Ground Clearance (mm)
|
325 mm | 325 mm | 325 mm | 361 mm ↑ | 361 mm | 361 mm | 361 mm | 361 mm |
|
Ground Clearance (in.)
|
12.8 inches | 12.8 inches | 12.8 inches | 14.2 inches ↑ | 14.2 inches | 14.2 inches | 14.2 inches | 14.2 inches |
|
Bore x Stroke (mm)
|
66.4 x 72.0 mm | 66.4 x 72.0 mm | 66.4 x 72.0 mm | 66.4 x 72.0 mm | 66.0 x 72.0 mm ↓ | 66.4 x 72.0 mm ↑ | 66.4 x 72.0 mm | 66.4 x 72.0 mm |
|
Brakes - Front Diameter (mm)
|
250 mm | 270 mm ↑ | 270 mm | - | - | - | - | - |
|
Brakes - Front Diameter (in.)
|
9.8 inches | 10.6 inches ↑ | 10.6 inches | - | - | - | - | - |
|
Seat Height
|
970 mm / 38.2 in. | 970 mm / 38.2 in. | 970 mm / 38.2 in. | 970 mm / 38.2 in. | 970 mm / 38.2 in. | 970 mm / 38.2 in. | 970 mm / 38.2 in. | 975 mm / 38.4 in. ↑ |
|
Wheelbase
|
1,486 mm / 58.5 in. | 1,486 mm / 58.5 in. | 1,486 mm / 58.5 in. | 1486 mm / 58.5 in. ↑ | 1486 mm / 58.5 in. | 1486 mm / 58.5 in. | 1486 mm / 58.5 in. | 1486 mm / 58.5 in. |
|
Fuel Capacity
|
7.57 litres / 2.00 gallons | 7.57 litres / 2.00 gallons | 7.57 litres / 2.00 gallons | 7.95 litres / 2.10 US gallons ↑ | 7.95 litres / 2.10 US gallons | 7.95 litres / 2.10 US gallons | 7.95 litres / 2.10 US gallons | 6.81 litres / 1.80 US gallons ↓ |
|
Suspension - Front
|
KYB Speed-Sensitive System | KYB Speed-Sensitive System | KYB® Speed-Sensitive System inverted fork; fully adjustable | KYB® Speed-Sensitive System inverted fork; fully adjustable | KYB® Speed-Sensitive System inverted fork; fully adjustable | KYB® Speed-Sensitive System inverted fork; fully adjustable | KYB® Speed-Sensitive System inverted fork; fully adjustable | KYB® Speed-Sensitive System inverted fork; fully adjustable |
|
Suspension - Rear
|
KYB Fully adjustable single shock | KYB Fully adjustable single shock | KYB® single shock; fully adjustable | KYB® single shock; fully adjustable | KYB® single shock; fully adjustable | KYB® single shock; fully adjustable | KYB® single shock; fully adjustable | KYB® single shock; fully adjustable |
|
Fuel System
|
Injection. Keihin® PWK38S | Injection. Keihin® PWK38S | Injection. Keihin® PWK38S | Injection. Keihin® PWK38S ↓ | Injection. Keihin® PWK38S | Injection. Keihin® PWK38S | Injection. Keihin® PWK38S | Injection. Hitachi Astemo® Keihin PWK38S |
|
Colours
|
Team Yamaha Blue/White | Blue/White | Team Yamaha Blue | Team Yamaha Blue | Team Yamaha Blue | Team Yamaha Blue | Team Yamaha Blue | Team Yamaha Blue |
|
Final Drive
|
Chain | Chain | Chain | Chain (final drive) | Chain (final drive) | Chain (final drive) | Chain (final drive) | Chain (final drive) |
|
Rims
|
- | - | Dunlop® AT81F tyres | Dunlop® AT81F tyres ↓ | Dunlop® AT81F tyres | Dunlop® AT81F tyres | Dunlop® Geomax AT81 tyres | Dunlop® Geomax MX33 tyres ↓ |
|
Height
|
1,280 mm / 50.4 in. | 1,280 mm / 50.4 in. | 1,280 mm / 50.4 in. | 1290 mm / 50.8 in. ↑ | 1290 mm / 50.8 in. | 1290 mm / 50.8 in. | 1290 mm / 50.8 in. | 1290 mm / 50.8 in. |
|
Length
|
2,184 mm / 86.0 in. | 2,184 mm / 86.0 in. | 2,184 mm / 86.0 in. | 2184 mm / 86.0 in. ↑ | 2184 mm / 86.0 in. | 2184 mm / 86.0 in. | 2184 mm / 86.0 in. | 2184 mm / 86.0 in. |
|
Wet Weight
|
103.9 kg / 229.0 lbs | 103.9 kg / 229.0 lbs | 229.0 kg / 504.9 lbs ↑ | 103.9 kg / 229.0 lbs ↓ | 103.9 kg / 229.0 lbs | 103.9 kg / 229.0 lbs | 103.9 kg / 229.0 lbs | 103.9 kg / 229.0 lbs |
|
Tyres - Front
|
90/90-21 | 90/90-21 | 90/90-21 | 90/90-21 | 90/90-21 | 90/90-21 | 90/90-21 | 80/100-21 ↓ |
|
Primary Drive
|
O-ring chain | O-ring chain | O-ring chain | O-ring chain | O-ring chain | Sealed O-ring chain | Sealed O-ring chain. Constant mesh. | Sealed O-ring chain. Constant mesh. |
|
Rake
|
25.0° | 25.0° | 27.7° ↑ | 27.7° | 27.7° | 27.7° | 27.7° | 27.7° |
|
Trail
|
76 mm / 3.0 in. | 76 mm / 3.0 in. | 122 mm / 4.8 in. ↑ | 122 mm / 4.8 in. | 122 mm / 4.8 in. | 122 mm / 4.8 in. | 122 mm / 4.8 in. | 122 mm / 4.8 in. |
|
Ignition
|
- | - | - | CDI | CDI | Digital CDI | Digital CDI | Digital CDI |
