x 260 mm discs, 2 piston calipers
Brakes - Rear
Single 250 mm disc, 1 piston caliper
Tyres - Front
110/90 -18
Tyres - Rear
130/90 -17
