Key Specifications
Engine
Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven
Power
100 kW / 136 hp @ 9750 rpm With racing kit: 105 kW / 143 hp @ 9750 rpm
Torque
106 Nm / 10.8 kgf-m / 78.1 ft-lb @ 8000rpm With racing kit: 111.8 Nm / 11.4 kgf-m / 82.5 ft-lb @ 8000 rpm
Top Speed
270 km/h / 168 mph
Fuel Capacity
15.5 Litres / 4.1 US gal / 3.4 Imp gal
Full 2006 Ducati 999 S Specifications
Year
2006
Make Model
Ducati 999 S
Seat Height
780 mm / 30.7 in
Wheelbase
1420 mm / 55.9 in
Height
1090 mm / 42.9 in
Length
2095 mm / 82.5 in
Width
730 mm / 28.7 in
Dry Weight (kg)
199
Dry Weight
199 kg / 438 lbs
Fuel Capacity
15.5 Litres / 4.1 US gal / 3.4 Imp gal
Displacement
998 cc / 60.9 cu in
Engine Detail
Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven
Bore x Stroke
100 x 63.5 mm
Compression Ratio
11.4:1
Cooling System
Liquid cooled
Engine Oil Specification
Synthetic, 10W/40
Exhaust
Single steel muffler with catalytic converter
Fuel Consumption
5.56 L/100 km / 18 km/l / 42.3 US mpg / 50.8 Imp mpg
Fuel Induction
Weber Marelli electronic fuel injection, 54 mm throttle body
Ignition
Marelli electronic
Lubrication
Wet sump
Spark Plug
Champion RG4HC
Starter
Electric
Battery Capacity
12V 10Ah
Clutch
Dry multiplate with hydraulic control
Final Drive
Chain
Final Drive Ratio
2.400:1 (15/36)
Gear Ratios
1st 2.466 / 2nd 1.765 / 3rd 1.400 / 4th 1.182 / 5th 1.043 / 6th 0.958:1
Primary Drive Ratios
Straight cut gears, 1.84:1
Transmission / Drive
6 Speed
Frame Type
Tubular steel trellis
Suspension - Front
Öhlins 43mm upside-down fully adjustable fork with TiN surface treatment
Suspension - Rear
Progressive linkage with fully adjustable Öhlins monoshock
Rake
23.5° - 24.5°
Trail
97 mm / 3.8 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
128 mm / 5 in
Brakes - Front
2 x 320 mm Discs, 4 piston calipers
Brakes - Rear
Single 245mm disc, 2 piston caliper
Tyres - Front
120/70 ZR17
Tyres - Rear
190/50 ZR17
Wheels - Front
Y-shaped 5-spoke light alloy 3.50 x 17
Wheels - Rear
Y-shaped 5-spoke light alloy 5.50 x 17
