Ground Clearance (in.)
|
13.2 inches | 13.2 inches | 13.2 inches | 13.2 inches | 13.2 inches | 13.2 inches | 12.6 inches ↓ | 12.6 inches |
|
Comments
|
- | - | - | - | - | Power Tuner app | Power Tuner app | Power Tuner App. Adjustable Engine Mapping. |
|
Bore x Stroke (mm)
|
97.0 x 60.8 mm | 97.0 x 60.8 mm | 97.0 x 60.8 mm | 97.0 x 60.9 mm | 97.0 x 60.9 mm | 97.0 x 60.9 mm | 97.0 x 60.9 mm | 97.0 x 60.9 mm |
|
Ground Clearance (mm)
|
335 mm | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm | 320 mm ↓ | 320 mm |
|
Frame Type
|
Aluminum Bilateral Beam frame | Aluminum Bilateral Beam frame | Aluminum Bilateral Beam frame | Aluminum Bilateral Beam frame | Aluminum Bilateral Beam frame | Aluminum Bilateral Beam frame | Aluminum Bilateral Beam frame | Aluminum Bilateral Beam |
|
Seat Height
|
965 mm / 38.0 in. | 965 mm / 38.0 in. | 965 mm / 38.0 in. | 965 mm / 38.0 in. | 965 mm / 38.0 in. | 955 mm / 37.6 in. ↓ | 955 mm / 37.6 in. | 955 mm / 37.6 in. |
|
Wheelbase
|
2,164 mm / 85.2 in. | 2,164 mm / 85.2 in. | 2,164 mm / 85.2 in. | 1481 mm / 58.3 in. ↑ | 1481 mm / 58.3 in. | 1481 mm / 58.3 in. | 1481 mm / 58.3 in. | 1481 mm / 58.3 in. |
|
Fuel Capacity
|
7.57 litres / 2.00 gallons | 7.57 litres / 2.00 gallons | 7.57 litres / 2.00 gallons | 8.33 litres / 2.20 US gallons ↑ | 8.33 litres / 2.20 US gallons | 8.33 litres / 2.20 US gallons | 8.33 litres / 2.20 US gallons | 8.33 litres / 2.20 US gallons |
|
Suspension - Front
|
KYB® spring-type fork with speed sensitive damping; fully adjustable | KYB® spring-type fork with speed sensitive damping; fully adjustable | KYB® spring-type fork with speed sensitive damping; fully adjustable | KYB® spring-type fork with speed sensitive damping; fully adjustable | KYB® spring-type fork with speed sensitive damping; fully adjustable | KYB® spring-type fork with speed sensitive damping; fully adjustable | KYB® spring-type fork with speed sensitive damping; fully adjustable | KYB® spring-type fork with speed sensitive damping; fully adjustable |
|
Suspension - Rear
|
KYB® single shock; full adjustable | KYB® single shock; full adjustable | KYB® single shock; full adjustable | KYB® single shock; full adjustable | KYB® single shock; full adjustable | KYB® single shock; full adjustable | KYB® single shock; full adjustable | KYB® single shock; full adjustable |
|
Fuel System
|
Injection. Keihin 44mm | Injection. Keihin 44mm | Injection. Keihin 44mm | Injection. Keihin 44mm | Injection. Mikuni® fuel injection, 44mm | Injection. Mikuni® 44mm | Injection. Mikuni® 44mm | Injection. Mikuni® 44mm |
|
Colours
|
Team Yamaha Blue/White | Blue/White | Team Yamaha Blue | Team Yamaha Blue | Team Yamaha Blue | Team Yamaha Blue | Team Yamaha Blue | Team Yamaha Blue |
|
Final Drive
|
Chain | Chain | Chain | Chain (final drive) | Chain (final drive) | Chain (final drive) | Chain (final drive) | Chain (final drive) |
|
Height
|
1,290 mm / 50.8 in. | 1,290 mm / 50.8 in. | 1,290 mm / 50.8 in. | 1290 mm / 50.8 in. ↑ | 1270 mm / 50.0 in. ↓ | 1280 mm / 50.4 in. ↑ | 1280 mm / 50.4 in. | 1280 mm / 50.4 in. |
|
Rims
|
- | - | Dunlop® AT81F tyres | Dunlop® AT81F tyres ↓ | Dunlop® MX3S tyres ↓ | Dunlop® MX3S tyres | Dunlop Geomax MX33 tyres ↑ | Dunlop Geomax MX33 tyres |
|
Length
|
2,174 mm / 85.6 in. | 2,174 mm / 85.6 in. | 2,174 mm / 85.6 in. | 2174 mm / 85.6 in. ↑ | 2174 mm / 85.6 in. | 2174 mm / 85.6 in. | 2174 mm / 85.6 in. | 2174 mm / 85.6 in. |
|
Wet Weight
|
118.8 kg / 262.0 lbs | 118.8 kg / 262.0 lbs | 118.8 kg / 262.0 lbs | 116.1 kg / 256.0 lbs ↓ | 116.1 kg / 256.0 lbs | 115.2 kg / 254.0 lbs ↓ | 115.2 kg / 254.0 lbs | 115.2 kg / 254.0 lbs |
|
Compression Ratio
|
12.5:1 | 12.5:1 | 12.5:1 | 12.8:1 ↑ | 12.8:1 | 12.8:1 | 12.8:1 | 13.0:1 ↑ |
|
Tyres - Front
|
90/90-21 | 90/90-21 | 90/90-21 | 80/100-21 ↓ | 80/100-21 | 80/100-21 | 80/100-21 | 80/100-21 |
|
Rake
|
28.0° | 28.0° | 28.0° | 27.2° ↓ | 27.2° | 27.2° | 27.2° | 27.2° |
