Key Specifications
Engine
Four stroke, 90° °L° twin cylinder, SOHC, desmodromic 2 valve per cylinder
Power
55 kW / 75 hp @ 8250 rpm
Torque
68 Nm / 6.9 kgf-m / 50 lb-ft @ 5750 rpm
Fuel Capacity
13.5 Litres / 3.57 US gal / 3.0 Imp gal
Full 2016 Ducati Scrambler Icon Specifications
Year
2015 - 16
Make Model
Ducati Scrambler Icon
Seat Height
790 mm / 31.1 in. low seat 770 mm / 30.3 in. available as accessory
Wheelbase
1455 mm / 57.3 in
Height
1150 mm / 45.3 in
Length
2100 - 2165 mm / 82.7 - 85.2 in
Width
845 mm / 33.3 in
Wet Weight (kg)
186
Dry Weight (kg)
170
Dry Weight
170 kg / 375 lbs
Fuel Capacity
13.5 Litres / 3.57 US gal / 3.0 Imp gal
Wet Weight
186 kg / 410 lbs
Displacement
803 cc /
Engine Detail
Four stroke, 90° °L° twin cylinder, SOHC, desmodromic 2 valve per cylinder
Bore x Stroke
88 x 66 mm
Compression Ratio
11.0:1
Cooling System
Air cooled
Exhaust
Exhaust system with single stainless steel muffler with aluminium exterior cover, catalytic converter and 2 lambda probes
Fuel Induction
Electronic fuel injection, 50 mm throttle bodies
Ignition
Marelli electronic
Starter
Electric
Clutch
APTC wet multiplate with mechanical control
Final Drive
Chain, front spocket 15, rear sprocket 46
Gear Ratios
1st 20/13, 2nd 30/18, 3rd 28/21, 4th 26/23, 5th 22/22, 6th 24/26
Primary Drive
Straight cut gears, ratio 1.85:1
Transmission / Drive
6 Speed
Frame Type
Tubular steel trellis frame
Suspension - Front
Upside down Kayaba 41 mm fork
Suspension - Rear
Kayaba rear shock, pre-load adjustable
Rake
24°
Steering Lock
35°
Trail
112 mm / 4.4 in
Wheel Travel - Front
150 mm / 5.9 in
Wheel Travel - Rear
150 mm / 5.9 in
Equipment / Features
Steel tank with interchangeable aluminium side panels, headlight with glass lens, LED light-guide and interchangeable aluminium cover, LED rear light with diffusive lens, LCD instruments with interchangeable aluminium cover, machine-finished aluminium belt covers, 18"" front, 17"" rear wheels, underseat storage compartment with USB socket Classic equipment Spoked aluminium wheels, front and rear aluminium mudguards, seat with dedicated design, fuel tank with black stripe, dedicated logo, high plate support. Instrumentation LCD Ducati electronics dual-channel ABS Versions Dual seat
Brakes - Front
Single 330 mm disc, 4-piston caliper with ABS as standard equipment
Brakes - Rear
Single 245 mm disc, 1-piston caliper with ABS as standard equipment
Tyres - Front
110/80 R18 Pirelli MT 60 RS
Tyres - Rear
180/55 R17 Pirelli MT 60 RS
Wheels
10-spoke in light alloy
Wheels - Front
3.00 x 18
Wheels - Rear
5.50 x 17
