| General |
| Comments | - | 5 configurable riding modes. Traction control. Cruise control. Keyless. |
| Year | 2009 | - |
| Colours | - | Sapphire Black, Matte Silver Ice |
| Make Model | Buell 1125CR | - |
| Dimensions |
| Height (in.) | - | 42.9 inches |
| Height (mm) | - | 1089 mm |
| Length (in.) | - | 80.9 inches |
| Length (mm) | - | 2055 mm |
| Seat Height (mm) | - | 830 mm |
| Wheelbase (in.) | - | 56.9 inches |
| Wheelbase (mm) | - | 1445 mm |
| Width (in.) | - | 31.2 inches |
| Width (mm) | - | 792 mm |
| Seat Height (in.) | - | 32.7 inches |
| Seat Height | 775 mm / 30.5" | - |
| Wheelbase | 1384 mm / 54.5" | - |
| Weights & Capacities |
| Oil Capacity (Quarts) | - | 4.02 US quarts |
| Fuel Capacity (l) | - | 15.50 litres |
| Wet Weight (kg) | - | 198.0 kg |
| Dry Weight (kg) | 168 | - |
| Wet Weight (lbs.) | - | 436.5 pounds |
| Oil Capacity (l) | - | 3.80 litres |
| Fuel Capacity (gal.) | - | 4.10 US gallons |
| Dry Weight | 168 kg / 370 lbs | - |
| Fuel Capacity | 21.2 L / 5.6 US gal | - |
| Performance |
| Max Power | 109 kW / 146 hp @ 9800 rpm | - |
| Max Torque | 111 Nm / 11.3 kgf-m / 81.9 ft.lbs@ 9000 rpm | 124.8 Nm (12.7 kgf-m or 92.0 ft.lbs) @ 9000 Revolutions">RPM |
| Engine |
| Displacement (ci) | - | 70.78 cubic inches |
| Displacement (cc) | - | 1160.0 cc |
| Fuel Control | - | Double Overhead Cams/Twin Cam (DOHC) |
| Engine Type | - | In-line three, four-stroke |
| Bore x Stroke (in,) | - | 3.5 x 2.4 inches |
| Bore x Stroke (mm) | - | 90.0 x 60.8 mm |
| CO2 | - | 149.2 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Displacement | 1125 cc / 68.7 cu in | - |
| Engine Detail | Four stroke, 72° V-Twin | - |
| Fuel System | - | Injection. Multipoint sequential electronic fuel injection with electronic throttle control |
| Bore x Stroke | 103 x 67.5 mm | - |
| Compression Ratio | 12.3:1 | 13.2:1 |
| Cooling System | Liquid cooled | - |
| Exhaust | - | Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer |
| Fuel Consumption | - | 6.43 litres/100 km (15.6 km/l or 36.58 mpg) |
| Fuel Induction | Dual Ø61 mm downdraft throttle Bbodies, DDFI III Fuel Injection System | - |
| Starter | Electric | Electric |
| Valve System | - | 4 |
| Drivetrain |
| Clutch | - | Wet. multi-plate, slip |
| Final Drive | Belt | Chain (final drive) |
| Gear Ratios | 1st 2.46 / 2nd 1.75 / 3rd / 1.28 / 4th 1.17 / 5th 1.04 / 6th 1.00 | - |
| Gearbox | - | 6-speed |
| Primary Drive | - | X-ring chain |
| Transmission / Drive | 6 Speed | - |
| Chassis |
| Trail (mm) | - | 105 mm |
| Trail (in.) | - | 4.1 inches |
| Wheel Travel - Rear (mm) | - | 120 mm |
| Wheel Travel - Front (mm) | - | 120 mm |
| Wheel Travel - Rear (in.) | - | 4.7 inches |
| Wheel Travel - Front (in.) | - | 4.7 inches |
| Frame Type | Aluminium frame with fuel in frame. | Aluminum twin spar frame. bolt-on aluminium rear subframe |
| Suspension - Front | ø47 mm Showa inverted forks, adjustable compression damping. rebound damping and spring preload. 120mm wheel travel. | Ohlins 43 mm NIX30 upside down forks with adjustable preload, rebound and compression damping |
| Suspension - Rear | 120 mm / 4.7" | Showa® coil over monoshock, adjustable compression damping. rebound damping and spring preload. | Öhlins TTX36 twin tube monoshock with preload, rebound and compression damping |
| Rake | - | 23.9° |
| Wheel Travel - Front | 120 mm / 4.7" | - |
| Electrical Systems |
| Instrumentation | - | 5 inch TFT color instruments |
| Lighting system | - | All-LED lighting. with self-cancelling indicators |
| Wheels & Brakes |
| Brakes - Front | ZTL type brake, 6-piston, fixed caliper, Ø375 mm single-sided, inside out, stainless steel, floating rotor | Double disc. ABS. Floating discs. Brembo. |
| Brakes - Rear | Single Ø240 mm disc, 2 piston floating caliper | Single disc. ABS. Two-piston calipers. Brembo. |
| Rims | - | Cast Aluminum. Metzeler Racetec RR K3 tires. |
| Tyres - Front | 120/70 ZR17, Pirelli Diablo Corsa III | 120/70-ZR17 |
| Tyres - Rear | 180/55 ZR17, Pirelli Diablo Corsa III | - |
