Key Specifications
Engine
In-line six, four-stroke
Power
118 kW / 160.5 hp @ 7750 rpm
Torque
175.0 Nm (17.8 kgf-m or 129.1 ft.lbs) @ 5520 Revolutions">RPM
Weight
336 kg / 740.7 lbs
Fuel Capacity
26.50 litres
Full 2019 BMW K1600 Grand America Specifications
Comments
High Windshield. Dynamic Traction Control. Adaptive Headlight. Tyre Pressure Control. Audio System. Reverse Gear. Anti-theft Alarm System. Intelligent Emergency Call (ECALL).
Year
2018 - 19
Colours
Black Storm Metallic, Imperial Blue Metallic
Colours
Black Storm Metallic
Make Model
BMW K1600 Grand America
Width (mm)
1000 mm
Width (in.)
39.4 inches
Wheelbase (mm)
1618 mm
Wheelbase (in.)
63.7 inches
Storage
Saddle bags, top box
Seat Heigth -Alternate (mm)
780 mm
Seat Heigth -Alternate (in.)
30.7 inches
Seat Height (mm)
750 mm
Seat Height (in.)
29.5 inches
Length (mm)
2560 mm
Length (in.)
100.8 inches
Height (mm)
1440 mm
Height (in.)
56.7 inches
Width (mm)
1,000 mm
Width (in.)
39.4 inches
Wheelbase (mm)
1,618 mm
Wheelbase (in.)
63.7 inches
Storage
Saddle bags, top box
Seat Heigth -Alternate (mm)
780 mm
Seat Heigth -Alternate (in.)
30.7 inches
Seat Height (mm)
750 mm
Seat Height (in.)
29.5 inches
Length (mm)
2,560 mm
Length (in.)
100.8 inches
Height (mm)
1,440 mm
Height (in.)
56.7 inches
Seat Height
780 mm / 30.7 in
Wheelbase
1680 mm / 66.1 in
Height
1465 mm / 57.7 in (excl. mirrors)
Length
2324 m / 91.5 in
Width
1000 mm / 39.4 in (incl. mirrors)
Fuel Capacity (l)
26.50 litres
Fuel Capacity (l)
26.50 litres
Fuel Capacity (gal.)
7.00 gallons
Fuel Capacity (gal.)
7.00 US gallons
Wet Weight (kg)
364.0 kg
Wet Weight (lbs.)
802.5 pounds
Wet Weight (lbs.)
802.5 pounds
Wet Weight (kg)
364.0 kg
Fuel Capacity
26.5 Litres / 7.0 US gal
Wet Weight
336 kg / 740.7 lbs
Displacement (cc)
1649.0 cc
Displacement (ci)
100.62 cubic inches
CO2
132.2 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
72.0 x 67.5 mm
Engine Type
In-line six, four-stroke
Bore x Stroke (in,)
2.8 x 2.7 inches
Bore x Stroke (mm)
72.0 x 67.5 mm
CO2
132.2 CO2 g/km. (CO2 - Carbon dioxide emission)
Displacement (cc)
1649.00 cc
Displacement (ci)
100.62 cubic inches
Engine Type
In-line six, four-stroke
Bore x Stroke (in,)
2.8 x 2.7 inches
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Fuel Reserve (gal.)
1.06 gallons
Fuel Reserve (l)
4.00 litres
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Fuel Reserve (gal.)
1.06 US gallons
Fuel Reserve (l)
4.00 litres
Displacement
1649 cc / 100.6 cu in.
Engine Detail
Four stroke, transverse six cylinder, 4 valves per cylinder
Fuel System
Injection. Electronic intake pipe injection
Fuel System
Injection. Electronic intake pipe injection
Bore x Stroke
72 x 67.5 mm
Compression Ratio
12.2:1
Compression Ratio
12.2:1
Cooling System
Liquid cooled
Emissions
Closed-loop 3-way catalytic converter, emission standard EU-4
Emissions
Closed-loop 3-way catalytic converter, emission standard EU-4
Engine Lubrication
Dry sump
Engine Lubrication
Dry sump
Fuel Consumption
5.70 litres/100 km (17.5 km/l or 41.27 mpg)
Fuel Consumption
5.70 litres/100 km (17.5 km/l or 41.27 mpg)
Fuel Induction
52mm Throttle valve diameter, BMS-X
Fuel Reserve
4 Litres / 1.1 US gal
Fuel Type
Premium unleaded (95 RON)
Ignition
Digital CDI
Starter
Electric
Starter
Electric
Valve System
4
Valve System
4
Battery Capacity
12 V / 19 Ah maintenance free
Clutch
Multiplate wet clutch, hydraulically activated
Clutch
Multiple-disc clutch in oil bath
Final Drive
Shaft drive (cardan) (final drive)
Final Drive
Shaft
Gear Ratios
1st 2.23 / 2nd 1.641 / 3rd 1.319 / 4th 1.101 / 5th 0.926 / 6th 0.788
Gearbox
6-speed
Gearbox
6-speed
Transmission / Drive
Constant-mesh 6-speed gearbox, helical cut
Wheel Travel - Rear (mm)
135 mm
Wheel Travel - Rear (in.)
5.3 inches
Wheel Travel - Front (mm)
125 mm
Wheel Travel - Front (in.)
4.9 inches
Wheel Travel - Rear (mm)
135 mm
Wheel Travel - Rear (in.)
5.3 inches
Wheel Travel - Front (mm)
125 mm
Wheel Travel - Front (in.)
4.9 inches
Trail (mm)
108 mm
Trail (in.)
4.3 inches
Trail (mm)
108 mm
Trail (in.)
4.3 inches
Frame Type
Bridge-type frame, cast aluminium, load-bearing engine
Frame Type
Bridge-type frame, cast aluminium, load-bearing engine
Suspension - Front
BMW Motorrad Duolever
Suspension - Front
Dual longitudinal control arm, Dynamic ESA semi-active suspension (road and dynamic modes)
Suspension - Rear
BMW Motorrad Paralever
Suspension - Rear
Paralever (single-sided swing arm), central spring strut, rebound/continuously variable, Dynamic ESA semi-active suspension (road and dynamic modes)
Rake
27.8°
Rake
27.8°
Steering Head Angle
62.2°
Trail
108.4 mm / 4.3 in
Wheel Travel - Front
115 mm / 4.9 in
Wheel Travel - Rear
135 mm / 5.3 in
Brakes - Rear Diameter (mm)
320 mm
Brakes - Rear Diameter (in.)
12.6 inches
Brakes - Front Diameter (mm)
320 mm
Brakes - Front Diameter (in.)
12.6 inches
Brakes - Front
2 x 320mm discs, 4 piston calipers
Brakes - Front
Double disc. ABS. Four-piston calipers.
Brakes - Rear
Single 320mm disc, 2 piston caliper
Brakes - Rear
Single disc. ABS. Two-piston calipers.
ABS
BMW Motorrad ABS (partial integral)
Rims - Front
3.0 x 17
Rims - Rear
6.00 x 17
Tyres - Front
120/70-ZR17
Tyres - Front
120/70 ZR17
Tyres - Rear
190/55 ZR17
Wheels
Cast aluminium wheels
