Key Specifications
Fuel Capacity
23.00 litres
Advertisement
Full 2018 KTM 1090 Adventure Specifications
Comments
Small windscreen. Ride-by-wire system. Traction control with different modes.
Colours
Orange/black
Wheelbase (mm)
1,560 mm
Wheelbase (in.)
61.4 inches
Seat Height (mm)
850 mm
Seat Height (in.)
33.5 inches
Ground Clearance (mm)
220 mm
Ground Clearance (in.)
8.7 inches
Fuel Capacity (l)
23.00 litres
Fuel Capacity (gal.)
6.08 gallons
Dry Weight (lbs.)
451.9 pounds
Dry Weight (kg)
205
Engine Type
Twin, four-stroke
Displacement (ci)
64.07 cubic inches
Displacement (cc)
1050.00 cc
Bore x Stroke (mm)
103.0 x 63.0 mm
Bore x Stroke (in,)
4.1 x 2.5 inches
Engine Detail
75° V arrangement
Fuel System
Injection
Engine Lubrication
Forced oil lubrication with 3 oil pump
Ignition
Keihin EMS with RBW, twin ignition
Starter
Electric
Clutch
PASC slipper clutch, hydraulically actuated
Final Drive
Chain
Gearbox
6-speed
Primary Drive
5/8 x 5/16 X Ring. Primary drive: 40:76.
Wheel Travel - Front (in.)
7.3 inches
Wheel Travel - Front (mm)
185 mm
Wheel Travel - Rear (in.)
7.5 inches
Wheel Travel - Rear (mm)
190 mm
Frame Type
Chromium-Molybdenum steel trellis frame, powder coated
Suspension - Front
WP upside-down ? 43 mm
Suspension - Rear
WP monoshock
Rake
26.0°
Brakes - Front Diameter (in.)
12.6 inches
Brakes - Front Diameter (mm)
320 mm
Brakes - Rear Diameter (in.)
10.5 inches
Brakes - Rear Diameter (mm)
267 mm
Brakes - Front
Double disc. ABS. Four-piston calipers. Radially mounted. Brembo
Brakes - Rear
Single disc. ABS. Two-piston calipers. Brembo.
Rims
Metzeler Tourance Next tires
Tyres - Front
110/80-R19
Tyres - Rear
150/90-R17
