Ducati Diavel Specs

2011 - 2018 • 3 variants

The Ducati Diavel is a cruiser produced from 2011 to 2018 across 3 variants. It is powered by a four stroke, 90° °l° twin cylinder, dohc, desmodromic 4 valves per cylinder.. Peak power output is 162 hp. Peak torque is 127.5 Nm.

About the Ducati Diavel

Documented here are the full technical specifications for the Ducati Diavel, a Custom / cruiser motorcycle with a production run from 2011 to 2018. Specification data includes engine type and displacement, maximum power and torque output, transmission details, frame construction, suspension travel front and rear, brake types and rotor dimensions, tyre sizes, and overall weight and dimension figures. Select a year above to view the complete spec sheet for that model year.

AdSense - 728Ã90

Ducati Diavel by Year

2018 Ducati Diavel View specs →

2012 Ducati Diavel View specs →

2011 Ducati Diavel View specs →

Spec Evolution

How key specs changed across production years.

Specification	2011	2012	2013	2014	2016	2018
Seat Height	770 mm / 30.3in	770 mm / 30.3in	770 mm / 30.3in	770 mm / 30.3in	770 mm / 30.3in	770 mm / 30.3in
Displacement	1198.4 cc / 73.1 cu in	1198.4 cc / 73.1 cu in	-	1198.4 cc / 73.1 cu in	1198.4 cc / 73.1 cu-in	1198.4 cc / 73.1 cu-in
Dry Weight	210 Kg / 463 lbs	210 Kg / 463 lbs	210 Kg / 463 lbs	210 Kg / 463 lbs	210 kg / 463 lbs	210 Kg / 463 lbs
Engine Detail	Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valves per cylinder.	Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valves per cylinder.	Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valves per cylinder.	Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valves per cylinder.	Four stroke, 90°°L°twin cylinder, DOHC, desmodromic 4 valve per cylinder.	Four stroke, 90Â° â€œLâ€ twin cylinder, DOHC, desmodromic 4 valve per cylinder.
Brakes - Front	2 x 320 mm Semi-floating discs, radially mounted Monobloc Brembo calipers, 4-piston with ABS	2 x 320 mm Semi-floating discs, radially mounted Monobloc Brembo calipers, 4-piston with ABS	2 x 320 mm Semi-floating discs, radially mounted Monobloc Brembo calipers, 4-piston with ABS	2 x 320 mm Semi-floating discs, radially mounted Monobloc Brembo calipers, 4-piston with ABS	2 x 320mm semi-floating discs, radially mounted Monobloc Brembo callipers, 4-piston with ABS	2 x 320mm semi-floating discs, radially mounted Monobloc Brembo callipers, 4-piston with ABS
Brakes - Rear	Single 265 mm disc, 2-piston floating caliper with ABS	Single 265 mm disc, 2-piston floating caliper with ABS	Single 265 mm disc, 2-piston floating caliper with ABS	Single 265 mm disc, 2-piston floating caliper with ABS	Single 265mm disc, 2-piston floating calliper with ABS	Single 265mm disc, 2-piston floating calliper with ABS
Fuel Capacity	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 5.3 US gal	-
Suspension - Front	Marzocchi 50mm fully adjustable USD forks	Marzocchi 50mm fully adjustable USD forks	Marzocchi 50mm fully adjustable USD forks	Marzocchi 50mm fully adjustable USD forks	Marzocchi 50mm fully adjustable usd forks,	Marzocchi 50mm fully adjustable USD forks,
Bore x Stroke	106 x 67.9 mm	106 x 67.9 mm	106 x 67.9 mm	106 x 67.9 mm	106 x 67.9mm	106 x 67.9mm
Height	1192 mm / 46.9 in	1192 mm / 46.9 in	1192 mm / 46.9 in	1192 mm / 46.9 in	1192 mm	1192 mm / 46.9 in
Length	2235 mm / 87.9 in	2235 mm / 87.9 in	2235 mm / 87.9 in	2235 mm / 87.9 in	860 mm / 33.9 in ↓	2235 mm / 87.9 in ↑
Compression Ratio	11.5:1	11.5:1	11.5:1	11.5:1	12.5:1 ↑	11.5:1 ↓
Wet Weight	239 kg / 527lbs	239 kg / 527lbs	239 kg / 527lbs	239 kg / 527lbs	239 kg / 527lbs	239 kg / 527lbs ABS
Gear Ratios	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25
Width	860 mm / 33.8 in	860 mm / 33.8 in	860 mm / 33.8 in	860 mm / 33.8 in	860 mm / 33.9 in	860 mm / 33.8 in
Rake	28°	28°	28°	28°	28°	28Â°
Exhaust	Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers	Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers	Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers	Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers	Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminum mufflers	Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers
Instrumentation	Tank mounted instrumentation with TFT colour display: Gear selected, air temp, battery voltage, trips 1 & 2, fuel reserve trip, average and actual fuel consumption and speed, trip time, scheduled maintenance. Full status and/or management of Riding Modes, DTC, RbW and ABS.	Tank mounted instrumentation with TFT colour display: Gear selected, air temp, battery voltage, trips 1 & 2, fuel reserve trip, average and actual fuel consumption and speed, trip time, scheduled maintenance. Full status and/or management of Riding Modes, DTC, RbW and ABS.	Tank mounted instrumentation with TFT colour display: Gear selected, air temp, battery voltage, trips 1 & 2, fuel reserve trip, average and actual fuel consumption and speed, trip time, scheduled maintenance. Full status and/or management of Riding Modes, DTC, RbW and ABS.	Tank mounted instrumentation with TFT colour display: Gear selected, air temp, battery voltage, trips 1 & 2, fuel reserve trip, average and actual fuel consumption and speed, trip time, scheduled maintenance. Full status and/or management of Riding Modes, DTC, RbW and ABS.	Handlebar mounted instrumentation with LCD display: speed, rpm, time, coolant temp. Warning lights for: Neutral, turn signals, high-beam, rev-limit, DTC intervention, ABS status, oil pressure, fuel reserve. Tank mounted instrumentation with TFT colour display: gear selected, air temp, battery voltage, trips 1 & 2, fuel reserve trip, average and actual fuel consumption and speed, trip time, scheduled maintenance. Full status and/or management of Riding Modes, DTC, RbW and ABS.	-
Steering Angle	70°	70°	70°	70°	70°	70Â°
Wheel Travel - Front	120 mm / 4.72 in	120 mm / 4.72 in	120 mm / 4.72 in	120 mm / 4.72 in	120mm / 4.72in	120 mm / 4.72 in
Max Power	119 kW / 162 hp / @ 9500rpm	119 kW / 162 hp / @ 9500rpm	119 kW / 162 hp / @ 9500rpm	119 kW / 162 hp / @ 9500rpm	162 hp / 119 kW @ 9200rpm ↑	152 hp / 113.3 kW @ 9500rpm ↓
Wheel Travel - Rear	120 mm / 4.72 in	120 mm / 4.72 in	120 mm / 4.72 in	120 mm / 4.72 in	120mm / 4.72in	120 mm / 4.72 in
Max Torque	127.5 Nm / 13.0 kgf-m / 94 lb-ft / @ 8000rpm	127.5 Nm / 13.0 kgf-m / 94 lb-ft / @ 8000rpm	127.5 Nm / 13.0 kgf-m / 94 lb-ft / @ 8000rpm	127.5 Nm / 13.0 kgf-m / 94 lb-ft / @ 8000rpm	96 lb-ft / 127.5 Nm @ 8000rpm ↓	94 lb-ft / 127.5 Nm @ 8000rpm ↓
