Dry Weight
|
204 kg / 450lbs | 204 kg / 450lbs | 204 kg / 450 lbs | 204 kg / 450 lbs |
|
Brakes - Front
|
2 x 320 mm Semi-floating discs, radially mounted monoblocco Brembo callipers, 4-piston, 2-pad, ABS standard | 2 x 320 mm Semi-floating discs, radially mounted monoblocco Brembo callipers, 4-piston, 2-pad, ABS standard | 2 x 320 mm semi-floating discs, Radially mounted Brembo monobloc 4-piston 2-pad callipers, Radial Master Cylinder, Bosch Cornering ABS | 2 x 320 mm semi-floating discs, Radially mounted Brembo monobloc 4-piston 2-pad callipers, Radial Master Cylinder, Bosch Cornering ABS |
|
Fuel Capacity
|
20 L / 5.3 US gal / 4.4 Imp gal | 20 L / 5.3 US gal / 4.4 Imp gal | 20 Litres / 5.3 US gal / 4.4 Imp gal | 20 Litres / 5.3 US gal / 4.4 Imp gal |
|
Brakes - Rear
|
Single 265 mm Disc, 2-piston floating calliper, ABS standard | Single 265 mm Disc, 2-piston floating calliper, ABS standard | Single 265mm disc, 2-piston floating calliper, Bosch Cornering ABS | Single 265mm disc, 2-piston floating calliper, Bosch Cornering ABS |
|
Suspension - Front
|
KYB 48 mm fully adjustable upside-down forks | KYB 48 mm fully adjustable upside-down forks | 48 mm fully adjustable USD fork | 48 mm fully adjustable USD fork |
|
Suspension - Rear
|
Fully adjustable Sachs monoshock unit, temote spring preload adjustment, aluminium doublesided swingarm | Fully adjustable Sachs monoshock unit, temote spring preload adjustment, aluminium doublesided swingarm | Fully adjustable monoshock, Remote spring preload adjustment, Aluminium double-sided swingarm | Fully adjustable monoshock, Remote spring preload adjustment, Aluminium double-sided swingarm |
|
Clutch
|
Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on overrun | Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on overrun | Slipper and self-servo wet multiplate clutch with hydraulic control | Slipper and self-servo wet multiplate clutch with hydraulic control |
|
Final Drive
|
Chain | Chain | Chain, Front sprocket Z15, Rear sprocket Z43 | Chain, Front sprocket Z15, Rear sprocket Z43 |
|
Tyres - Front
|
120/70 - R19, Pirelli Scorpion Trail II | 120/70 - R19, Pirelli Scorpion Trail II | 120/70 - ZR19, Pirelli Scorpion Trail II | 120/70 - ZR19, Pirelli Scorpion Trail II |
|
Tyres - Rear
|
170/60 - R17, Pirelli Scorpion Trail II | 170/60 - R17, Pirelli Scorpion Trail II | 170/60 - ZR17, Pirelli Scorpion Trail II | 170/60 - ZR17, Pirelli Scorpion Trail II |
|
Primary Drive Ratios
|
1.84:1 | 1.84:1 | Straight cut gears, ratio 1.84 : 1 | Straight cut gears, ratio 1.84 : 1 |
|
Rake
|
25.2o | 25.2o | 25° ↓ | 25° |
|
Exhaust
|
Stainless steel muffler with catalytic converter and 2 lambda probes, single stainless steel muffler, Euro 4 compliant | Stainless steel muffler with catalytic converter and 2 lambda probes, single stainless steel muffler, Euro 4 compliant | Stainless steel single muffler, Catalytic converter and 2 lambda probes | Stainless steel single muffler, Catalytic converter and 2 lambda probes |
|
Wheels - Front
|
Cast alloy, 3.00 x 19" | Cast alloy, 3.00 x 19" | Light alloy casted 3.0″ x 19″ | Light alloy casted 3.0″ x 19″ |
|
Wheels - Rear
|
Cast alloy, 4.50 x 17" | Cast alloy, 4.50 x 17" | Light alloy casted 4.5″ x 17″ | Light alloy casted 4.5″ x 17″ |
|
Fuel Induction
|
Fuel injection Bosch electronic fuel injection system, cylindrical throttle bodies with Ride-by-Wire, diameter 53 mm | Fuel injection Bosch electronic fuel injection system, cylindrical throttle bodies with Ride-by-Wire, diameter 53 mm | Electronic fuel injection system, 53 mm throttle bodies with Ride-by-Wire system | Electronic fuel injection system, 53 mm throttle bodies with Ride-by-Wire system |
|
Trail
|
105.7 mm / 4.16 in | 105.7 mm / 4.16 in | 106 mm / 4.2 in ↑ | 106 mm / 4.2 in |
