Key Specifications
Engine
Single cylinder, four-stroke
Weight
109.2 kg / 240.7 lbs
Fuel Capacity
8.50 litres
Full 2019 Husqvarna FE 350 Specifications
Year
2018 - 19
Colours
White/blue/yellow
Colours
White/blue/yellow
Make Model
Husqvarna FE 350
Wheelbase (mm)
1482 mm
Wheelbase (in.)
58.3 inches
Seat Height (mm)
970 mm
Seat Height (in.)
38.2 inches
Ground Clearance (mm)
345 mm
Ground Clearance (in.)
13.6 inches
Wheelbase (mm)
1,482 mm
Wheelbase (in.)
58.3 inches
Seat Height (mm)
970 mm
Seat Height (in.)
38.2 inches
Ground Clearance (mm)
345 mm
Ground Clearance (in.)
13.6 inches
Seat Height
970 mm / 38.2 in
Wheelbase
1482±10 mm / 58.3 in
Ground Clearance
370 mm / 14.5 in
Fuel Capacity (l)
8.50 litres
Fuel Capacity (gal.)
2.25 US gallons
Dry Weight (lbs.)
241.0 pounds
Dry Weight (kg)
109.3
Fuel Capacity (l)
8.50 litres
Fuel Capacity (gal.)
2.25 gallons
Dry Weight (lbs.)
241.0 pounds
Dry Weight (kg)
109.3
Dry Weight
109.2 kg / 240.7 lbs
Fuel Capacity
8.5 Litres / 2.25 US gal
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Bore x Stroke (in,)
3.5 x 2.3 inches
Bore x Stroke (mm)
88.0 x 57.5 mm
Engine Type
Single cylinder, four-stroke
Displacement (cc)
349.70 cc
Displacement (ci)
21.34 cubic inches
Displacement (ci)
21.34 cubic inches
Engine Type
Single cylinder, four-stroke
Displacement (cc)
349.7 cc
Bore x Stroke (mm)
88.0 x 57.5 mm
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Bore x Stroke (in,)
3.5 x 2.3 inches
Displacement
349.7 cc / 21.3 cu in
Engine Detail
Four stroke, single cylinder, DOHC, 4 valves
Fuel System
Carburettor
Fuel System
Carburettor
Bore x Stroke
88 x 57.5 mm
Compression Ratio
13.5:1
Compression Ratio
11.1:1
Cooling System
Liquid cooling system, continuous circulation of cooling liquid with water pump
Engine Management
Keihin EMS
Fuel Induction
Keihin electronic fuel injection and 42mm throttle body
Ignition
Keihin EMS
Ignition
Keihin EMS
Lubrication
Forced oil lubrication with 2 Eaton pumps
Starter
Electric
Starter
Electric
Valve System
4
Valve System
4
Clutch
Wet, DDS multi-disc clutch, Magura hydraulics
Clutch
Wet, DDS multi-disc clutch, Magura hydraulics
Final Drive
X-Ring Chain
Final Drive
Chain (final drive)
Gearbox
6-speed
Gearbox
6-speed
Primary Drive
5/8 x 1/4
Primary Drive
5/8 x 1/4
Primary Drive Ratios
24:73
Secondary Drive Ratio
14:52 (13:52)
Transmission / Drive
6-speed, claw shifted
Frame Type
25CrMo4 steel central-tube frame
Frame Type
25CrMo4 steel central-tube
Suspension - Front
WP-USD Xplor 48 with preload adjuster
Suspension - Front
48 mm WP-USD Xplor forks with preload adjuster
Suspension - Rear
WP shock absorber with linkage
Suspension - Rear
WP Monoshock with linkage
Rake
26.5°
Rake
26.5°
Steering Head Angle
63.5°
Wheel Travel - Front
300 mm / 11.8 in
Wheel Travel - Rear
330 mm / 13.0 in
Brakes - Rear Diameter (mm)
220 mm
Brakes - Rear Diameter (in.)
8.7 inches
Brakes - Front Diameter (mm)
260 mm
Brakes - Front Diameter (in.)
10.2 inches
Brakes - Front
Single disc. Magura two-piston floating calliper
Brakes - Front
Single 260 mm disk, Magura two-piston floating calliper
Brakes - Rear
Single disc. Magura single-piston floating calliper
Brakes - Rear
Single 220 mm disc, Magura single-piston floating calliper
Tyres - Front
90/90-21
Tyres - Front
90/90-21
Tyres - Rear
140/90-18
