Key Specifications
Power
72 kW / 98 hp @ 6750rpm
Top Speed
198 km/h / 123 mph
Fuel Capacity
23.40 litres
Full 2004 BMW K 1200LT Specifications
Year
2003 - 05
Colours
Anthracite Metallic, Impala Brown Metallic
Make Model
BMW K 1200LT
Wheelbase (mm)
1,633 mm
Wheelbase (in.)
64.3 inches
Seat Heigth -Alternate (mm)
800 mm
Seat Heigth -Alternate (in.)
31.5 inches
Seat Height (mm)
770 mm
Seat Height (in.)
30.3 inches
Width (mm)
920 mm
Width (in.)
36.2 inches
Wheelbase (mm)
1,637 mm
Wheelbase (in.)
64.4 inches
Seat Heigth -Alternate (mm)
800 mm
Seat Heigth -Alternate (in.)
31.5 inches
Seat Height (mm)
770 mm
Seat Height (in.)
30.3 inches
Length (mm)
2,505 mm
Length (in.)
98.6 inches
Height (mm)
1,395 mm
Height (in.)
54.9 inches
Seat Height
770 mm / 30.3 in
Wet Weight (kg)
378
Fuel Capacity (l)
23.40 litres
Fuel Capacity (gal.)
6.18 gallons
Dry Weight (lbs.)
833.3 pounds
Dry Weight (kg)
378
Fuel Capacity (l)
24.00 litres
Fuel Capacity (gal.)
6.34 gallons
Dry Weight (lbs.)
779.3 pounds
Dry Weight (kg)
353.5
Dry Weight
345 kg / 761 lbs
Fuel Capacity
22 L / 5.8 US gal
Wet Weight
378 kg / 833 lbs
Fuel Control
DOHC
Fuel Reserve (gal.)
1.06 gallons
Fuel Reserve (l)
4.00 litres
Engine Type
Single cylinder
Displacement (ci)
71.45 cubic inches
Displacement (cc)
1171.00 cc
Stroke
4
Stroke
4
Engine Type
In-line four
Displacement (ci)
71.45 cubic inches
Displacement (cc)
1171.00 cc
Bore x Stroke (mm)
70.5 x 75.0 mm
Bore x Stroke (in,)
2.8 x 3.0 inches
Displacement
1172 cc / 71.5 cu in
Engine Detail
Four stroke, horizontal in line four cylinder, DOHC, 4 valves per cylinder
Fuel System
Injection
Bore x Stroke
75 x 70.5 mm
Compression Ratio
11.5:1
Compression Ratio
10.8:1
Cooling System
Liquid cooled
Fuel Consumption
6.0 L/100 km / 16.8 km/l / 39.5 US mpg
Fuel Induction
Electronic intake pipe injection
Ignition
MA 2.4 Bosch Motronic
Starter
Electric
Valve System
4
Final Drive
Shaft
Final Drive
Shaft drive (cardan)
Gear Ratios
1st 2.050 / 2nd 1.600 / 3rd 1.270 / 4th 0.960 / 5th 0.700:1
Gearbox
5-speed
Transmission / Drive
5 Speed
Wheel Travel - Rear (mm)
130 mm
Wheel Travel - Rear (in.)
5.1 inches
Wheel Travel - Front (mm)
102 mm
Wheel Travel - Front (mm)
102 mm
Wheel Travel - Front (in.)
4.0 inches
Wheel Travel - Front (in.)
4.0 inches
Frame Type
Bridging frame consisting of die cast aluminium, engine de-coupled from vibration through bearings
Frame Type
Bridging frame consisting of die-cast aluminium, engine decoupled from vibration through bearings.
Suspension - Front
Motorrad Telelever, stanchion diameter ∅35 mm, central strut
Suspension - Front
BMW Motorrad Telelever; stanchion diameter 35 mm, central strut.
Suspension - Rear
Die cast Aluminum single sided swinging arm with Paralever, central strut, spring preload adjustable to continuously variable levels by mean of hydraulic hand wheel
Suspension - Rear
Die-cast aluminium single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring pre-load hydraulically adjustable to continuously variable levels by means of handwheel.
Brakes - Front Diameter (in.)
12.6 inches
Brakes - Front Diameter (mm)
320 mm
Brakes - Rear Diameter (in.)
11.2 inches
Brakes - Rear Diameter (mm)
285 mm
Brakes - Front
2 x ∅320mm disc, 4 piston calipers, ABS
Brakes - Front
Double disc
Brakes - Rear
Single ∅285mm disc, 2 piston caliper, ABS
Brakes - Rear
Single disc
Tyres - Front
120/70 ZR17
Tyres - Front
120/70-ZR17
Tyres - Rear
160/70 ZR17
Tyres - Rear
160/70-ZR17
