Yamaha Tracer 900GT Specs
2019
• 1 variants
First introduced in 2019, the Yamaha Tracer 900GT is a supermotard that has seen 1 variant. The engine is a four stroke, transverse three cylinder, DOHC, 12 Valve at 847.0 cc. Peak output is rated at 114 hp. It delivers 87.5 Nm of torque.
About the Yamaha Tracer 900GT
Yamaha introduced the Tracer 900GT as part of their Super motard range, with production running from 2018 to 2020. This technical reference page documents the full specification sheet for the Yamaha Tracer 900GT, including engine displacement, power and torque figures, frame and suspension geometry, braking systems, and overall dimensions. Select a model year above to view year-specific technical data. Specifications are compiled from official manufacturer sources.
Yamaha Tracer 900GT by Year
Spec Evolution
How key specs changed across production years.
No numeric spec data available for this model.
|
Specification
|
2018
|
2019
|
2020
|
|
Oil Capacity (Quarts)
|
0.22 quarts | 3.59 US quarts ↑ | 3.59 US quarts |
|
Displacement (cc)
|
847.00 cc | - | 847.0 cc |
|
Frame Type
|
Diamond | Diamond frame | Diamond |
|
Wheelbase
|
1,440 mm / 56.7 in. | 1440 mm / 56.7 in ↑ | 1501 mm / 59.1 in. ↑ |
|
Brakes - Front
|
Double disc. Hydraulic. ABS. | 2x 298mm discs, ABS | Double disc. Hydraulic. ABS. |
|
Fuel Capacity
|
18.17 litres / 4.80 gallons | 18 Litres / 4.8 US gal ↓ | 18.17 litres / 4.80 US gallons ↑ |
|
Brakes - Rear
|
Single disc. Hydraulic. ABS. | Single 245mm disc, ABS | Single disc. Hydraulic. ABS. |
|
Suspension - Front
|
41mm inverted fork, fully adjustable | 41mm fork, adjustable preload and rebound damping | 41mm inverted fork, fully adjustable |
|
Suspension - Rear
|
Single shock, adjustable preload and rebound damping | Rear single shock, adjustable preload and rebound damping | Single shock, adjustable preload and rebound damping |
|
Colours
|
Raven | Raven | Matte Raven Black/Reddish Copper |
|
Clutch
|
Multiplate assist and slipper clutch | Wet, multiple-disc | Multiplate assist and slipper clutch |
|
Final Drive
|
Chain | O-ring chain | Chain (final drive) |
|
Height
|
- | 1338 mm to 1375 mm / 52.9 in to 54.1 in | 1430 mm / 56.3 in. ↑ |
|
Length
|
- | 2160 mm / 85.0 in | 2159 mm / 85.0 in. ↓ |
|
Wet Weight
|
- | N/A | 215.0 kg / 474.0 lbs |
|
Compression Ratio
|
11.5:1 | 11.5 :1 | 11.5:1 |
|
Tyres - Front
|
120/70-ZR17 | 120/70-ZR17M/C | 120/70-ZR17 |
|
Width
|
- | 850 mm / 37.4 in | 851 mm / 33.5 in. ↑ |
|
Tyres - Rear
|
180/55-ZR17 | 180/55-ZR17M/C | - |
|
Rake
|
24.0° | 24° | 24.0° |
|
Trail
|
100 mm / 3.9 in. | 100 mm / 3.9 in | 100 mm / 3.9 in. |
|
Wheel Travel - Front
|
137 mm / 5.4 in. | 137 mm / 5.4 in | 137 mm / 5.4 in. |
|
Wheel Travel - Rear
|
130 mm / 5.1 in. | 130 mm / 5.1 in | 130 mm / 5.1 in. |
|
Ignition
|
TCI | Transistorized coil ignition | TCI |
|
Max Torque
|
87.50 Nm (8.9 kgf-m or 64.5 ft.lbs) @ 8900 Revolutions | 87.5 Nm / 8.9 kgf-m @ 8,500 rpm | 87.5 Nm (8.9 kgf-m or 64.5 ft.lbs) @ 8900 Revolutions |
