Key Specifications
Engine
In-line four, four-stroke
Power
101.5 kW / 138 hp @ 9600 rpm
Torque
110.00 Nm (11.2 kgf-m or 81.1 ft.lbs) @ 7800
Top Speed
242.6 km/h / 150.7 mph
Weight
228 kg / 231 kg ABS
Fuel Capacity
5.02 gallons
Full 2012 Kawasaki Z 1000SX Specifications
Year
2011 - 12
Colours
Realtree APG HD camouflage
Colours
Green/black, grey/black
Make Model
Kawasaki Z 1000SX
Warranty
12 Months
Warranty
12 Months
Ground Clearance (in.)
5.3 inches
Ground Clearance (mm)
135 mm
Height (in.)
46.1 inches
Height (mm)
1,170 mm
Length (in.)
82.9 inches
Length (mm)
2,105 mm
Seat Height (in.)
32.3 inches
Seat Height (mm)
820 mm
Wheelbase (in.)
56.9 inches
Wheelbase (mm)
1,445 mm
Width (in.)
31.1 inches
Width (mm)
790 mm
Ground Clearance (in.)
5.3 inches
Ground Clearance (mm)
135 mm
Height (in.)
46.1 inches
Height (mm)
1,170 mm
Length (in.)
82.9 inches
Length (mm)
2,105 mm
Seat Height (in.)
32.3 inches
Seat Height (mm)
820 mm
Wheelbase (in.)
56.9 inches
Wheelbase (mm)
1,445 mm
Width (in.)
31.1 inches
Width (mm)
790 mm
Seat Height
822 mm / 32.3 in
Wheelbase
1445 mm / 56.8 in
Ground Clearance
135 mm / 5.2 in
Height
1230 mm / 48.4 in
Length
2105 mm / 82.8 in
Width
790 mm / 31.1 in
Fuel Capacity (gal.)
5.02 gallons
Fuel Capacity (l)
19.00 litres
Wet Weight (lbs.)
643.9 pounds
Wet Weight (kg)
292.1 kg
Wet Weight (kg)
228.0 kg
Wet Weight (lbs.)
502.7 pounds
Fuel Capacity (l)
19.00 litres
Fuel Capacity (gal.)
5.02 gallons
Dry Weight (lbs.)
502.7 pounds
Dry Weight (kg)
228
Fuel Capacity
18 Litres / 4.8 US gal
Wet Weight
228 kg / 231 kg ABS
Bore x Stroke (in,)
3.0 x 2.2 inches
Bore x Stroke (mm)
77.0 x 56.0 mm
Displacement (cc)
1043.00 cc
Displacement (ci)
63.64 cubic inches
Engine Type
In-line four, four-stroke
Fuel Control
DOHC
Bore x Stroke (in,)
3.0 x 2.2 inches
Bore x Stroke (mm)
77.0 x 56.0 mm
Displacement (cc)
1043.00 cc
Displacement (ci)
63.64 cubic inches
Fuel Control
DOHC
Engine Type
In-line four, four-stroke
Displacement
1043 cc / 63.7 cu-in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.
Fuel System
Injection. 38 mm x 4 (Keihin) with oval sub-throttles
Fuel System
Injection. 38 mm x 4 (Keihin) with oval sub-throttles
Bore x Stroke
77.0 x 56.0mm
Compression Ratio
11.8:1
Compression Ratio
11.8:1
Cooling System
Liquid cooled
Engine Lubrication
Forced lubrication, wet sump
Engine Lubrication
Forced lubrication, wet sump
Engine Oil Specification
Synthetic, 10W/40
Fuel Consumption
17.6 km/lit
Fuel Induction
DFIØ with four 38mm Keihin throttle bodies, oval sub-throttles
Ignition
TCBI with digital advance
Ignition
Digital
Lubrication
Wet sump
Spark Plug
NGK, CR9EK
Starter
Electric
Starter
Electric
Valve System
4
Valve System
4
Clutch
Wet, multiple discs, cable operated
Clutch
Wet mDouble disk, manual
Final Drive
Chain
Final Drive
Chain
Gear Ratios
1st 2.600 (39/15) 2nd 1.950 (39/20) 3rd 1.600 (24/15) 4th 1.389 (25/18) 5th 1.238 (26/21) 6th 1.136 (25/22)
Gearbox
6-speed
Primary Drive
Sealed chain
Primary Drive
Sealed chain
Transmission / Drive
6 Speed
Wheel Travel - Rear (mm)
138 mm
Wheel Travel - Rear (in.)
5.4 inches
Wheel Travel - Front (mm)
120 mm
Wheel Travel - Front (mm)
120 mm
Wheel Travel - Front (in.)
4.7 inches
Wheel Travel - Front (in.)
4.7 inches
Trail (mm)
102 mm
Trail (in.)
4.0 inches
Trail (in.)
4.0 inches
Trail (mm)
102 mm
Wheel Travel - Front (in.)
4.7 inches
Wheel Travel - Front (in.)
4.7 inches
Wheel Travel - Front (mm)
120 mm
Wheel Travel - Front (mm)
120 mm
Wheel Travel - Rear (in.)
5.4 inches
Wheel Travel - Rear (mm)
138 mm
Frame Type
Type: Aluminum Backbone
Frame Type
Aluminium twin-tube
Suspension - Front
41 mm inverted fork with stepless compression and rebound damping and spring preload adjustability
Suspension - Front
41mm inverted cartridge fork with stepless compression and rebound damping, adjustable spring preload
Suspension - Rear
Horizontal monoshock with stepless rebound damping, adjustable spring preload
Suspension - Rear
Horizontal Back-link, gas-charged, with stepless rebound damping and cam-style spring preload adjustability
Rake
25°
Rake
24.5°
Trail
102 mm / 4..0 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
135 mm / 5.4 in
Lighting system
30W x 2 halogen
Brakes - Rear Diameter (mm)
250 mm
Brakes - Rear Diameter (in.)
9.8 inches
Brakes - Front Diameter (mm)
300 mm
Brakes - Front Diameter (in.)
11.8 inches
Brakes - Rear Diameter (mm)
250 mm
Brakes - Rear Diameter (in.)
9.8 inches
Brakes - Front Diameter (mm)
300 mm
Brakes - Front Diameter (in.)
11.8 inches
Brakes - Front
2x 300mm 4 piston calipers
Brakes - Front
Double disc. Optional anti-lock braking
Brakes - Rear
Single 292mm disc 2 piston caliper
Brakes - Rear
Single disc. Optional anti-lock braking
Tyres - Front
120/70 R17
Tyres - Front
120/70-ZR17
Tyres - Front
25/8-12
Tyres - Rear
190/50 R17
Tyres - Rear
25/10-12
Tyres - Rear
190/50-ZR17
