Comments
|
- | - | Small windscreen. | Small windscreen. Swicthable ABS. | Small windscreen. Swicthable ABS. | Small windscreen. Riding Modes Rain and Road. |
|
Frame Type
|
Tubular frame in steal partly carrying the engine | Tubular frame in steal partly carrying the engine | Tubular frame in steal partly carrying the engine | Tubular frame in steal partly carrying the engine | Tubular frame in steal partly carrying the engine | Tubular steel space frame, load-bearing engine |
|
Dry Weight
|
214 kg / 472 lbs | 214 kg / 472 lbs | 214 kg / 472 lbs | 214 kg / 472 lbs | 214 kg / 472 lbs | 192 kg / 423.3 lbs ↓ |
|
Seat Height
|
890 mm / 860 mm / 35 in. / 33.9 in. | 890 mm / 860 mm / 35 in. / 33.9 in. | 890 mm / 860 mm / 35 in. / 33.9 in. | 890 mm / 860 mm / 35 in. / 33.9 in. | 890 mm / 860 mm / 35 in. / 33.9 in. | 890 mm / 35.0 in. |
|
Wheelbase
|
1577 mm / 62.1 in | 1577 mm / 62.1 in | 1577 mm / 62.1 in | 1577 mm / 62.1 in | 1577 mm / 62.1 in | 1,573 mm / 61.9 in. ↓ |
|
Brakes - Front
|
2 x ∅300mm discs, 4 piston calipers, ABS | 2 x 300mm discs, 4 piston calipers, ABS | 2 x ∅300mm discs, 4 piston calipers, ABS | 2 x ∅300mm discs, 4 piston calipers, ABS | 2 x ∅300mm discs, 4 piston calipers, ABS | Double disc. ABS |
|
Brakes - Rear
|
Single ∅265mm disc, 2 piston caliper, ABS | Single 265mm disc, 2 piston caliper, ABS | Single ∅265mm disc, 2 piston caliper, ABS | Single ∅265mm disc, 2 piston caliper, ABS | Single ∅265mm disc, 2 piston caliper, ABS | Single disc. ABS |
|
Fuel Capacity
|
24 Litres / 6.3 US gal. | 24 Litres / 6.3 US gal. | 24 Litres / 6.3 US gal. | 24 Litres / 6.3 US gal. | 24 Litres / 6.3 US gal. | 24.00 litres / 6.34 gallons |
|
Suspension - Front
|
43mm Marzocchi upside down forks | 43mm Marzocchi upside down forks | 43mm Marzocchi upside down forks | ∅43mm Marzocchi upside down forks | 43mm Marzocchi upside down forks | Upside-down fork |
|
Top Speed
|
199.0 km/h / 124 mph | 199.0 km/h / 124 mph | 199.0 km/h / 124 mph | 199.0 km/h / 124 mph | 199.0 km/h / 124 mph | 193.0 km/h / 119.9 mph ↓ |
|
Suspension - Rear
|
Double strut swing arm aluminium coast in one piece | Double strut swing arm aluminium coast in one piece | Double strut swing arm aluminium coast in one piece | Double strut swing arm aluminium coast in one piece | Double strut swing arm aluminium coast in one piece | Aluminium double sided swing-arm at the rear |
|
Fuel System
|
- | Injection. Electronic fuel injection,BMS-K+ electronic engine management | Injection. Electronic fuel injection,BMS-K+ electronic engine management | Injection. Electronic fuel injection,BMS-K+ electronic engine management | Injection. Electronic intake pipe injection, digital engine management (BMS-K+) | Injection. Electronic intake pipe injection, digital engine management (BMS-K+) |
|
Colours
|
- | Red, sand | Black | Kalamata Metallic Matte, Alpine White | Catalano Grey, Racing Red | Racing Blue Metallic, Racing Red Matt |
|
Clutch
|
Multiplate-plate in oil bath | Multiplate-plate in oil bath | Multiplate-plate in oil bath | Multiplate-plate in oil bath | Multiplate-plate in oil bath | Multiple-disc clutch in oil bath, mechanically operated |
|
Max Load
|
496 lbs. | 496 lbss | - | - | - | - |
|
Height
|
1450 mm / 57.1 in (excl. mirrors) | 1450 mm / 57.1 in (excl. mirrors) | 1450 mm / 57.1 in (excl. mirrors) | 1450 mm / 57.1 in (excl. mirrors) | 1450 mm / 57.1 in (excl. mirrors) | 1,450 mm / 57.1 in. ↓ |
|
Rims
|
- | Spoked | Spoked | Spoked | Wire spoke wheels | Spoke wheels |
|
Length
|
2304 mm / 90.7 in | 2304 mm / 90.7 in | 2304 mm / 90.7 in | 2304 mm / 90.7 in | 2304 mm / 90.7 in | 2,305 mm / 90.7 in. ↓ |
|
Wet Weight
|
229 kg / 505 lbs | 229 kg / 505 lbs | 229 kg / 505 lbs | 229 kg / 505 lbs | 229 kg / 505 lbs | 232.0 kg / 511.5 lbs ↑ |
|
Emissions
|
- | Regulated three-way catalytic converter, compliant with EU3 emission standard | Regulated three-way catalytic converter, compliant with EU3 emission standard | Regulated three-way catalytic converter, compliant with EU3 emission standard | Performance / fuel consumption | - |
|
Tyres - Front
|
90/90 - 21 54V | 90/90 - 21 54V | 90/90 - 21 54V | 90/90 - 21 54V | 90/90 - 21 54V | 90/90-21 |
|
Width
|
925 mm / 36.4 in (incl. mirrors) | 925 mm / 36.4 in (incl. mirrors) | 925 mm / 36.4 in (incl. mirrors) | 925 mm / 36.4 in (incl. mirrors) | 925 mm / 36.4 in (incl. mirrors) | 925 mm / 36.4 in. |
|
Tyres - Rear
|
150/70 - 17 69V | 150/70 - 17 69V | 150/70 - 17 69V | 150/70 - 17 69V | 150/70 - 17 69V | 150/70-17 |
|
Primary Drive
|
- | Endless O-ring chain with cush damper at rear wheel hub | Endless O-ring chain with cush damper at rear wheel hub | Endless O-ring chain with cush damper at rear wheel hub | Endless O-ring chain with shock damping in rear wheel hub | Endless O-ring chain with shock damping in rear wheel hub |
|
Rake
|
26° | 26° | 26° | 26° | 26° | 26.0° |
|
Fuel Consumption
|
4.3 L/100km / 23.3 km/l / 55 mpg | 4.3 L/100km / 23.3 km/l / 55 mpg | 4.3 L/100km / 23.3 km/l / 55 mpg | 4.3 L/100km / 23.3 km/l / 55 mpg | 4.3 L/100km / 23.3 km/l / 55 mpg | 4.30 litres/100 km (23.3 km/l or 54.70 mpg) |
|
Trail
|
117 mm / 4.6 in. | 117 mm / 4.6 in. | 117 mm / 4.6 in. | 117 mm / 9.1 in. | 117 mm / 4.6 in. | 117 mm / 4.6 in. |
|
Max Torque
|
80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm | 80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm | 80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm | 80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm | 80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm | 83.00 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 5750 Revolutions ↑ |
|
Power-to-Weight Ratio
|
- | 0.4450 HP/kg | 0.4450 HP/kg | 0.4450 HP/kg | 0.4450 HP/kg | 0.4427 HP/kg |
