2017 Harley-Davidson Dyna Street Bob Specifications

Name: 2017 Harley-Davidson Dyna Street Bob
Brand: Harley-Davidson

No images available

Tap to enlarge

2017 Harley-Davidson Dyna Street Bob Overview

The 2017 Harley-Davidson Dyna Street Bob is a custom / cruiser motorcycle built around 1690 cc of displacement. Under the tank sits a Four stroke, V-Twin, Twin Cam 103° with integrated oil cooler engine, a compression ratio of 9.6:1. 2017 Harley-Davidson Dyna Street Bob delivers 130 Nm @ 3000 rpm of torque. From a practical standpoint, the 2017 Dyna Street Bob tips the scales at 304 kg, carries a 17 8 litres fuel tank, offers a seat height of Laden 648 mm and spans a 1630 mm wheelbase. Scroll down for the complete 2017 Harley-Davidson Dyna Street Bob spec sheet covering every technical detail from suspension travel to tyre sizes.

2017 Dyna Street Bob - Pros & Cons

Strengths

Accessible seat height: At Laden 648 mm, the seat height is approachable for a wide range of rider heights and builds confidence in low-speed manoeuvring.

Considerations

Age-related wear: As with any used Dyna Street Bob, a thorough pre-purchase inspection covering consumables, service history and tyres is always recommended.

Owner Experiences & Common Issues

General ownership notes

The 2017 Harley-Davidson Dyna Street Bob has built a reputation for solid everyday reliability when serviced to schedule. As with any motorcycle of this era, documented service history is the single biggest indicator of long-term reliability when buying used.

Dyna Street Bob - Buying & Maintenance Guide

What to check before buying

When inspecting a used 2017 Harley-Davidson Dyna Street Bob, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained Dyna Street Bob should fire up cleanly and settle to a smooth idle within a few seconds.

Oil and filter changes

Regular oil changes are the single most important maintenance task on any Dyna Street Bob. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. Always use the correct viscosity grade as specified in the owner's manual.

2017 Harley-Davidson Dyna Street Bob - Frequently Asked Questions

What engine does the 2017 Harley-Davidson Dyna Street Bob have?

The 2017 Harley-Davidson Dyna Street Bob uses a Four stroke, V-Twin, Twin Cam 103° with integrated oil cooler engine with 1690 cc of displacement. It is air cooled.

How much does the 2017 Harley-Davidson Dyna Street Bob weigh?

The 2017 Harley-Davidson Dyna Street Bob weighs 304 kg. This is the manufacturer's wet figure.

How much power does the 2017 Harley-Davidson Dyna Street Bob make?

The 2017 Harley-Davidson Dyna Street Bob produces 130 Nm @ 3000 rpm of torque.

What is the fuel tank capacity of the 2017 Harley-Davidson Dyna Street Bob?

The 2017 Harley-Davidson Dyna Street Bob has a 17 8 litres fuel tank. At around 5-6 litres per 100 km, that is roughly 283-340 km between stops.

Is the 2017 Harley-Davidson Dyna Street Bob suitable for shorter riders?

The 2017 Harley-Davidson Dyna Street Bob has a seat height of Laden 648 mm. This is a comfortable, accessible height for most riders.

What brakes does the 2017 Harley-Davidson Dyna Street Bob have?

The 2017 Harley-Davidson Dyna Street Bob uses Single 300mm disc, 4 piston caliper, fixed at the front and Single 292mm disc, 2 piston caliper, floating at the rear.

What tyre sizes does the 2017 Harley-Davidson Dyna Street Bob use?

The 2017 Harley-Davidson Dyna Street Bob runs 100/90-B19 57H front and 160/70-B17 73V rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2017 Harley-Davidson Dyna Street Bob have?

The 2017 Harley-Davidson Dyna Street Bob is fitted with a 6 Speed transmission.

Harley-Davidson Dyna Street Bob Spec Evolution

The Harley-Davidson Dyna Street Bob was produced across 4 model years (2013-2017). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2013	2014	2015	2017
Wet Weight	302.6 kg / 667 lbs.	304.0 kg / 670 lbs	304.0 kg / 670 lbs	304.0 kg / 670 lbs
Engine Detail	Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder	Four stroke, V-Twin, Twin Cam 103° with integrated oil cooler	Four stroke, V-Twin, Twin Cam 103° with integrated oil cooler	Four stroke, V-Twin, Twin Cam 103° with integrated oil cooler
Seat Height	Laden 648 mm / 25.5 in. Unladen 678 mm / 26.7 in.	Laden 648 mm / 25.5 in. Unladen 678 mm / 26.7 in.	Laden 648 mm / 25.5 in. Unladen 678 mm / 26.7 in.	Laden 648 mm / 25.5 in. Unladen 680 mm / 26.8 in.
Fuel Capacity	17.8 Litres / 4.7 gal	17 8 Litres / 4.7 US gal	17 8 Litres / 4.7 US gal	17 8 Litres / 4.7 US gal
Displacement	1584 cc / 96 cu-in	1690 cc / 103.1 cu in	1690 cc / 103.1 cu in	1690 cc / 103.1 cu in
Brakes - Front	Single 300mm disc 4 piston caliper	Single 300mm disc 4 piston caliper	Single 300mm disc 4 piston caliper	Single 300mm disc, 4 piston caliper, fixed
Brakes - Rear	Single 292mm disc 2 piston caliper	Single 292mm disc 2 piston caliper	Single 292mm disc 2 piston caliper	Single 292mm disc, 2 piston caliper, floating
Suspension - Rear	Coil over shock ,	Coil over shock ,	Coil over shock ,	Coil over shock

Key Specifications

Engine

Four stroke, V-Twin, Twin Cam 103° with integrated oil cooler

Power

N/A

Torque

130 Nm / 13.3 kgf-m / 95.9 ft-lb @ 3000 rpm

Top Speed

N/A

Weight

304.0 kg / 670 lbs

Fuel Capacity

17 8 Litres / 4.7 US gal

Full 2017 Harley-Davidson Dyna Street Bob Specifications

Year 2016 - 17

Make Model Harley Davidson Dyna Street Bob

Max Torque 130 Nm / 13.3 kgf-m / 95.9 ft-lb @ 3000 rpm

Displacement 1690 cc / 103.1 cu in

Engine Detail Four stroke, V-Twin, Twin Cam 103° with integrated oil cooler

Bore x Stroke 98.4 x 111.1 mm

Compression Ratio 9.6:1

Cooling System Air cooled

Exhaust Chrome, staggered, shorty exhaust with dual tapered mufflers

Fuel Induction Electronic Sequential Port Fuel Injection (ESPFI)

Ignition Single-fire, non-wasted, map-controlled spark ignition

Starter Electric
