Honda XR 150L Specs
2016 - 2023
• 3 variants
First introduced in 2016, the Honda XR 150L is an enduro motorcycle that has seen 3 variants through 2023. The engine is a four stroke, single cylinder. OHV. 4 valve at 125.00 cc.
About the Honda XR 150L
Documented here are the full technical specifications for the Honda XR 150L, a Enduro / Off-Road motorcycle with a production run from 2014 to 2023. Specification data includes engine type and displacement, maximum power and torque output, transmission details, frame construction, suspension travel front and rear, brake types and rotor dimensions, tyre sizes, and overall weight and dimension figures. Select a year above to view the complete spec sheet for that model year.
Honda XR 150L by Year
Spec Evolution
How key specs changed across production years.
No numeric spec data available for this model.
|
Specification
|
2015
|
2016
|
2017
|
2022
|
2023
|
|
Bore x Stroke (in,)
|
2.1 x 2.3 inches | 2.3 x 2.3 inches ↑ | - | 2.3 x 2.3 inches | 2.3 x 2.3 inches |
|
Bore x Stroke (mm)
|
52.4 x 57.8 mm | 57.3 x 57.8 mm ↑ | - | 57.3 x 57.8 mm | 57.3 x 57.8 mm |
|
Brakes - Front Diameter (in.)
|
9.4 inches | 9.4 inches | - | - | |
|
Brakes - Front Diameter (mm)
|
240 mm | 240 mm | - | - | |
|
Comments
|
Sold in Australia and Asia. | Sold as a farm bike in Australia and Asia. | - | Sold in Australia. | Model id: XR150LP. |
|
Displacement (cc)
|
125.00 cc | 149.00 cc ↑ | - | 149.0 cc | 149.0 cc |
|
Displacement (ci)
|
7.63 cubic inches | 9.09 cubic inches ↑ | - | 9.09 cubic inches | 9.09 cubic inches |
|
Fuel Control
|
Overhead Valves (OHV) | Overhead Valves (OHV) | - | - | Overhead Cams (OHC) |
|
Storage
|
Rear rack | Rear rack | - | - | |
|
Seat Height
|
825 mm / 32.5 in. | 825 mm / 32.5 in. | - | 825 mm / 32.5 in. | 833 mm / 32.8 in. ↑ |
|
Dry Weight
|
129 kg / 284.4 lbs | 130 kg / 286.6 lbs ↑ | - | - | - |
|
Engine Detail
|
- | Four stroke, single cylinder. OHV. 4 valve | Four stroke, single cylinder. OHV. 4 valve | - | |
|
Wheelbase
|
1,450 mm / 57.1 in. | 1360 mm / 53.5 in ↑ | 1360 mm / 53.5 in | 1360 mm / 53.5 in. | 1360 mm / 53.5 in. |
|
Brakes - Front
|
Single disc. Dual-piston calliper | Single 240 mm disc 2 piston caliper | Single 240 mm disc 2 piston caliper | Single disc | Single disc |
|
Fuel Capacity
|
12.00 litres / 3.17 gallons | 12 Litres / 3.1 US gal | 12 Litres / 3.1 US gal | - | 10.60 litres / 2.80 US gallons |
|
Brakes - Rear
|
Expanding brake (drum brake) | 110 drum | 110 drum | Expanding brake (drum brake) | Expanding brake (drum brake) |
|
Suspension - Front
|
Telescopic fork | 31mm Telescopic forks | 31mm Telescopic forks | Telescopic fork | Telescopic fork |
|
Suspension - Rear
|
Swingarm | Swingarm, single shock | Monoshock | Single Shock | Pro-Link® single shock with adjustable spring preload |
|
Fuel System
|
Carburettor. 20mm piston-valve | Carburettor. 20mm piston-valve | - | Carburettor | Carburettor. 22mm piston-valve |
|
Colours
|
Red, black | Red | - | Red/white | Black, whitw |
|
Final Drive
|
Chain | Chain | Chain | Chain (final drive) | Chain (final drive) |
|
Height
|
1,126 mm / 44.3 in. | 1,125 mm / 44.3 in. | 1125 mm / 44.2 in ↑ | 1125 mm / 44.3 in. | 1125 mm / 44.3 in. |
|
Length
|
2,100 mm / 82.7 in. | 2090 mm / 82.2 in ↑ | 2090 mm / 82.2 in | 2090 mm / 82.3 in. | 2090 mm / 82.3 in. |
|
Warranty
|
- | - | - | 12 months | 12 months transferable limited warranty |
|
Compression Ratio
|
9.2:1 | 9.5:1 ↑ | 9.5:1 | 9.5:1 | 9.5:1 |
|
Wet Weight
|
- | 130 kg / 286.6 lb | 130 kg / 286.6 lb | 130.0 kg / 286.6 lbs | 127.9 kg / 282.0 lbs ↓ |
|
Tyres - Front
|
90/90-19 | 90/90-19 | 90/90-19 | 70/100-19 ↓ | 90/90-19 ↑ |
|
Width
|
820 mm / 32.3 in. | 810 mm / 31.9 in. ↓ | 810 mm / 31.8 in | 810 mm / 31.9 in. | 810 mm / 31.9 in. |
|
Tyres - Rear
|
110/90-17 | 110/90-17 | 110/90-17 | - | |
|
Seat
|
Two-person seat | Two-person seat | - | - | |
|
Trail
|
- | - | - | 150 mm / 5.9 in. | 102 mm / 4.0 in. ↓ |
|
Wheel Travel - Front
|
160 mm / 6.3 in. | 160 mm / 6.3 in. | - | 180 mm / 7.1 in. | 180 mm / 7.1 in. |
|
Wheel Travel - Rear
|
151 mm / 5.9 in. | 151 mm / 5.9 in. | 150 mm ↓ | 152 mm / 6.0 in. ↑ | 150 mm / 5.9 in. ↓ |
|
Ignition
|
- | CDI | CDI | - | |
|
Max Torque
|
12.50 Nm (1.3 kgf-m or 9.2 ft.lbs) @ 6000 Revolutions | NA | NA | 12.5 Nm (1.3 kgf-m or 9.2 ft.lbs) @ 6000 Revolutions | 12.5 Nm (1.3 kgf-m or 9.2 ft.lbs) @ 6000 rpm |
|
Starter
|
Electric & kick | Electric & Kick | Electric & Kick | Electric & kick | Electric & kick |
|
Valve System
|
4 | 4 | - | 2 | 2 |
