Key Specifications
Torque
136.00 Nm (13.9 kgf-m or 100.3 ft.lbs) @ 7500 Revolutions">RPM
Fuel Capacity
30.00 litres
Full 2017 Ducati Multistrada 1200 Enduro Specifications
Comments
Windscreen.
Colours
Red
Warranty
2 years unlimited mileage
Wheelbase (mm)
1,594 mm
Wheelbase (in.)
62.8 inches
Storage
Saddle bags.
Seat Height (mm)
870 mm
Seat Height (in.)
34.3 inches
Length (mm)
2,200 mm
Length (in.)
86.6 inches
Wet Weight (lbs.)
560.0 pounds
Wet Weight (kg)
254.0 kg
Fuel Capacity (l)
30.00 litres
Fuel Capacity (gal.)
7.93 gallons
Dry Weight (lbs.)
496.0 pounds
Dry Weight (kg)
225
Fuel Control
Desmodromic valve control
Engine Type
V2, four-stroke
Displacement (ci)
73.13 cubic inches
Bore x Stroke (in,)
4.2 x 2.7 inches
Bore x Stroke (mm)
106.0 x 67.9 mm
Displacement (cc)
1198.40 cc
CO2
129.9 CO2 g/km. (CO2 - Carbon dioxide emission)
Engine Detail
Testastretta DVT
Fuel System
Injection. Bosch electronic fuel injection system, elliptical throttle bodies with Ride-by-Wire, equivalent diameter 56 mm
Compression Ratio
12.5:1
Emissions
Euro 4
Exhaust
Stainless steel muffler with catalytic converter and 2 lambda probes, alluminium tail pipes
Fuel Consumption
5.60 litres/100 km (17.9 km/l or 42.00 mpg)
Ignition
Dual Spark
Starter
Electric
Valve System
4
Clutch
Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Final Drive
Chain
Gearbox
6-speed
Primary Drive
Chain 5.30
Trail (in.)
4.3 inches
Trail (mm)
110 mm
Wheel Travel - Front (in.)
7.9 inches
Wheel Travel - Front (mm)
200 mm
Wheel Travel - Rear (in.)
7.9 inches
Wheel Travel - Rear (mm)
200 mm
Frame Type
Tubular steel Trellis frame
Suspension - Front
Sachs 48 mm fully adjustable usd forks. Electronic compression and rebound damping adjustment with Ducati Skyhook Suspension (DSS)
Suspension - Rear
Fully adjustable Sachs unit. Electronic compression and rebound damping adjustment. Electronic spring pre-load adjustment with Ducati Skyhook Suspension (DSS). Aluminium double-sided swingarm
Rake
25.0°
Instrumentation
LCD display
Brakes - Rear Diameter (mm)
265 mm
Brakes - Rear Diameter (in.)
10.4 inches
Brakes - Front Diameter (mm)
320 mm
Brakes - Front Diameter (in.)
12.6 inches
Brakes - Front
Double disc. ABS. Bremo. Floating discs. Four-piston calipers. Radially mounted.
Brakes - Rear
Single disc. ABS. bremo Two-piston calipers.
Rims
Y-shaped 3-spoke light alloy. Pirelli Scorpion Trail II tyres.
Tyres - Front
120/70-ZR19
Tyres - Rear
170/60-ZR17
