| General |
| Comments | - | Ride by Wire. 5 ride modes. Traction control. Cruise control. Windscreen. Heated grips. Heated seats. Phone connectivity. |
| Colours | Blue, grey, white | Snowdonia White, Snowdonia White, Lucerne Blue |
| Warranty | - | 3 years, unlimited mileage warranty |
| Dimensions |
| Seat Height (in.) | 31.1 inches | 33.5 inches |
| Length (mm) | 2,165 mm | 2248 mm |
| Length (in.) | 85.2 inches | 88.5 inches |
| Height (mm) | 1,300 mm | 1470 mm |
| Height (in.) | 51.2 inches | 57.9 inches |
| Wheelbase (in.) | 59.6 inches | 61.4 inches |
| Wheelbase (mm) | 1,515 mm | 1560 mm |
| Width (in.) | 35.7 inches | 33.4 inches |
| Width (mm) | 906 mm | 849 mm |
| Seat Heigth -Alternate (in.) | - | 34.5 inches |
| Seat Heigth -Alternate (mm) | - | 877 mm |
| Seat Height (mm) | 790 mm | 850 mm |
| Seat Height | 790 mm / 31.1 in. | 850 mm / 33.5 in. |
| Wheelbase | 1,515 mm / 59.6 in. | 1560 mm / 61.4 in. |
| Height | 1,300 mm / 51.2 in. | 1470 mm / 57.9 in. |
| Length | 2,165 mm / 85.2 in. | 2248 mm / 88.5 in. |
| Width | 906 mm / 35.7 in. | 849 mm / 33.4 in. |
| Weights & Capacities |
| Fuel Capacity (gal.) | 4.76 gallons | 7.90 US gallons |
| Wet Weight (kg) | 231.0 kg | 254.9 kg |
| Wet Weight (lbs.) | 509.3 pounds | 562.0 pounds |
| Oil Capacity (Quarts) | - | 4.23 US quarts |
| Fuel Capacity (l) | 18.00 litres | 29.90 litres |
| Oil Capacity (l) | - | 4.00 litres |
| Fuel Capacity | 18.00 litres / 4.76 gallons | 29.90 litres / 7.90 US gallons |
| Wet Weight | 231.0 kg / 509.3 lbs | 254.9 kg / 562.0 lbs |
| Performance |
| Max Torque | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions | 130.0 Nm (13.3 kgf-m or 95.9 ft.lbs) @ 7000 Revolutions" |
| Engine |
| Engine Type | Two cylinder boxer, four-stroke | In-line three, four-stroke |
| Fuel Control | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel Reserve (gal.) | 0.79 gallons | - |
| Fuel Reserve (l) | 3.00 litres | - |
| Displacement (cc) | 1170.00 cc | 1160.0 cc |
| CO2 | 90.5 CO2 g/km. (CO2 - Carbon dioxide emission) | 113.7 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Bore x Stroke (mm) | 101.0 x 73.0 mm | 89.9 x 60.5 mm |
| Bore x Stroke (in,) | 4.0 x 2.9 inches | 3.5 x 2.4 inches |
| Displacement (ci) | 71.39 cubic inches | 70.78 cubic inches |
| Fuel System | Injection. Electronic intake pipe injection/BMS-K+ digital enfinemanagement with overrun fuel cut-off, twin spark ignition | Injection. Multipoint sequential electronic fuel injection with electronic throttle control |
| Compression Ratio | 12.0:1 | 13.2:1 |
| Emissions | Closed-loop 3-way catalytic converter, emission standard EU-3 | - |
| Engine Lubrication | Dry sump | - |
| Exhaust | - | Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer |
| Fuel Consumption | 3.90 litres/100 km (25.6 km/l or 60.31 mpg) | 4.90 litres/100 km (20.4 km/l or 48.00 mpg) |
| Fuel Reserve | 3.00 litres / 0.79 gallons | - |
| Starter | Electric | Electric |
| Valve System | 4 | 4 |
| Drivetrain |
| Clutch | Single dry plate clutch, hydraulically operated | Hydraulic, Wet, multi-plate, slip and assist |
| Final Drive | Shaft drive (cardan) | Shaft drive (cardan) (final drive) |
| Gearbox | 6-speed | 6-speed |
| Chassis |
| Wheel Travel - Rear (mm) | 140 mm | 200 mm |
| Wheel Travel - Rear (in.) | 5.5 inches | 7.9 inches |
| Trail (in.) | 4.9 inches | 4.7 inches |
| Trail (mm) | 126 mm | 120 mm |
| Wheel Travel - Front (in.) | 5.5 inches | 7.9 inches |
| Wheel Travel - Front (mm) | 140 mm | 200 mm |
| Frame Type | Two section frame consisting of front and rear sections, load bearing engine-gearbox unit | Tubular steel frame, with forged aluminium outriggers. Fabricated, bolt-on aluminium rear subframe. |
| Suspension - Front | Telescopic Upside-Down fork; stanchion diameter 45 mm | Showa 49mm, semi-active damping USD forks |
| Suspension - Rear | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel | Showa semi-active damping monoshock, with automatic electronic preload adjustment |
| Rake | 27.7° | 24.0° |
| Trail | 126 mm / 4.9 in. | 120 mm / 4.7 in. |
| Wheel Travel - Front | 140 mm / 5.5 in. | 200 mm / 7.9 in. |
| Wheel Travel - Rear | 140 mm / 5.5 in. | 200 mm / 7.9 in. |
| Electrical Systems |
| Instrumentation | - | Full-colour 7” TFT screen |
| Lighting system | - | All LED lighting |
| Wheels & Brakes |
| Brakes - Front Diameter (in.) | 12.6 inches | - |
| Brakes - Rear Diameter (in.) | 10.4 inches | - |
| Brakes - Rear Diameter (mm) | 265 mm | - |
| Brakes - Front Diameter (mm) | 320 mm | - |
| Brakes - Front | Double disc. ABS. Floating discs. Four-piston calipers. | Double disc. Brembo M4.30 Stylema monoblock radial calipers, ABS. |
| Brakes - Rear | Single disc. ABS. Floating disc. Two-piston calipers. | Single disc. Brembo single piston caliper, ABS. |
| Rims | Cast aluminium | Cast aluminium alloy. Metzeler Tourance tires. |
| Tyres - Front | 120/70-ZR17 | 120/70-R19 |
| Tyres - Rear | 180/55-ZR17 | - |
