Key Specifications
Engine
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Power
132.1 kW / 181.5 hp @ 9500 rpm
Torque
146 Nm / 14.9 kgf-m / 108 lb-ft @ 7200 rpm
Top Speed
252.9 km/h / 157.1 mph
Weight
235.0 kg / 518.1 lbs
Fuel Capacity
16.5 Litres / 4.4 US gal / 3.6 Imp gal
Advertisement
Full 2009 Suzuki GSX 1300 B-King Specifications
Year
2009
Year
2009
Make Model
Suzuki GSX 1300 B-King
Make Model
Suzuki GSX 1300 B-King
Seat Height
805 mm / 31.7 in
Seat Height
805 mm / 31.7 in
Wheelbase
1525 mm / 60.0 in
Wheelbase
1525 mm / 60.0 in
Ground Clearance
120 mm / 4.7 in
Ground Clearance
120 mm / 4.7 in
Length
2245 mm / 88.4 in
Length
2245 mm / 88.4 in
Width
800 mm / 31.5 in
Width
800 mm / 31.5 in
Dry Weight
235.0 kg / 518.1 lbs
Dry Weight
235.0 kg / 518.1 lbs
Fuel Capacity
16.5 Litres / 4.4 US gal / 3.6 Imp gal
Fuel Capacity
16.5 Litres / 4.4 US gal / 3.6 Imp gal
Displacement
1340 cc / 81.8 cu-in
Displacement
1340 cc / 81.8 cu-in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Bore x Stroke
81 x 65 mm
Bore x Stroke
81 x 65 mm
Compression Ratio
12.5:1
Compression Ratio
12.5:1
Cooling System
Liquid cooled
Cooling System
Liquid cooled
Exhaust
4-into-2-into-1 exhaust system with a large capacity catalyzer, oxygen sensors and an oval cross section canister with dual openings that meets Euro 3 and Tier 2 regulation
Exhaust
4-into-2-into-1 exhaust system with a large capacity catalyzer, oxygen sensors and an oval cross section canister with dual openings that meets Euro 3 and Tier 2 regulation
Fuel Consumption
6.2 L/100 km / 16.1 km/l / 38 US mpg / 45 Imp mpg
Fuel Consumption
6.2 L/100 km / 16.1 km/l / 38 US mpg / 45 Imp mpg
Fuel Induction
Fuel injection . Suzuki SDTV fuel injection system with dual injectors per cylinder and ram air intake with large volume airbox
Fuel Induction
Fuel injection . Suzuki SDTV fuel injection system with dual injectors per cylinder and ram air intake with large volume airbox
Ignition
Electronic
Ignition
Electronic
Lubrication
Wet sump
Lubrication
Wet sump
Starter
Electric
Starter
Electric
Clutch
Wet, multiple discs, hydraulic operated
Clutch
Wet, multiple discs, hydraulic operated
Final Drive
Chain, RK GB50GSV Z4, 118 links
Final Drive
Chain, RK GB50GSV Z4, 118 links
Transmission / Drive
6 Speed
Transmission / Drive
6 Speed
Frame Type
Twin-spar cast aluminum alloy
Frame Type
Twin-spar cast aluminum alloy
Suspension - Front
Inverted telescopic coil springs, spring preload, rebound and compression damping fully adjustable.
Suspension - Front
Inverted telescopic coil springs, spring preload, rebound and compression damping fully adjustable.
Suspension - Rear
Link type, oil damped, coil springs, spring preload, rebound and compression damping fully adjustable.
Suspension - Rear
Link type, oil damped, coil springs, spring preload, rebound and compression damping fully adjustable.
Rake
25.7°
Rake
25.7°
Trail
107 mm / 4.2 in
Trail
107 mm / 4.2 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
137 mm / 5.4 in
Wheel Travel - Rear
137 mm / 5.4 in
Brakes - Front
2 x 310 mm Discs, 4 piston calipers
Brakes - Front
2 x 310 mm Discs, 4 piston calipers
Brakes - Rear
Single 260m disc, 1 piston caliper
Brakes - Rear
Single 260m disc, 1 piston caliper
Tyres - Front
120/70 ZR17
Tyres - Front
120/70 ZR17
Tyres - Rear
200/50 ZR17
Tyres - Rear
200/50 ZR17
Wheels - Front
3.50 x 17
Wheels - Front
3.50 x 17
Wheels - Rear
6.00 x 17
Wheels - Rear
6.00 x 17
