2016 Ducati XDiavel S Specifications

Name: 2016 Ducati XDiavel S
Brand: Ducati

Custom / cruiser • Specs last verified 13 July 2026

No images available

Tap to enlarge

2016 Ducati XDiavel S Overview

The 2016 Ducati XDiavel S is a custom / cruiser motorcycle built around 1262 cc of displacement. Under the tank sits a Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark engine, a compression ratio of 13.0:1. 2016 Ducati XDiavel S delivers 114.7 kW @ 9500 rpm of peak power and 128.9 Nm @ 5000 rpm of torque. From a practical standpoint, the 2016 XDiavel S tips the scales at 247 kg, carries a 18-litre fuel tank, offers a seat height of 755 mm and spans a 1615 mm wheelbase. That's roughly 53.6 kg lighter than the average custom / cruiser motorcycle in our database. Scroll down for the complete 2016 Ducati XDiavel S spec sheet covering every technical detail from suspension travel to tyre sizes.

2016 XDiavel S - Pros & Cons

Strengths

Strong power output: 2016 Ducati XDiavel S makes 114.7 kW @ 9500 rpm with 128.9 Nm @ 5000 rpm of torque - competitive figures for its class.
Fuel injection: The BOSCH fuel injection system system delivers crisp throttle response and reliable cold starts regardless of altitude or temperature.
Accessible seat height: At 755 mm, the seat height is approachable for a wide range of rider heights and builds confidence in low-speed manoeuvring.
Large fuel range: The 18-litre tank is generously sized, translating to extended range between stops - ideal for touring or longer commutes.
Low-maintenance final drive: Belt; Front sprocket Z28; Rear sprocket Z80 final drive means no chain to clean, lube or adjust - meaningfully less routine maintenance than a chain-driven equivalent.

Considerations

Age-related wear: As with any used XDiavel S, a thorough pre-purchase inspection covering consumables, service history and tyres is always recommended.

Wear Points & Servicing Notes

Cooling system servicing

The Liquid cooled system on the XDiavel S needs a coolant change roughly every two years (or per the service schedule) - skipping it lets the coolant turn acidic and corrode the aluminium water passages over time.

Fuelling & injector care

Fuelling comes from BOSCH fuel injection system. Systems like this are largely maintenance-free beyond keeping fuel quality decent and injectors clear - a fuel-system cleaner every service interval is cheap insurance.

Brake disc and pad wear

The 2 x 320 mm (12,60 in) Semifloating discs, Radial Brembo monobloc 4-piston M50 callipers and radial master cylinder. front brake gives strong, progressive stopping power. Disc thickness and pad depth are worth checking at every tyre change, since worn pads can score the disc surface.

Suspension condition on used examples

Up front, the XDiavel S runs Adjustable ø 50 mm and Single shock absorber, Adjustable preload and rebound, Remote reservoir. Single sided swingarm, Cast/trellis frame at the rear. On a used example, check fork seals for weeping oil and test the rear linkage for play - seals are a relatively cheap fix but useful when negotiating price.

Final drive maintenance

Final drive is by belt - lower maintenance than chain with no lubrication needed, but tension and tooth wear should still be checked at service intervals.

Frame & chassis check

The frame is Tubular steel trellis frame - worth a visual check for corrosion or impact damage around the head-stock and swingarm pivot on any used example, since frame damage is far costlier to fix than any service item.

Handling the weight at a standstill

At 247 kg, the XDiavel S is a substantial machine - low-speed manoeuvring in car parks takes more physical effort than on a lighter bike, though the weight disappears once rolling.

XDiavel S - Buying & Maintenance Guide

What to check before buying

When inspecting a used 2016 Ducati XDiavel S, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained XDiavel S should fire up cleanly and settle to a smooth idle within a few seconds.

Oil and filter changes

Regular oil changes are the single most important maintenance task on any XDiavel S. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. Always use the correct viscosity grade as specified in the owner's manual.

Fuel system care

The XDiavel S's fuel injection system is durable but benefits from quality fuel and the occasional use of a fuel-system cleaner additive. If the bike has been stored for more than three months, drain and replace the fuel to prevent varnish deposits in the injectors.

2016 Ducati XDiavel S - Frequently Asked Questions

What engine does the 2016 Ducati XDiavel S have?

The 2016 Ducati XDiavel S uses a Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark engine with 1262 cc of displacement. It is liquid cooled.

How much does the 2016 Ducati XDiavel S weigh?

The 2016 Ducati XDiavel S weighs 247 kg. This is the manufacturer's wet figure.

How much power does the 2016 Ducati XDiavel S make?

The 2016 Ducati XDiavel S produces 114.7 kW @ 9500 rpm of power and 128.9 Nm @ 5000 rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2016 Ducati XDiavel S?

The 2016 Ducati XDiavel S has a 18-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 300-360 km between stops.

Is the 2016 Ducati XDiavel S suitable for shorter riders?

The 2016 Ducati XDiavel S has a seat height of 755 mm. This is a comfortable, accessible height for most riders.

What brakes does the 2016 Ducati XDiavel S have?

The 2016 Ducati XDiavel S uses 2 x 320 mm at the front and 265 mm at the rear.

What tyre sizes does the 2016 Ducati XDiavel S use?

The 2016 Ducati XDiavel S runs Pirelli Diablo Rosso II, 120/70 ZR17 front and Pirelli Diablo Rosso II 240/45 ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2016 Ducati XDiavel S have?

The 2016 Ducati XDiavel S is fitted with a 6-Speed transmission.

Ducati XDiavel S Spec Evolution

The Ducati XDiavel S was produced across 4 model years (2016-2021). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2016	2018	2020	2021
Max Power	114.7 kW / 156 hp @ 9500 rpm	114.7 kW / 156 hp @ 9500 rpm	114.7 kW / 156 hp @ 9500 rpm	118 kW / 160 hp @ 9500 rpm
Wet Weight	247 kg / 545 lbs	247 kg / 545 lbs	247 kg / 545 lbs	249 kg / 549 lbs
Dry Weight	220 kg / 485 lbs	220 kg / 485 lbs	220 kg / 485 lbs	223 kg / 492 lbs
Engine Detail	Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark	Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark	Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark	Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Brakes - Front	2 x 320 mm (12,60 in) Semifloating discs, Radial Brembo monobloc 4-piston M50 callipers and radial master cylinder.	2x 320 mm semifloating discs, radial Brembo monobloc 4-piston M4-32 callipers and radial master cylinder	2x 320 mm semifloating discs, radial Brembo monobloc 4-piston M4-32 callipers and radial master cylinder	2x 320 mm semifloating discs, radial Brembo monobloc 4-piston M50 callipers, PR16/19 radial master cylinder
Brakes - Rear	265 mm (10,43 in) Disc, 2-piston floating calliper	Single 265 mm disc, 2-piston floating calliper	Single 265 mm disc, 2-piston floating calliper	Single 265 mm disc, Brembo 2-piston floating calliper
Suspension - Front	Adjustable ø 50 mm (ø 1,97 in) usd fork with DLC treatment	50mm USD adjustable forks with DLC treatment	50mm USD adjustable forks with DLC treatment	50mm USD adjustable forks with DLC treatment
Suspension - Rear	Single shock absorber, Adjustable preload and rebound, Remote reservoir. Single sided swingarm, Cast/trellis frame	Single shock absorber, adjustable preload and rebound, remote reservoir. Single sided cast/trellis frame swingarm, natural anodized and brushed swingarm	Single shock absorber, adjustable preload and rebound, remote reservoir. Single sided cast/trellis frame swingarm, natural anodized and brushed swingarm	Single shock absorber, adjustable preload and rebound, remote reservoir, Single sided cast/trellis frame swingarm

Key Specifications

Engine

Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark

Power

114.7 kW / 156 hp @ 9500 rpm

Torque

128.9 Nm / 13.1 kgf-m / 95 lb-ft @ 5000 rpm

Top Speed

Not published by manufacturer

Weight

247 kg / 545 lbs

Fuel Capacity

18 Litres / 4.75 US gal

Full 2016 Ducati XDiavel S Specifications

Year 2016

Make Model Ducati XDiavel S

Seat Height 755 mm / 29.7 in

Wheelbase 1615 mm / 63.6 in

Dry Weight 220 kg / 485 lbs

Fuel Capacity 18 Litres / 4.75 US gal

Wet Weight 247 kg / 545 lbs

Max Power 114.7 kW / 156 hp @ 9500 rpm

Max Torque 128.9 Nm / 13.1 kgf-m / 95 lb-ft @ 5000 rpm

Displacement 1262 cc / 77 cu in

Engine Detail Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90° L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark

Bore x Stroke 106 x 71.5 mm

Compression Ratio 13.0:1

Cooling System Liquid cooled

Exhaust Stainless steel exhaust and muffler with dual oval exits, Catalytic converter and 2 lambda probes

Fuel Induction BOSCH fuel injection system, full ride-by-wire system, 56mm oval throttle bodies

Ignition Electronic

Starter Electric

Clutch Slipper and self-servo wet multiplate clutch with hydraulic control

Final Drive Belt; Front sprocket Z28; Rear sprocket Z80

Gear Ratios 1st 37:15 / 2nd 30:17 / 3rd 27:20 / 4th 24:22 / 5th 23:24 / 6th 22:25

Primary Drive Straight cut gears, 1,84:1 ratio

Transmission / Drive 6-Speed

Frame Type Tubular steel trellis frame

Suspension - Front Adjustable ø 50 mm (ø 1,97 in) usd fork with DLC treatment

Suspension - Rear Single shock absorber, Adjustable preload and rebound, Remote reservoir. Single sided swingarm, Cast/trellis frame

Rake 30º

Trail 130 mm / 5.1 in

Wheel Travel - Front 120 mm / 4.7 in

Wheel Travel - Rear 110 mm / 4.33 in

Brakes - Front 2 x 320 mm (12,60 in) Semifloating discs, Radial Brembo monobloc 4-piston M50 callipers and radial master cylinder.

Brakes - Rear 265 mm (10,43 in) Disc, 2-piston floating calliper

ABS BOSCH cornering ABS as standard equipment

Tyres - Front Pirelli Diablo Rosso II, 120/70 ZR17

Tyres - Rear Pirelli Diablo Rosso II 240/45 ZR17

Wheels - Front Light alloy, Cast and machined, 3.5 x 17

Wheels - Rear Light alloy, Cast and machined, 8.00 x 17

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
