Key Specifications
Engine
In-line four, four-stroke
Torque
97.00 Nm (9.9 kgf-m or 71.5 ft.lbs) @ 6500
Fuel Capacity
19.00 litres
Full 2012 Honda CBF 1000 Specifications
Comments
French brand.
Colours
Red, silver, black, white
Width (mm)
685 mm
Width (in.)
27.0 inches
Wheelbase (mm)
1,483 mm
Wheelbase (in.)
58.4 inches
Seat Height (mm)
795 mm
Seat Height (in.)
31.3 inches
Length (mm)
2,176 mm
Length (in.)
85.7 inches
Height (mm)
1,175 mm
Height (in.)
46.3 inches
Ground Clearance (mm)
135 mm
Ground Clearance (in.)
5.3 inches
Wet Weight (lbs.)
551.2 pounds
Wet Weight (kg)
250.0 kg
Fuel Capacity (l)
19.00 litres
Fuel Capacity (gal.)
5.02 gallons
Dry Weight (lbs.)
194.0 pounds
Dry Weight (kg)
88
Fuel Reserve (l)
4.00 litres
Fuel Reserve (gal.)
1.06 gallons
Fuel Control
DOHC
Engine Type
In-line four, four-stroke
Displacement (ci)
60.90 cubic inches
Displacement (cc)
998.00 cc
Bore x Stroke (mm)
75.0 x 56.5 mm
Bore x Stroke (in,)
3.0 x 2.2 inches
Fuel System
Injection. PGM-FI
Ignition
Computer-controlled digital transistorised with electronic advance
Starter
Electric
Valve System
4
Final Drive
Chain
Gearbox
6-speed
Primary Drive
#530 O-ring sealed chain
Wheel Travel - Front (in.)
4.7 inches
Wheel Travel - Front (in.)
4.7 inches
Wheel Travel - Front (mm)
120 mm
Wheel Travel - Front (mm)
120 mm
Wheel Travel - Rear (in.)
4.7 inches
Wheel Travel - Rear (mm)
120 mm
Suspension - Front
41 mm cartridge-type telescopic fork
Suspension - Rear
Pro-Link with gas-charges HMAS damper
Seat
Dual
Brakes - Rear Diameter (mm)
240 mm
Brakes - Rear Diameter (in.)
9.4 inches
Brakes - Front Diameter (mm)
296 mm
Brakes - Front Diameter (in.)
11.7 inches
Brakes - Front
Double disc. 2-piston caliper, sintered metal pads and Combined ABS
Brakes - Rear
Single disc. 1-piston caliper, sintered metal pads and Combined ABS
Rims
Hollow-section 6-spoke cast aluminium
Tyres - Front
2.50-12
Tyres - Front
120/70-ZR17
Tyres - Rear
3.00-12
Tyres - Rear
160/60-ZR17
