2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 Specifications

Name: 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900
Brand: Yamaha

Sport touring • Specs last verified 13 July 2026

No images available

Tap to enlarge

2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 Overview

Yamaha FJ-09 / MT-09 Tracer / Tracer 900 is a sport touring motorcycle, displacing 847 cc. Power comes from a Four stroke, transverse three cylinder, DOHC, 12 Valve engine, a compression ratio of 11.5 :1. On the performance side, it delivers 84.6 kW @ 10,000 rpm of peak power and 87.5 Nm @ 8,500 rpm of torque. On the road, the 2016 FJ-09 / MT-09 Tracer / Tracer 900 tips the scales at 207 kg, carries a 18-litre fuel tank, offers a seat height of 845 mm - 860 mm and spans a 1440 mm wheelbase. That's roughly 40.9 kg lighter than the average sport touring motorcycle in our database. The full 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 spec sheet below covers every technical detail, from suspension travel to tyre sizes.

2016 FJ-09 / MT-09 Tracer / Tracer 900 - Pros & Cons

Strengths

Strong power output: With 84.6 kW @ 10,000 rpm and 87.5 Nm @ 8,500 rpm of torque on tap, the FJ-09 / MT-09 Tracer / Tracer 900 is no slouch for its class.
Fuel injection: Fuel injection means consistent cold starts and clean throttle response without the fussiness of a carbureted setup.
Large fuel range: A 18-litre tank means fewer stops on longer rides - a genuine plus for touring or a lengthy daily commute.

Considerations

Tall seat height: At 845 mm - 860 mm, shorter riders will likely be on tiptoes at a standstill - worth sitting on one before you buy.
Chain final drive upkeep: Budget time for routine chain maintenance - it's cheap to replace but needs consistent attention to avoid premature sprocket wear.

Wear Points & Servicing Notes

Cooling system servicing

FJ-09 / MT-09 Tracer / Tracer 900's Liquid cooled setup is low-maintenance provided the coolant interval is kept - old, acidic coolant is the main cause of long-term corrosion in the water passages.

Fuelling & injector care

The fuel injection on the FJ-09 / MT-09 Tracer / Tracer 900 needs little beyond good fuel and periodic use of an injector-cleaner additive - no jetting or float-bowl maintenance to worry about.

Brake disc and pad wear

Braking up front comes from 2x 298mm discs - solid stopping power, with disc and pad wear best checked on the same schedule as tyre changes.

Suspension condition on used examples

The FJ-09 / MT-09 Tracer / Tracer 900's suspension runs 41mm fork; adjustable preload and rebound damping at the front. The rear uses Rear Single shock; adjustable preload and rebound damping. Fork-seal condition and rear linkage play are the two things worth checking before buying used.

Final drive maintenance

The FJ-09 / MT-09 Tracer / Tracer 900 uses chain final drive, which is cheap to replace but needs regular cleaning, lubrication and tension checks to get a full service life out of the sprockets.

Frame & chassis check

Built around a Diamond frame, the FJ-09 / MT-09 Tracer / Tracer 900's chassis is straightforward to inspect: look for corrosion, cracks or repair welds around stress points like the head-stock and swingarm mounts.

FJ-09 / MT-09 Tracer / Tracer 900 - Buying & Maintenance Guide

What to check before buying

Before handing over money for a used 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900, cover the fundamentals: service book and oil change history, chain and sprocket wear, and any sign of oil weeping around the casings. Cold-starting it yourself tells you a lot - a healthy FJ-09 / MT-09 Tracer / Tracer 900 should catch quickly and settle into a smooth idle.

Oil and filter changes

Nothing protects a FJ-09 / MT-09 Tracer / Tracer 900's engine like disciplined oil changes - stay on the manufacturer's schedule (roughly every 6,000 km or annually). Match the viscosity grade to what the owner's manual specifies, not what's cheapest.

Fuel system care

Fuel injection on the FJ-09 / MT-09 Tracer / Tracer 900 needs little attention beyond decent fuel and an occasional system-cleaner additive. Anything left standing for three months or more should have its fuel drained and replaced before it varnishes the injectors.

2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 - Frequently Asked Questions

What engine does the 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 have?

The 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 uses a Four stroke, transverse three cylinder, DOHC, 12 Valve engine with 847 cc of displacement. It is liquid cooled.

How much does the 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 weigh?

The 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 weighs 207 kg. This is the manufacturer's wet figure.

How much power does the 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 make?

The 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 produces 84.6 kW @ 10,000 rpm of power and 87.5 Nm @ 8,500 rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900?

The 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 has a 18-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 300-360 km between stops.

Is the 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 suitable for shorter riders?

The 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 has a seat height of 845 mm - 860 mm. This is towards the tall end of the spectrum and will require most riders under 175 cm to tiptoe at stops.

What brakes does the 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 have?

The 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 uses 2x 298mm discs at the front and Single 245mm disc at the rear.

What tyre sizes does the 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 use?

The 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 runs 120/70-ZR17M/C front and 180/55-ZR17M/C rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 have?

The 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 is fitted with a 6 Speed transmission.

Key Specifications

Engine

Four stroke, transverse three cylinder, DOHC, 12 Valve

Power

84.6 kW / 114 hp @ 10,000 rpm

Torque

87.5 Nm / 8.9 kgf-m @ 8,500 rpm

Top Speed

Not published by manufacturer

Weight

207 kg / 462 lbs

Fuel Capacity

18 Litres / 4.8 US gal

Full 2016 Yamaha FJ-09 / MT-09 Tracer / Tracer 900 Specifications

Year 2015 - 16

Make Model Yamaha FJ-09 / MT-09 Tracer / Tracer 900

Seat Height 845 mm - 860 mm / 33.3 in - 33.9 in

Wheelbase 1440 mm / 56.7 in

Ground Clearance 135 mm / 5.3 in

Height 1338 mm to 1375 mm / 52.9 in to 54.1 in

Length 2160 mm / 85.0 in

Width 850 mm / 37.4 in

Fuel Capacity 18 Litres / 4.8 US gal

Wet Weight 207 kg / 462 lbs

Max Power 84.6 kW / 114 hp @ 10,000 rpm

Max Torque 87.5 Nm / 8.9 kgf-m @ 8,500 rpm

Displacement 847 cc / 51.6 cu-in

Engine Detail Four stroke, transverse three cylinder, DOHC, 12 Valve

Bore x Stroke 78 x 59.1 mm

Compression Ratio 11.5 :1

Cooling System Liquid cooled

Fuel Induction Electronic Fuel Injection

Ignition Transistorized coil ignition

Lubrication Wet sump

Starter Electric

Clutch Wet, multiple-disc

Final Drive Chain

Transmission / Drive 6 Speed

Frame Type Diamond frame

Suspension - Front 41mm fork; adjustable preload and rebound damping

Suspension - Rear Rear Single shock; adjustable preload and rebound damping

Rake 24°

Trail 100 mm / 3.9 in

Wheel Travel - Front 137 mm / 5.4 in

Wheel Travel - Rear 130 mm / 5.1 in

Brakes - Front 2x 298mm discs

Brakes - Rear Single 245mm disc

Notes The Yamaha Tracer 900, in USA known as the FJ-09 until 2017, then known as the Tracer 900, while in Japan, South America, Australia, and New Zealand it is known as the MT-09 Tracer.)

Tyres - Front 120/70-ZR17M/C

Tyres - Rear 180/55-ZR17M/C

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
