BMW R 1100S Specs

2001 - 2004 • 4 variants

The BMW R 1100S is a sport tourer produced from 2001 to 2004 across 4 variants. It is powered by a four stroke, two cylinder horizontally opposed boxer, 4 valves per cylinder displacing 1085.00 cc. Peak power output is 98 hp. Peak torque is 97 Nm.

About the BMW R 1100S

The R 1100S represents BMW's contribution to the Sport motorcycle segment, spanning the 1999 to 2006 production run. Our database contains detailed technical specifications for each model year, covering powertrain details, chassis geometry, suspension and braking systems, fuel capacity, and certified weight figures. Use the year navigation above to drill into year-specific data. All specifications are referenced from official BMW documentation.

AdSense - 728Ã90

BMW R 1100S by Year

2004 BMW R 1100S View specs →

2002 BMW R 1100S View specs →

Spec Evolution

How key specs changed across production years.

Specification	2000	2002	2004	2006
Fuel Control	-	-	OHC	SOHC
Engine Type	Two cylinder boxer, four-stroke	Two cylinder boxer, four-stroke	Two cylinder boxer	Two cylinder boxer
Brakes - Front Diameter (mm)	310 mm	305 mm ↓	320 mm ↑	305 mm ↓
Brakes - Front Diameter (in.)	12.2 inches	12.0 inches ↓	12.6 inches ↑	12.0 inches ↓
Bore x Stroke (in,)	-	2.8 x 3.9 inches	3.9 x 2.8 inches ↑	-
Bore x Stroke (mm)	-	70.0 x 99.0 mm	99.0 x 70.5 mm ↑	-
Seat Height	800 mm / 31.4 in	800 mm / 31.5 in.	800 mm / 31.4 in	800 mm / 31.4 in
Dry Weight	237 kg / 522.5 lbs	229 kg / 504.9 lbs ↓	229 kg / 505 lbs	229 kg / 505 lbs
Frame Type	Three section composite frame consisting of front & rear section, load bearing engine	Three section composite frame consisting of front & rear section, load bearing engine	Three-section composite frame consisting of front and rear section, load bearing engine	Three section composite frame consisting of front & rear section, load bearing engine
Wheelbase	1,478 mm / 58.2 in.	1478 mm / 58.2 in ↑	1,478 mm / 58.2 in. ↓	1478 mm / 58.2 in ↑
Brakes - Front	Single disc	2 x 320mm discs, 4 piston calipers	Double disc	2 x 320mm discs, 4 piston calipers
Brakes - Rear	Single disc	Single 276mm disc, 2 piston caliper	Single 276mm disc, 2 piston caliper	Single 276mm disc, 2 piston caliper
Fuel Capacity	18.00 litres / 4.76 gallons	18.00 litres / 4.76 gallons	18 Litres / US 4.76 gal	18 Litres / US 4.76 gal
Suspension - Front	Motorrad Telelever, stanchion diameter 35mm, central strut, rebound damping adjustable.	Motorrad Telelever, stanchion diameter 35mm, central strut, rebound damping adjustable.	Motorrad Telelever, stanchion diameter 35mm, central strut, rebound damping adjustable.	Motorrad Telelever, stanchion diameter 35mm, central strut, rebound damping adjustable.
Top Speed	225.0 km/h / 139.8 mph	218.7 km/h / 135.9 mph ↓	227 km/h / 141 mph ↑	227 km/h / 141 mph
Suspension - Rear	Paralever, central strut, spring preload adjustable to continuously variable levels by mean of a hydraulic handwheel, rebound adjustable damping.	Paralever, central strut, spring preload adjustable to continuously variable levels by mean of a hydraulic handwheel, rebound adjustable damping.	Die-cast aluminium single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring pre-load hydraulically adjustable to continuously variable levels by means of handwheel, rebound damping adjustable	Paralever, central strut, spring preload adjustable to continuously variable levels by mean of a hydraulic handwheel, rebound adjustable damping.
Fuel System	-	Injection	Injection	Injection. Electronic intake pipe injection/digital engine management: Bosch Motronic MA 2.4 with overrun fuel cut-off, twin spark ignition
Colours	Yellow, black, red, two-toned silver/yellow for extra charge	-	Gray, Red, Gray/Mandarin, Blue	-
Final Drive	Shaft	Shaft	Shaft drive (cardan)	Shaft
Height	1160 mm / 45.6 in	1160 mm / 45.6 in	1160 mm / 45.6 in	1160 mm / 45.6 in
Length	2180 mm / 85.8 in	2180 mm / 85.8 in	2180 mm / 85.8 in	2180 mm / 85.8 in
Wet Weight	236 kg / 520 lbs	236 kg / 520 lbs	229.0 kg / 504.9 lbs ↓	236 kg / 520 lbs ↑
Width	880 mm / 34.6 in	880 mm / 34.6 in	895 mm / 35.2 in. ↑	880 mm / 34.6 in ↓
Tyres - Rear	160/60-ZR18	170/60-ZR17 ↑	160/60-ZR18 ↓	160/60-ZR18
Fuel Reserve	4 Litres / 1.05 US gal	4.00 litres / 1.06 gallons	4.00 litres / 1.06 gallons	4 Litres / 1.05 US gal
Wheel Travel - Front	110 mm / 4.3 in	110 mm / 4.3 in	110 mm / 4.3 in	110 mm / 4.3 in
Wheel Travel - Rear	130 mm / 5.1 in	130 mm / 5.1 in.	130 mm / 5.1 in	130 mm / 5.1 in
Max Torque	97 Nm / 9.9 kgf-m / 71.5 lb-ft.@ 5750 rpm	97 Nm / 9.9 kgf-m / 71.5 lb-ft.@ 5750 rpm	97.00	97 Nm / 9.9 kgf-m / 71.5 lb-ft.@ 5750 rpm
Power-to-Weight Ratio	0.4135 HP/kg	0.4279 HP/kg ↑	0.4279 HP/kg	0.4642 HP/kg ↑
