CO2
|
74.2 CO | 73.8 CO2 g/km. (CO2 - Carbon dioxide emission) ↓ | - |
|
Fuel Control
|
DOHC | Double Overhead Cams/Twin Cam (DOHC) | - |
|
Seat Height
|
861 mm / 33.9 in. | 860 mm to 900 mm / 33.9 in. to 35.4 in. ↓ | 860 mm to 900 mm / 33.9 in. to 35.4 in. |
|
Dry Weight
|
176.9 kg / 390.0 lbs | 177 kg / 390 lbs ↑ | 177 kg / 390 lbs |
|
Brakes - Front
|
Single 300mm disc, 2 piston caliper | Single 300mm disc, 2 piston caliper | Single 300mm disc, 2 piston caliper |
|
Wheelbase
|
1484 mm / 58.4 in. | 1484 mm / 58.4 in. | 1484 mm / 58.4 in. |
|
Engine Detail
|
Ducati 90 degree L-Twin | Four stroke, single cylinder, DOHC, 4 valves per cylinder ↓ | Four stroke, single cylinder, DOHC, 4 valves per cylinder |
|
Fuel Capacity
|
14.00 litres / 3.70 gallons | 14 Litres / 3.7 US gal | 14 Litres / 3.7 US gal |
|
Brakes - Rear
|
Single 240mm disc, 1 piston caliper | Single 240mm disc, 1 piston caliper | Single 240mm disc, 1 piston caliper |
|
Suspension - Front
|
Telescopic fork, 41 mm, fork stabilizer | 41mm telescopic fork with stabilizer bridge | 41mm telescopic fork with stabilizer bridge |
|
Suspension - Rear
|
Box-section steel dual swing arm, central spring strut operated by lever system, spring preload hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable | Spring setting and rebound stage damping continuously adjustable, | Spring setting and rebound stage damping continuously adjustable, |
|
Fuel System
|
Injection. Electronic intake pipe injection/BMW engine management, twin spark ignition | Injection. Electronic intake pipe injection / BMW engine management, twin-spark ignition | - |
|
Colours
|
Red, white | Blue/white | - |
|
Height
|
1440 mm / 56.7 in.(excl. mirrors) | 1440 mm / 56.7 in.(excl. mirrors) | 1440 mm / 56.7 in.(excl. mirrors) |
|
Length
|
2185 mm / 86 in. | 2185 mm / 86 in. | 2185 mm / 86 in. |
|
Wet Weight
|
191 kg / 421 lbs | 191 kg / 421 lbs | 191 kg / 421 lbs |
|
Tyres - Front
|
120/70-17 | 90/90 S21 ↓ | 90/90 S21 |
|
Width
|
920 mm / 36.2 in. (incl. mirrors) | 920 mm / 36.2 in. (incl. mirrors) | 920 mm / 36.2 in. (incl. mirrors) |
|
Tyres - Rear
|
130/80-17 | 130/80-17 | 130/80-17 |
|
Fuel Consumption
|
3.18 litres/100 km (31.4 km/l or 73.97 mpg) | 3.18 litres/100 km (31.4 km/l or 73.97 mpg) | - |
|
Fuel Reserve
|
3.79 litres / 1.00 gallons | 3.79 litres / 1.00 gallons | - |
|
Trail
|
122 mm / 4.8 in. | 123 mm / 4.8 in ↑ | 123 mm / 4.8 in |
|
Wheel Travel - Front
|
210 mm / 8.3 in | 210 mm / 8.3 in | 210 mm / 8.3 in |
|
Wheel Travel - Rear
|
120 mm / 4.7 in. | 210 mm / 8.3 in ↑ | 210 mm / 8.3 in |
|
Max Torque
|
60 Nm / 6.1 kgf-m / 44.25 lb-ft. @ 5000 rpm | 60 Nm / 6.1 kgf-m / 44.25 lb-ft. @ 5000 rpm | 60 Nm / 6.1 kgf-m / 44.25 lb-ft. @ 5000 rpm |
|
Power-to-Weight Ratio
|
0.2743 HP/kg | 0.2826 HP/kg | - |
