Key Specifications
Engine
In-line four, four-stroke
Torque
102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 10400
Fuel Capacity
21.00 litres
Full 2012 Kawasaki Versys 1000 Specifications
Colours
Realtree APG HD camouflage
Warranty
12 Months
Width (mm)
900 mm
Width (in.)
35.4 inches
Wheelbase (mm)
1,520 mm
Wheelbase (in.)
59.8 inches
Seat Height (mm)
845 mm
Seat Height (in.)
33.3 inches
Length (mm)
2,235 mm
Length (in.)
88.0 inches
Height (mm)
1,405 mm
Height (in.)
55.3 inches
Ground Clearance (mm)
155 mm
Ground Clearance (in.)
6.1 inches
Wet Weight (lbs.)
643.9 pounds
Wet Weight (kg)
292.1 kg
Fuel Capacity (l)
21.00 litres
Fuel Capacity (gal.)
5.55 gallons
Dry Weight (lbs.)
526.9 pounds
Dry Weight (kg)
239
Fuel Control
DOHC
Engine Type
In-line four, four-stroke
Displacement (ci)
63.64 cubic inches
Displacement (cc)
1043.00 cc
Bore x Stroke (mm)
77.0 x 56.0 mm
Bore x Stroke (in,)
3.0 x 2.2 inches
Fuel System
Injection
Compression Ratio
10.3:1
Engine Lubrication
Forced lubrication, wet sump
Ignition
Digital
Starter
Electric
Valve System
4
Clutch
Wet mDouble disk, manual
Final Drive
Chain
Primary Drive
Sealed chain
Frame Type
Aluminium twin-tube
Suspension - Front
43 mm inverted fork with stepless
Suspension - Rear
Horizontal Back-link, gas-charged,
Rake
27.0°
Lighting system
30W x 2 halogen
Brakes - Front
Double disc
Brakes - Rear
Single disc
Tyres - Front
120/70-ZR17
Tyres - Front
25/8-12
Tyres - Rear
180/55-ZR17
Tyres - Rear
25/10-12
