Key Specifications
Engine
Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Power
78.3 kW / 105 hp @ 8000 rpm
Torque
100 Nm / 73.7 lb-ft @ 6500 rpm
Fuel Capacity
20 Litres / 5.3 US gal
Full 2023 KTM 890 Adventure Specifications
Year
2023
Make Model
KTM 890 Adventure
Seat Height
860 mm / 33.8 in
Wheelbase
1529 mm / 60.2 in
Ground Clearance
233 mm / 9.17 in
Wet Weight (kg)
210
Fuel Capacity
20 Litres / 5.3 US gal
Wet Weight
210 kg / 463 lbs
Displacement
889 cc / 54.3 cu-in
Engine Detail
Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Bore x Stroke
90.7 x 68.8 mm
Compression Ratio
13.5:1
Cooling System
Liquid cooled with water/oil heat exchanger
Emissions
Euro 5
Engine Management
Bosch EMS with RBW
Exhaust
Stainless-steel
Fuel Induction
DKK Dell'Orto with 46mm throttle body
Lubrication
Pressure lubrication with 2 oil pumps
Starter
Electric
Clutch
PASC antihopping clutch, mechanically operated
Final Drive
Chain 520 X-Ring
Transmission / Drive
6 Speed
Frame Type
Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Suspension - Front
48mm WP APEX 43 forks
Suspension - Rear
WP APEX - Monoshock
Rake
26.3°
Steering Head Angle
64.1°
Wheel Travel - Front
200 mm / 7.87 in
Wheel Travel - Rear
200 mm / 7.87 in
Brakes - Front
2x 320mm discs with 4-piston radially mounted calipers
Brakes - Rear
Single 260mm disc 2-piston floating caliper
ABS
Bosch 9.1 MP incl. Cornering-ABS and offroad mode, disengageable
Tyres - Front
90/90 x 21 Continental Twinduro TKC 80
Tyres - Rear
150/70 x 18 Continental Twinduro TKC 80
Wheels
Wire-spoked
Wheels - Front
2.50 x 21
Wheels - Rear
4.50 x 18
