Comments
|
Windscreen. | - | Windscreen. Keyless. | Windscreen. Ride by Wire. Self calibrating ASC. Keyless. USB charging. | - |
|
Frame Type
|
Steel tube construction with aluminum die cast unit | Steel tube construction with aluminum die cast unit | Steel tube construction with aluminum die cast unit and #8232; | Steel tube construction with aluminum die cast unit and #8232; | Steel bridge-type frame |
|
Dry Weight
|
203 kg / 450 lbs | 202 kg / 445.3 lbs ↓ | 202 kg / 445.3 lbs | 202 kg / 445.3 lbs | 207 kg / 456.3 lbs ↑ |
|
Displacement
|
350 cc / 21.3 cub in | 350 cc / 21.3 cu-in | - | - | 350 cc / 21.3 cu-in |
|
Seat Height
|
775 mm / 30.5 in. | 775 mm / 30.5 in | 775 mm / 30.5 in. | 775 mm / 30.5 in. | 765 mm / 30.1 in ↓ |
|
Wheelbase
|
1564.5 mm / 61.6 in | 1564.5 mm / 61.6 in | 1565 mm / 61.6 in. ↑ | 1565 mm / 61.6 in. | 1564.5 mm / 61.6 in ↓ |
|
Brakes - Front
|
2x 265mm Rigid discs 4 piston caliper | 2x 265mm Rigid discs, 4 piston caliper | Double disc. 4-piston calipers. ABS. ↑ | Double disc. 4-piston calipers. ABS. | 2x 265mm Rigid discs, 4 piston caliper ↓ |
|
Brakes - Rear
|
Single 265mm disc 1 piston caliper | Single 265mm disc, 1 piston floating caliper | Single disc. 1-piston floating calipers. ABS. ↓ | Single disc. 1-piston floating calipers. ABS. | Single 265mm disc, 1 piston floating caliper ↑ |
|
Fuel Capacity
|
12.8 Litres / 3.4 US gal | 12.8 Litres / 3.4 US gal | 12.80 litres / 3.38 US gallons | 12.80 litres / 3.38 US gallons | 12.8 Litres / 3.4 US gal |
|
Suspension - Front
|
35mm Telescopic forks. | 35mm Telescopic forks | Telescopic front fork, Ø 35 mm | Telescopic front fork, Ø 35 mm | 35mm Telescopic forks |
|
Suspension - Rear
|
Double Aluminum swingarm, Double spring struts, adjustable preload | Double Aluminum swingarm, double spring struts, adjustable preload | Double aluminum swingarm, double springs struts, adjustable preload | Double aluminum swingarm, double springs struts, adjustable preload | Double Aluminum swingarm, double shock absorber, adjustable spring preload |
|
Fuel System
|
Injection | - | Injection. Electronic port fuel injection/digital engine management: BMS-ME with e-throttle grip | Injection. Electronic port fuel injection/digital engine management: BMS-ME with e-throttle grip | - |
|
Colours
|
Alpine White, Moonwalkgrey Metallic, Blackstorm Metallic | - | Alpine White, Callisto Gray Metallic, Triple Black | Alpine White, Callisto Gray Metallic, Triple Black | - |
|
Height
|
1437 mm / 56.5 in | 1437 mm / 56.5 in | 1305 mm / 51.4 in. ↓ | 1305 mm / 51.4 in. | 1500 mm / 59.0 in ↑ |
|
Length
|
2210 mm / 87 in | 2210 mm / 87 in | 2210 mm / 87.0 in. | 2210 mm / 87.0 in. | 2200 mm / 86.6 in ↓ |
|
Wet Weight
|
212.0 kg / 467.4 lbs | 214 kg / 471.7 lbs ↑ | 214.1 kg / 472.0 lbs ↑ | 214.1 kg / 472.0 lbs | 215 kg / 474.0 lbs ↑ |
|
Emissions
|
Closed-loop 3-way catalytic converter, emission standard EU-4 | EURO5 ↑ | Closed-loop 3-way catalytic converter, emission standard EU-4 ↓ | Closed-loop 3-way catalytic converter, emission standard EU-4 | EURO5 ↑ |
|
Tyres - Front
|
120/70-ZR15 | 120/70 R15 | 120/70-R15 | 120/70-R15 | 120/70 R15 |
|
Width
|
835 mm / 32.9 in. | 835 mm / 32.9 in | 835 mm / 32.9 in. | 835 mm / 32.9 in. | 845 mm / 33.3 in ↑ |
|
Tyres - Rear
|
150/70 ZR14 | 150/70 R14 | - | - | 150/70 R14 |
|
Exhaust
|
Stainless Steel | Closed-loop three-way catalytic converter | - | Stainless steel | Closed-loop three-way catalytic converter |
|
Transmission / Drive
|
Stepless CVT gearbox | Stepless CVT gearbox | - | - | Stepless CVT gearbox, belt drive |
|
Steering Head Angle
|
63,6° | 63.6° | - | - | 63.6° |
|
Fuel Induction
|
Fuel injection, BMS-E2 40mm throttle valve diameter | Electronic intake pipe fuel injection/digital engine management: BMS-ME with e-throttle grip | - | - | Electronic intake pipe fuel injection/digital engine management: BMS-ME with throttle-by-wire |
|
Trail
|
81.2 mm / 3.2 in | 81.2 mm / 3.2 in | 81 mm / 3.2 in. ↓ | 81 mm / 3.2 in. | 81.2 mm / 3.2 in ↑ |
|
Max Power
|
25.3 kW / 34 hp @ 7500 rpm | 25 kW / 33.5 hp @ 7500 rpm ↓ | - | - | 25 kW / 33.5 hp @ 7500 rpm |
|
Wheel Travel - Front
|
110 mm / 4.3 in | 110 mm / 4.3 in | 110 mm / 4.3 in. | 110 mm / 4.3 in. | 110 mm / 4.3 in |
|
Wheel Travel - Rear
|
112 mm / 4.4 in | 112 mm / 4.4 in | 112 mm / 4.4 in. | 112 mm / 4.4 in. | 112 mm / 4.4 in |
|
Max Torque
|
34.3 Nm / 25.8 lb-ft @ 6000 rpm | 35 Nm / 25.8 lb-ft @ 5750 rpm ↑ | 35.0 Nm (3.6 kgf-m or 25.8 ft.lbs) @ 6000 Revolutions" | 35.0 Nm (3.6 kgf-m or 25.8 ft.lbs) @ 6000 Revolutions" | 35 Nm / 25.8 lb-ft @ 5750 rpm |
|
Starter
|
Electric, 500 kW | Electric, 500 kW | Electric | Electric | Electric, 500 kW |
