Key Specifications
Engine
Four stroke, 60° V-Twin, DOHC, 4-valves per cylinder
Power
100 hp / 74.5 kW @ 8100 rpm
Torque
72.2 ft-lbs / 97.7 Nm @ 5900 rpm
Fuel Capacity
12.5 Litres / 3.3 US gal
Full 2018 Indian Scout Specifications
Year
2017 - 18
Make Model
Indian Scout
Seat Height
673 mm / 26.5 in Laden 643 mm/ 25.3 in
Wheelbase
1562 mm / 61.5 in
Ground Clearance
135 mm / 5.3 in
Height
1207 mm / 47.5 in
Length
2311 mm / 91 in
Width
880 mm / 34.6 in
Wet Weight (kg)
253
Dry Weight (kg)
244
Dry Weight
244 kg / 538 lbs
Fuel Capacity
12.5 Litres / 3.3 US gal
Maximum Load / GVWR
449 kg / 988 lbs
Oil Capacity
4.73 Litres
Wet Weight
253 kg / 558 lbs
Displacement
1133 cc / 69 cu in
Engine Detail
Four stroke, 60° V-Twin, DOHC, 4-valves per cylinder
Bore x Stroke
99 x 73.6mm / 3.898 x 2.898 in
Compression Ratio
10.7:1
Cooling System
Liquid cooled
Engine Oil Specification
SAE 15W60
Exhaust
Split dual exhaust with crossover, exhaust control two O2 sensors, one each bank, single three-way catalyst in each muffler
Fuel Induction
Electronic fuel injection, closed loop, 60 mm bore
Lubrication
Semi-dry sump
Starter
Electric
Battery Capacity
12 volts / 12 amp/hour, 210 CCA, maintenance free AGM
Clutch
Wet, multi-plate
Final Drive
Belt drive, 141 tooth
Final Drive Ratio
2.357:1
Gear Ratios
1st 10.782:1 2nd 7.328:1 3rd 5.841:1 4th 4.957:1 5th 4.380:1 6th 4.034:1
Primary Drive
Gear drive wet clutch
Transmission / Drive
6 Speed sliding-mesh/foot shift
Suspension - Front
41 mm Telescopic fork
Suspension - Rear
Dual shocks
Rake
29°
Trail
119.9 mm / 4.7 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
76 mm / 3.0 in
Charging System
35 amp max output
Brakes - Front
Single 298 mm rotor with 2 piston caliper
Brakes - Rear
Single 298 mm rotor with 1 piston caliper
Tyres - Front
130/90-16 72H
Tyres - Rear
150/80-16 71H
Wheels - Front
Cast 16" x 3.5"
Wheels - Rear
Cast 16" x 3.5"
