2023 Harley-Davidson Breakout 117 Overview
The 2023 Harley-Davidson Breakout 117 is a custom / cruiser motorcycle built around 1917.4 cc of displacement. Under the tank sits a V2, four-stroke engine running Double Overhead Cams/Twin Cam (DOHC) valve actuation, a compression ratio of 10.2:1. The bore and stroke measures 103.5 x 114 mm. 2023 Harley-Davidson Breakout 117 delivers 166.8 Nm @ 3500 Revolutions of torque. From a practical standpoint, the 2023 Breakout 117 tips the scales at 309.8 kg, carries a 18.93-litre fuel tank, offers a seat height of 650 mm and spans a 1695 mm wheelbase. That's roughly 9.2 kg heavier than the average custom / cruiser motorcycle in our database. Scroll down for the complete 2023 Harley-Davidson Breakout 117 spec sheet covering every technical detail from suspension travel to tyre sizes.
2023 Breakout 117 - Pros & Cons
Strengths
-
🔧
Fuel injection: The fuel injection system delivers crisp throttle response and reliable cold starts regardless of altitude or temperature.
-
📏
Accessible seat height: At 650 mm, the seat height is approachable for a wide range of rider heights and builds confidence in low-speed manoeuvring.
-
⛽
Large fuel range: The 18.93-litre tank is generously sized, translating to extended range between stops - ideal for touring or longer commutes.
-
⚙️
Low-maintenance final drive: Belt (final drive) final drive means no chain to clean, lube or adjust - meaningfully less routine maintenance than a chain-driven equivalent.
Considerations
-
ℹ️
Age-related wear: As with any used Breakout 117, a thorough pre-purchase inspection covering consumables, service history and tyres is always recommended.
Wear Points & Servicing Notes
Fuelling & injector care
Fuelling comes from fuel injection. Systems like this are largely maintenance-free beyond keeping fuel quality decent and injectors clear - a fuel-system cleaner every service interval is cheap insurance.
Valve clearance checks
Double Overhead Cams/Twin Cam (DOHC) valve actuation on the Breakout 117 means clearances should be checked at the manufacturer's specified interval - they can tighten as mileage accumulates, and a light top-end tick is usually the first sign.
Brake disc and pad wear
The Single disc. ABS. 4-piston front brake gives strong, progressive stopping power. Disc thickness and pad depth are worth checking at every tyre change, since worn pads can score the disc surface.
Suspension condition on used examples
Up front, the Breakout 117 runs Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring and Hidden, free piston, coil-over monoshock; 43mm stroke; toolless hydraulic preload adjustment at the rear. On a used example, check fork seals for weeping oil and test the rear linkage for play - seals are a relatively cheap fix but useful when negotiating price.
Final drive maintenance
Final drive is by belt - lower maintenance than chain with no lubrication needed, but tension and tooth wear should still be checked at service intervals.
Handling the weight at a standstill
At 309.8 kg, the Breakout 117 is a substantial machine - low-speed manoeuvring in car parks takes more physical effort than on a lighter bike, though the weight disappears once rolling.
Breakout 117 - Buying & Maintenance Guide
What to check before buying
When inspecting a used 2023 Harley-Davidson Breakout 117, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained Breakout 117 should fire up cleanly and settle to a smooth idle within a few seconds.
Oil and filter changes
Regular oil changes are the single most important maintenance task on any Breakout 117. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. The sump holds 4.70 litres, so budget for that volume of quality motorcycle-specific engine oil. Always use the correct viscosity grade as specified in the owner's manual.
Fuel system care
The Breakout 117's fuel injection system is durable but benefits from quality fuel and the occasional use of a fuel-system cleaner additive. If the bike has been stored for more than three months, drain and replace the fuel to prevent varnish deposits in the injectors.
Valve clearance service
Check that valve clearances have been adjusted at the correct intervals on any used Breakout 117. A bike with clearances out of spec doesn't always feel obviously wrong - but tight clearances accelerate valve seat wear. Ask for service documentation proving it's been done.
2023 Harley-Davidson Breakout 117 - Frequently Asked Questions
What engine does the 2023 Harley-Davidson Breakout 117 have?
The 2023 Harley-Davidson Breakout 117 uses a V2, four-stroke engine with 1917.4 cc of displacement.
How much does the 2023 Harley-Davidson Breakout 117 weigh?
The 2023 Harley-Davidson Breakout 117 weighs 309.8 kg. This is the manufacturer's wet figure.
How much power does the 2023 Harley-Davidson Breakout 117 make?
The 2023 Harley-Davidson Breakout 117 produces 166.8 Nm @ 3500 Revolutions of torque.
What is the fuel tank capacity of the 2023 Harley-Davidson Breakout 117?
The 2023 Harley-Davidson Breakout 117 has a 18.93-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 315-378 km between stops.
Is the 2023 Harley-Davidson Breakout 117 suitable for shorter riders?
The 2023 Harley-Davidson Breakout 117 has a seat height of 650 mm. This is a comfortable, accessible height for most riders.
What brakes does the 2023 Harley-Davidson Breakout 117 have?
The 2023 Harley-Davidson Breakout 117 uses Single disc. ABS. 4-piston at the front and Single disc. ABS. 2-piston floating at the rear.
What tyre sizes does the 2023 Harley-Davidson Breakout 117 use?
The front tyre size on the 2023 Harley-Davidson Breakout 117 is 130/60-B21.
How much oil does the 2023 Harley-Davidson Breakout 117 take?
The 2023 Harley-Davidson Breakout 117 takes 4.70 litres of engine oil at a full oil and filter change. Always verify against the dipstick or sight glass after filling.
Key Specifications
Power
Not published by manufacturer
Torque
166.8 Nm (17.0 kgf-m or 123.0 ft.lbs) @ 3500 Revolutions
Top Speed
Not published by manufacturer
Weight
309.8 kg / 683.0 lbs
Fuel Capacity
18.93 litres / 5.00 US gallons
Advertisement
Full 2023 Harley-Davidson Breakout 117 Specifications
Comments
Optional traction control.
Colours
Vivid Black, Baja Orange, Black Denim, Performance Orange, Atlas Silver Metallic
Ground Clearance (in.)
4.5 inches
Ground Clearance (mm)
115 mm
Seat Height
650 mm / 25.6 in.
Wheelbase
1695 mm / 66.7 in.
Length
2370 mm / 93.3 in.
Oil Capacity (l)
4.70 litres
Oil Capacity (Quarts)
4.97 US quarts
Dry Weight
296.2 kg / 653.0 lbs
Fuel Capacity
18.93 litres / 5.00 US gallons
Wet Weight
309.8 kg / 683.0 lbs
Bore x Stroke (in,)
4.1 x 4.5 inches
Bore x Stroke (mm)
103.5 x 114.0 mm
CO2
116.0 CO2 g/km. (CO2 - Carbon dioxide emission)
Displacement (cc)
1917.4 cc
Displacement (ci)
117.00 cubic inches
Engine Type
V2, four-stroke
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Engine Detail
Milwaukee-Eight 117 engine
Fuel System
Injection. Electronic Sequential Port Fuel Injection
Compression Ratio
10.2:1
Exhaust
2-into-2 staggered; catalyst in muffler
Fuel Consumption
5.00 litres/100 km (20.0 km/l or 47.04 mpg)
Starter
Electric
Clutch
Multi-plate with diaphragm spring in oil bath
Final Drive
Belt (final drive)
Gearbox
6-speed
Primary Drive
Chain, 34/46 ratio primary drive
Suspension - Front
Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring
Suspension - Rear
Hidden, free piston, coil-over monoshock; 43mm stroke; toolless hydraulic preload adjustment
Rake
34.0°
Trail
145 mm / 5.7 in.
Instrumentation
2.14-inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication
Lighting system
All LED, low beam, high beam and signature position lamp; Incandescent bullets
Brakes - Front
Single disc. ABS. 4-piston
Brakes - Rear
Single disc. ABS. 2-piston floating
Rims
Gloss black, 26-spoke cast aluminum. Michelin Scorcher tires.
Tyres - Front
130/60-B21
