Key Specifications
Engine
Single cylinder, four-stroke
Weight
111 kg / 244.7 lbs
Fuel Capacity
8.50 litres / 2.25 US gallons
Advertisement
Full 2021 Husqvarna FE 501 Specifications
Year
2020 - 21
Colours
White/blue/yellow
Colours
White/blue/yellow
Make Model
Husqvarna FE 501
Ground Clearance (mm)
360 mm
Ground Clearance (in.)
14.2 inches
Ground Clearance (mm)
360 mm
Ground Clearance (in.)
14.2 inches
Seat Height
950 mm / 37.4 in.
Seat Height
970 mm / 38.2 in
Wheelbase
1482 mm / 58.3 in.
Wheelbase
1482±10 mm / 58.3 in
Ground Clearance
370 mm / 14.6 in
Length
2260 mm / 89.0 in.
Length
2260 mm / 89.0 in
Dry Weight
108.4 kg / 239.0 lbs
Dry Weight
111 kg / 244.7 lbs
Fuel Capacity
8.50 litres / 2.25 US gallons
Fuel Capacity
8.5 Litres / 2.25 US gal
Fuel Control
Single Overhead Cams (SOHC)
Engine Type
Single cylinder, four-stroke
Displacement (ci)
31.14 cubic inches
Displacement (cc)
510.4 cc
CO2
84.0 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
95.0 x 72.0 mm
Bore x Stroke (in,)
3.7 x 2.8 inches
Fuel Control
Single Overhead Cams (SOHC)
Engine Type
Single cylinder, four-stroke
Displacement
510.4 cc / 31.1 cu in
Engine Detail
Four stroke. single cylinder. SOHC. 4 valve per cylinder
Fuel System
Carburettor
Fuel System
Carburettor
Bore x Stroke
95 x 72.0 mm
Compression Ratio
12.7:1.
Compression Ratio
12.2:1
Cooling System
Liquid cooling system, continuous circulation of cooling liquid with water pump
Engine Lubrication
Forced oil lubrication with 2 Eaton pumps
Fuel Consumption
3.62 litres/100 km (27.6 km/l or 64.98 mpg)
Fuel Induction
Keihin electronic fuel injection and 42mm throttle body
Ignition
Keihin EMS
Ignition
Keihin EMS
Lubrication
Forced oil lubrication with 2 Eaton pumps
Starter
Electric
Starter
Electric
Clutch
Wet, DDS multi-disc clutch, Magura hydraulics
Clutch
Wet, DDS multi-disc clutch, Magura hydraulics
Final Drive
Chain 520 X-Ring
Final Drive
Chain (final drive)
Gearbox
6-speed
Gearbox
6-speed
Primary Drive
X-ring 5/8 x 1/4 in chain
Primary Drive
X-ring 5/8 x 1/4 in chain
Primary Drive Ratios
31:76
Secondary Drive Ratio
14:52 (13:52)
Transmission / Drive
6 Speed, claw shifted
Frame Type
Central double-cradle-type 25CrMo4 steel
Frame Type
Frame design 25CrMo4 steel central-tube
Suspension - Front
WP XPLOR-USD, Ø 48 mm
Suspension - Front
WP-USD Xplor 48 with preload adjuster
Suspension - Rear
WP XACT Monoshock with linkage
Suspension - Rear
WP shock absorber with linkage
Rake
26.5°
Rake
26.5
Steering Head Angle
63.5°
Trail
107 mm / 4.2 in.
Trail
107 mm / 4.2 in
Wheel Travel - Front
300 mm /11.8 in
Wheel Travel - Front
300 mm / 11.8 in.
Wheel Travel - Rear
300 mm / 11.8 in
Wheel Travel - Rear
300 mm / 11.8 in.
Brakes - Front
Single disc. Magura. Wave disk.
Brakes - Front
Single 260 mm with 4 pot brake caliper
Brakes - Rear
Single disc. Magura. Wave disk.
Brakes - Rear
Single 220 mm with 1 pot brake caliper
Tyres - Front
90/90-21
Tyres - Front
90/90-21
Tyres - Rear
140/80-18
