Key Specifications
Engine
Four stroke, parallel twin with 270° crank and uni-cam, OHC, 4 valves per cylinder
Power
90 hp / 67.5 kW @ 9500rpm
Torque
75Nm / 55.3 lb-ft @ 7250rpm
Fuel Capacity
15.2 Litres / 4.0 US gal
Advertisement
Full 2025 Honda CB 750 Hornet Specifications
Year
2025
Make Model
Honda CB 750 Hornet
Seat Height
795 mm / 31.3 in
Wheelbase
1420 mm / 55.9 in
Ground Clearance
140 mm / 5.5 in
Height
1085mm / 42.7 in
Length
2090 mm / 82.3 in
Width
780 mm / 30.7 in
Fuel Capacity
15.2 Litres / 4.0 US gal
Wet Weight
192 kg / 423 lbs
Displacement
755cc / 46 cu-in
Engine Detail
Four stroke, parallel twin with 270° crank and uni-cam, OHC, 4 valves per cylinder
Bore x Stroke
87 x 63.5 mm
Compression Ratio
11.0:1
Cooling System
Liquid-cooled
Fuel Induction
PGM-FI electronic injection
Starter
Electric
Clutch
Wet multiple, Assisted slipper clutch
Final Drive
Chain
Transmission / Drive
6 speed
Frame Type
Steel diamond
Suspension - Front
41 mm Showa SFF-BPTMTM USD
Suspension - Rear
Monoshock damper, Pro-Link swingarm,
Rake
25˚
Trail
99 mm / 3.9 in
Wheel Travel - Front
130 mm / 5.1 in
Wheel Travel - Rear
130 mm / 5.1 in
Brakes - Front
2 x 296 mm floating discs, 4 piston Nissin radial calipers
Brakes - Rear
Single 240mm disc, 1 piston caliper
ABS
2 Channel
Tyres - Front
120/70ZR-17M/C 58W
Tyres - Rear
160/60ZR-17M/C 69W
Wheels
5Y-Spoke Cast Aluminium
Wheels - Front
17M/C x MT3.50
Wheels - Rear
17M/C x MT4.50
