| General |
| Comments | Security system. Noise Level L-urban: 74dB L-wot: 76.4dB. Model id: CB500FA. | - |
| Year | - | 2022 |
| Colours | Matte Grey Metallic | - |
| Make Model | - | Husqvarna Svartpilen 401 |
| Warranty | One year. Transferable. Unlimited-mileage. | - |
| Dimensions |
| Ground Clearance (mm) | 145 mm | - |
| Ground Clearance (in.) | 5.7 inches | - |
| Seat Height | 790 mm / 31.1 in. | 835 mm / 32.8 in |
| Wheelbase | 1410 mm / 55.5 in. | 1357 ± 15.5 mm / 53.4 in |
| Ground Clearance | - | 145 mm / 5.6 in |
| Height | 1060 mm / 41.7 in. | - |
| Length | 2080 mm / 81.9 in. | - |
| Width | 800 mm / 31.5 in. | - |
| Weights & Capacities |
| Oil Capacity (Quarts) | 2.85 US quarts | - |
| Oil Capacity (l) | 2.70 litres | - |
| Dry Weight | 192 kg / 423.3 lbs | 152 kg / 335.6 lbs |
| Fuel Capacity | 16.70 litres / 4.41 US gallons | 9.5 Litres / 2.5 US gal |
| Coolant Capacity | 2.00 litres (0.53 US gallons) | - |
| Wet Weight | 189.0 kg / 416.7 lbs | - |
| Performance |
| Max Power | - | 44 hp / 32 kW @ 9000 rpm |
| Max Torque | 43.0 Nm (4.4 kgf-m or 31.7 ft.lbs) @ 6500 Revolutions | 37 Nm / 27.3 lb-ft @ 7000 rpm |
| Power-to-Weight Ratio | 0.2445 HP/kg | - |
| Engine |
| CO2 | 81.2 CO2 g/km. (CO2 - Carbon dioxide emission) | - |
| Bore x Stroke (mm) | 67.0 x 66.8 mm | - |
| Bore x Stroke (in,) | 2.6 x 2.6 inches | - |
| Displacement (ci) | 28.74 cubic inches | - |
| Engine Type | Twin, four-stroke | - |
| Fuel Control | Double Overhead Cams/Twin Cam (DOHC) | - |
| Displacement (cc) | 471.0 cc | - |
| Displacement | - | 373.2 cc / 22.8 cu-in |
| Engine Detail | - | Four stroke, single cylinder, DOHC with cam levers, 4 valves |
| Fuel System | Injection. PGM-FI with 34mm throttle bodies | - |
| Bore x Stroke | - | 89 x 60 mm |
| Compression Ratio | 10.7:1 | 12.6:1 |
| Cooling System | - | Liquid cooled |
| Emissions | Euro 5 | EURO 5 |
| Engine Management | - | Bosch EMS |
| Exhaust | - | Stainless steel / Aluminium silencer with regulated catalytic converter |
| Fuel Consumption | 3.50 litres/100 km (28.6 km/l or 67.21 mpg) | - |
| Fuel Induction | - | Bosch EFI (throttle body 46 mm) |
| Ignition | Computer-controlled digital transistorized with electronic advance | - |
| Lubrication | - | Wet sump with 2 oil pumps |
| Spark Plug | NGK CPR8EA-9 | - |
| Starter | Electric | Electric |
| Valve System | 4 | - |
| Drivetrain |
| Chain Size | 520 | - |
| Clutch | Wet multiplate, assist/slipper clutch | Multi disc slipper clutch |
| Final Drive | Chain (final drive) | Chain, X-Ring 5/8 x 1/4″ |
| Final Drive Ratio | - | 15:45 |
| Gearbox | 6-speed | - |
| Number of Chain Links | 112 | - |
| Primary Drive | O-ring-sealed chain; 15T/41T | - |
| Primary Drive Ratios | - | 30:80 |
| Sprocket | 15/41 (front/rear) | - |
| Transmission / Drive | - | 6 Speed |
| Chassis |
| Fork Tube Size (in.) | 1.6 inches | - |
| Fork Tube Size (mm) | 41 mm | - |
| Frame Type | Diamond tube | Steel trellis frame, powder coated |
| Suspension - Front | Showa 41mm SFF-BP USD forks | 43mm WP APEX upside-down forks, with compression rebound adjustability |
| Suspension - Rear | Pro-Link® single shock with nine-position spring-preload adjustability | WP APEX monoshock with preload adjustability |
| Clamp Offset - Triple | - | 32 mm / 1.8 in |
| Rake | 25.5° | 25° |
| Steering Head Angle | - | 65° |
| Trail | 102 mm / 4.0 in. | 95 mm / 3.7 in |
| Wheel Travel - Front | 120 mm / 4.7 in. | 142 mm / 5.6 in |
| Wheel Travel - Rear | 119 mm / 4.7 in. | 142 mm / 5.6 in |
| Electrical Systems |
| Instrumentation | LCD Meter with Speedometer, Bar Graph Tachometer, Dual Trip Meters, Fuel Level and Consumption Gauge, Clock, Water Temp, Gear position, Shift UP Indicator | - |
| Lighting system | Full LED lighting | - |
| Wheels & Brakes |
| Brakes - Front | Single disc. ABS. 4-piston calipers. | Single 320mm disc, ByBre 4 piston caliper |
| Brakes - Rear | Single disc. ABS. | Single 230mm disc, ByBre, single piston, floating caliper |
| ABS | - | Two channel Bosch 10.1MB |
| Brake Fluid Type | DOT 4 | - |
| Tyre Pressure - Front | 36 PSI (2.5 Bar or 250 kPa) | - |
| Tyre Pressure - Rear | 42 PSI (2.9 Bar or 290 kPa) | - |
| Tyres - Front | 120/70-R17 | 110/70-R17 Pirelli Scorpion Rally STR |
| Tyres - Rear | - | 150/60-R17 Pirelli Scorpion Rally STR |
| Wheels | - | Spoked wheels with aluminium rims |
| Wheels - Front | - | 3.00 x 17 |
| Wheels - Rear | - | 4.00 x 17 |
