Brakes - Rear
|
245 mm disc, 2-piston calliper with Bosch Cornering ABS EVO | 245 mm disc, 2-piston calliper with Bosch Cornering ABS EVO | Single 245 mm disc, 2-piston calliper |
|
Fuel Capacity
|
16 Litres / 4.23 US gal | 16 Litres / 4.23 US gal | 17 Litres / 4.49 US gal ↑ |
|
Suspension - Rear
|
Fully adjustable Ohlins TTX36 unit. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode. Aluminium single-sided swingarm. | Fully adjustable Ohlins TTX36 unit. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode. Aluminium single-sided swingarm. | Fully adjustable Öhlins TTX36 unit. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode. Aluminium single-sided swingarm |
|
Clutch
|
Hydraulically controlled slipper and self-servo wet multiplate clutch | Hydraulically controlled slipper and self-servo wet multiplate clutch | Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder |
|
Final Drive
|
Chain, front sprocket 15, rear sprocket 42 | Chain, front sprocket 15, rear sprocket 42 | Chain 525, Front sprocket 15, Rear sprocket 42 ↑ |
|
Equipment / Features
|
Last generation digital unit with 5" TFT colour display Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down EVO 2, Full LED lighting with Daytime Running Light (DRL), Ducati Electronic Suspension (DES) EVO with Ohlins suspension and steering damper, Quick adjustment buttons, Auto-off indicators, Passenger seat and footpegs, Ducati Multimedia System (DMS). Marchesini aluminium forged wheels. | Last generation digital unit with 5" TFT colour display Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down EVO 2, Full LED lighting with Daytime Running Light (DRL), Ducati Electronic Suspension (DES) EVO with Ohlins suspension and steering damper, Quick adjustment buttons, Auto-off indicators, Passenger seat and footpegs, Ducati Multimedia System (DMS). Marchesini aluminium forged wheels. | Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down EVO 2, Full LED lighting with Daytime Running Light (DRL), Ducati Electronic Suspension (DES) EVO with Ohlins suspension and steering damper, Quick adjustment buttons, Auto-off indicators, Marchesini aluminum forged wheels, Lithium-ion battery, Passenger seat cover | Passenger seat and footpegs ↓ |
|
Wet Weight
|
199 kg / 439 lbs | 199 kg / 439 lbs | 196.8 kg / 434 lbs ↓ |
|
Gear Ratios
|
1st 38/14 2nd 36/17 3rd 33/19 4th 32/21 5th 30/22 6th 30/24 | 1st 38/14 2nd 36/17 3rd 33/19 4th 32/21 5th 30/22 6th 30/24 | 1st 38/14 2nd 36/17 3rd 33/19 4th 32/21 5th 30/22 6th 30/24 |
|
Emissions
|
Euro 4 | Euro 5 ↑ | Euro 5 |
|
Safety Equipment
|
Riding Modes, Power Modes, Cornering ABS EVO, Ducati Traction Control (DTC) EVO 2, Ducati Wheelie Control (DWC) EVO, Ducati Slide Control (DSC), Engine Brake Control (EBC) EVO, Auto tyre calibration. | Riding Modes, Power Modes, Cornering ABS EVO, Ducati Traction Control (DTC) EVO 2, Ducati Wheelie Control (DWC) EVO, Ducati Slide Control (DSC), Engine Brake Control (EBC) EVO, Auto tyre calibration. | Riding Modes, Power Modes, Cornering ABS EVO, Ducati Traction Control (DTC) EVO 2, Ducati Wheelie Control (DWC) EVO, Ducati Slide Control (DSC), Engine Brake Control (EBC) EVO 2, Auto tire calibration |
|
Rake
|
24,5° | 24.5° | - |
|
Trail
|
100 mm / 4 in | 100 mm / 4 in | 100 mm / 3.94 in |
|
Max Power
|
208 hp / 153 kW @ 12,750 rpm | 208 hp / 153 kW @ 12750 rpm | - |
|
Max Torque
|
123 Nm / 90.4 lb-ft @ 11,500 rpm | 123 Nm / 90.4 lb-ft @ 11000 rpm | - |
