| General |
| Comments | Small windscreen. Ride-by-wire system. | Switchable ABS. |
| Colours | White | Lupin Blue/Light Metallic Grey, Granite Grey Metallic Matte |
| Dimensions |
| Width (in.) | - | 36.4 inches |
| Width (mm) | - | 925 mm |
| Height (mm) | - | 1,273 mm |
| Height (in.) | - | 50.1 inches |
| Length (mm) | - | 2,202 mm |
| Ground Clearance (in.) | 8.7 inches | - |
| Length (in.) | - | 86.7 inches |
| Seat Height (in.) | 33.9 inches | 32.3 inches |
| Seat Heigth -Alternate (in.) | 34.4 inches | - |
| Ground Clearance (mm) | 220 mm | - |
| Seat Heigth -Alternate (mm) | 875 mm | - |
| Wheelbase (in.) | 61.4 inches | 60.1 inches |
| Wheelbase (mm) | 1,560 mm | 1,527 mm |
| Seat Height (mm) | 860 mm | 820 mm |
| Weights & Capacities |
| Fuel Capacity (gal.) | 7.93 gallons | 4.76 gallons |
| Wet Weight (kg) | - | 236.0 kg |
| Wet Weight (lbs.) | - | 520.3 pounds |
| Fuel Capacity (l) | 30.00 litres | 18.00 litres |
| Dry Weight (lbs.) | 504.9 pounds | 436.5 pounds |
| Dry Weight (kg) | 229 | 198 |
| Performance |
| Max Torque | - | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions">RPM |
| Power-to-Weight Ratio | 0.6987 HP/kg | 0.6231 HP/kg |
| Engine |
| Engine Type | V2, four-stroke | Two cylinder boxer, two-stroke |
| Bore x Stroke (mm) | 108.0 x 75.0 mm | 101.0 x 73.0 mm |
| Fuel Reserve (l) | - | 3.00 litres |
| Fuel Reserve (gal.) | - | 0.79 gallons |
| Fuel Control | - | Double Overhead Cams/Twin Cam (DOHC) |
| CO2 | - | 95.1 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Bore x Stroke (in,) | 4.3 x 3.0 inches | 4.0 x 2.9 inches |
| Engine Detail | 75° V arrangement | - |
| Fuel System | Injection | Injection. Electronic intake pipe injection |
| Compression Ratio | - | 12.5:1 |
| Engine Lubrication | Forced oil lubrication with 3 rotor pumps | Wet sump |
| Fuel Consumption | - | 4.10 litres/100 km (24.4 km/l or 57.37 mpg) |
| Ignition | Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment | - |
| Starter | Electric | Electric |
| Valve System | - | 4 |
| Drivetrain |
| Clutch | PASC anti-hopping clutch/ hydraulically operated | Oil lubricated clutch, hydraulically operated |
| Final Drive | Chain | Shaft drive (cardan) |
| Gearbox | 6-speed | 6-speed |
| Primary Drive | 5/8 x 5/16 X Ring. Primary drive: 40:76. | Constant mesh |
| Chassis |
| Trail (mm) | - | 115 mm |
| Trail (in.) | - | 4.5 inches |
| Wheel Travel - Rear (mm) | 200 mm | 140 mm |
| Wheel Travel - Rear (in.) | 7.9 inches | 5.5 inches |
| Wheel Travel - Front (mm) | 200 mm | 140 mm |
| Wheel Travel - Front (in.) | 7.9 inches | 5.5 inches |
| Frame Type | Tubular space frame made from chrome molybdenum steel, powder-coated | Two-section frame, front- and bolted on rear frame, load-bearing engine |
| Suspension - Front | WP Semi-active Suspension USD ? 48 mm | Telescopic Upside-Down fork |
| Suspension - Rear | WP Semi-active Suspension PDS Monoshock | Cast aluminium single-sided swing arm with BMW Motorrad Paralever |
| Rake | 26.0° | 27.7° |
| Wheels & Brakes |
| Brakes - Front Diameter (in.) | 12.6 inches | 12.6 inches |
| Brakes - Front Diameter (mm) | 320 mm | 320 mm |
| Brakes - Rear Diameter (in.) | 10.5 inches | 10.9 inches |
| Brakes - Rear Diameter (mm) | 267 mm | 276 mm |
| Brakes - Front | Double disc. ABS. Four-piston calipers. Radially mounted. | Double disc. Floating discs. Four-piston calipers. |
| Brakes - Rear | Single disc. ABS. Two-piston calipers. | Single disc. Floating disc. Two-piston calipers. |
| Rims | - | Cast aluminum wheels |
| Tyres - Front | - | 120/70-17 |
| Tyres - Rear | - | 180/55-17 |
