Engine Type
|
Two cylinder boxer, two-stroke | Two cylinder boxer, two-stroke | Two cylinder boxer, four-stroke | Two cylinder boxer, four-stroke |
|
Displacement (cc)
|
1170.00 cc | - | 1170.00 cc | 1170.0 cc |
|
CO2
|
95.1 CO2 g/km. (CO2 - Carbon dioxide emission) | 95.1 CO2 g/km. (CO2 - Carbon dioxide emission) | 106.7 CO2 g/km. (CO2 - Carbon dioxide emission) ↑ | 106.7 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Wheelbase
|
1,527 mm / 60.1 in. | 1,527 mm / 60.1 in. | 1,527 mm / 60.1 in. | 1527 mm / 60.1 in. ↑ |
|
Brakes - Front
|
Double disc. Floating discs. Four-piston calipers. | Double disc. Floating discs. Four-piston calipers. | Double disc. ABS. Four-piston calipers. | Double disc. ABS. Four-piston calipers. |
|
Fuel Capacity
|
18.00 litres / 4.76 gallons | 18.00 litres / 4.76 gallons | 18.00 litres / 4.76 gallons | 18.00 litres / 4.76 US gallons |
|
Brakes - Rear
|
Single disc. Floating disc. Two-piston calipers. | Single disc. Floating disc. Two-piston calipers. | Single disc. ABS. Floating disc. Two-piston calipers. | Single disc. ABS. Floating disc. Two-piston calipers. |
|
Suspension - Front
|
Telescopic Upside-Down fork | Telescopic Upside-Down fork | Upside-down telescopic fork, diameter 45 mm, travel 140 mm, silver-anodized | Upside-down telescopic fork, diameter 45 mm, travel 140 mm, silver-anodized |
|
Suspension - Rear
|
Cast aluminium single-sided swing arm with BMW Motorrad Paralever | Cast aluminium single-sided swing arm with BMW Motorrad Paralever | BMW Motorrad EVO Paralever | BMW Motorrad EVO Paralever |
|
Fuel System
|
Injection. Electronic intake pipe injection | Injection. Electronic intake pipe injection | Injection. Digital engine management with electronic fuel injection | Injection. Digital engine management with electronic fuel injection |
|
Colours
|
Blue/grey, grey | Lupin Blue/Light Metallic Grey, Granite Grey Metallic Matte | Light Grey Metallic/Magellan Grey Metallic Matt | Light Grey Metallic/Magellan Grey Metallic Matt |
|
Clutch
|
Oil lubricated clutch, hydraulically operated | Oil lubricated clutch, hydraulically operated | Wet eight-disc clutch with anti-hopping function, hyrdaulically operated | Wet eight-disc clutch with anti-hopping function, hyrdaulically operated |
|
Final Drive
|
Shaft drive (cardan) | Shaft drive (cardan) | Shaft drive (cardan) | Shaft drive (cardan) (final drive) |
|
Height
|
1,273 mm / 50.1 in. | 1,273 mm / 50.1 in. | 1,273 mm / 50.1 in. | 1250 mm / 49.2 in. ↑ |
|
Rims
|
- | Cast aluminum wheels | Cast aluminium | Cast aluminium |
|
Length
|
2,202 mm / 86.7 in. | 2,202 mm / 86.7 in. | 2,202 mm / 86.7 in. | 2202 mm / 86.7 in. ↑ |
|
Emissions
|
- | - | Closed-?loop 3-?way catalytic converter, emission standard EU-?4 | Closed-loop 3-way catalytic converter, emission standard EU-4 |
|
Tyres - Front
|
120/70-17 | 120/70-17 | 120/70-ZR17 | 120/70-ZR17 |
|
Engine Lubrication
|
Dry sump | Wet sump | Wet sump | Wet sump |
|
Tyres - Rear
|
180/55-17 | 180/55-17 | 180/55-ZR17 | - |
|
Rake
|
27.7° | 27.7° | 27.7° | 27.7° |
|
Fuel Consumption
|
4.10 litres/100 km (24.4 km/l or 57.37 mpg) | 4.10 litres/100 km (24.4 km/l or 57.37 mpg) | 4.60 litres/100 km (21.7 km/l or 51.13 mpg) ↑ | 4.60 litres/100 km (21.7 km/l or 51.13 mpg) |
|
Fuel Reserve
|
3.00 litres / 0.79 gallons | 3.00 litres / 0.79 gallons | 3.00 litres / 0.79 gallons | 3.00 litres / 0.79 US gallons |
|
Max Torque
|
125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions | 125.0 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions" |
