2020 Yamaha X-MAX 300 Specifications

Name: 2020 Yamaha X-MAX 300
Brand: Yamaha

Scooter • Specs last verified 13 July 2026

No images available

Tap to enlarge

2020 Yamaha X-MAX 300 Overview

For 2020, Yamaha offers the X-MAX 300 as a scooter motorcycle with 292 cc on tap. The 2020 Yamaha X-MAX 300 is built around a Single cylinder, four-stroke engine running Single Overhead Cams (SOHC) valve actuation, a compression ratio of 10.9:1. Internally, bore and stroke are 70 x 75.9 mm. Out on the road, the X-MAX 300 delivers 29 Nm @ 5750 Revolutions of torque. In everyday use, the 2020 X-MAX 300 tips the scales at 179 kg, carries a 13-litre fuel tank, offers a seat height of 795 mm and spans a 1540 mm wheelbase. That's roughly 18.7 kg lighter than the average scooter motorcycle in our database. Every technical detail, from suspension travel to tyre sizes, is covered in the full 2020 Yamaha X-MAX 300 spec sheet below.

2020 X-MAX 300 - Pros & Cons

Strengths

Fuel injection: No choke, no jetting, no altitude compensation to think about - fuel injection just works across a wider range of conditions than carburetion.
Low-maintenance final drive: Belt (final drive) final drive is about as close to maintenance-free as motorcycle drivetrains get.

Considerations

Age-related wear: No particular mechanical concern flags for the X-MAX 300 - condition on any used example comes down to how well it's been looked after.

Wear Points & Servicing Notes

Fuelling & injector care

Fuelling on the X-MAX 300 comes from fuel injection. Cold starts and throttle response stay consistent across altitude and temperature, the main practical edge over a carbureted equivalent.

Valve clearance checks

Valve clearances on Single Overhead Cams (SOHC)-equipped engines like the X-MAX 300's drift slowly with mileage rather than failing suddenly - sticking to the service interval keeps it a non-issue.

Brake disc and pad wear

Single disc. Hydraulic. ABS. up front provides the primary stopping power; inspect disc thickness and pad wear at each tyre change to catch scoring before it becomes a rotor replacement.

Suspension condition on used examples

Suspension duties are handled by Telescopic forks up front and Unit Swing at the rear. Weeping fork seals aren't a dealbreaker on a used bike, but they're a fair basis for negotiating price.

Final drive maintenance

Belt final drive keeps day-to-day maintenance minimal on the X-MAX 300 - just periodic tension and wear checks rather than the regular cleaning a chain demands.

Frame & chassis check

The Underbone chassis holds up well with normal use; on a used bike it's still worth checking the head-stock and swingarm pivot area for impact damage or corrosion.

X-MAX 300 - Buying & Maintenance Guide

What to check before buying

A pre-purchase check on the 2020 Yamaha X-MAX 300 should cover the same ground every time: service history, chain and sprocket condition, and any oil seepage around the casings. Start it from cold if you can - a well-kept X-MAX 300 settles to a smooth idle within seconds.

Oil and filter changes

Oil changes are the cheapest insurance you can buy for a X-MAX 300's engine - keep to the manufacturer's interval rather than stretching it. The sump holds 1.30 litres, so budget for that volume of quality motorcycle-specific engine oil. Use the viscosity grade the manual specifies, not whatever's on sale.

Fuel system care

Injector systems like the X-MAX 300's hold up well with basic care - decent fuel, an occasional cleaner additive, and draining old fuel before any layup longer than three months.

Valve clearance service

There's no reliable seat-of-the-pants way to tell if a X-MAX 300's valve clearances are in spec - a light top-end tick is the only real warning sign, and by then some wear has already happened. Service records are the only proof.

2020 Yamaha X-MAX 300 - Frequently Asked Questions

What engine does the 2020 Yamaha X-MAX 300 have?

The 2020 Yamaha X-MAX 300 uses a Single cylinder, four-stroke engine with 292 cc of displacement.

How much does the 2020 Yamaha X-MAX 300 weigh?

The 2020 Yamaha X-MAX 300 weighs 179 kg. This is the manufacturer's wet figure.

How much power does the 2020 Yamaha X-MAX 300 make?

The 2020 Yamaha X-MAX 300 produces 29 Nm @ 5750 Revolutions of torque.

What is the fuel tank capacity of the 2020 Yamaha X-MAX 300?

The 2020 Yamaha X-MAX 300 has a 13-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 216-260 km between stops.

Is the 2020 Yamaha X-MAX 300 suitable for shorter riders?

The 2020 Yamaha X-MAX 300 has a seat height of 795 mm. This is a moderate seat height that suits a wide range of rider heights.

What brakes does the 2020 Yamaha X-MAX 300 have?

The 2020 Yamaha X-MAX 300 uses Single disc. Hydraulic. ABS. at the front and Single disc. Hydraulic. ABS. at the rear.

What tyre sizes does the 2020 Yamaha X-MAX 300 use?

The front tyre size on the 2020 Yamaha X-MAX 300 is 120/70-15.

How much oil does the 2020 Yamaha X-MAX 300 take?

The 2020 Yamaha X-MAX 300 takes 1.30 litres of engine oil at a full oil and filter change. Always verify against the dipstick or sight glass after filling.

Yamaha X-MAX 300 Spec Evolution

The Yamaha X-MAX 300 was produced across 4 model years (2017-2020). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2017	2018	2019	2020
Fuel Capacity	13.00 litres / 3.43 gallons	13.00 litres / 3.43 gallons	13.00 litres / 3.43 US gallons	13.00 litres / 3.43 US gallons
Displacement (cc)	292.00 cc	-	292.0 cc	292.0 cc
Oil Capacity (Quarts)	0.09 quarts	0.09 quarts	1.37 US quarts	1.37 US quarts
Frame Type	-	-	Backbone	Underbone
Wheelbase	1,540 mm / 60.6 in.	1,540 mm / 60.6 in.	1540 mm / 60.6 in.	1540 mm / 60.6 in.
Colours	Black, white, bronze	Vivid White	Bronze, Matte Grey	Matt Silver
Final Drive	Belt	Belt	Belt (final drive)	Belt (final drive)
Rims	-	Dunlop® Scoot Smart tyres	Dunlop® Scoot Smart tyres	Dunlop® Scoot Smart tyres

Key Specifications

Engine

Single cylinder, four-stroke

Power

Not published by manufacturer

Torque

29.0 Nm (3.0 kgf-m or 21.4 ft.lbs) @ 5750 Revolutions

Top Speed

Not published by manufacturer

Weight

179.0 kg / 394.6 lbs

Fuel Capacity

13.00 litres / 3.43 US gallons

Full 2020 Yamaha X-MAX 300 Specifications

Colours Matt Silver

Ground Clearance (in.) 5.3 inches

Ground Clearance (mm) 135 mm

Seat Height 795 mm / 31.3 in.

Wheelbase 1540 mm / 60.6 in.

Height 1415 mm / 55.7 in.

Length 2185 mm / 86.0 in.

Width 775 mm / 30.5 in.

Oil Capacity (l) 1.30 litres

Oil Capacity (Quarts) 1.37 US quarts

Fuel Capacity 13.00 litres / 3.43 US gallons

Wet Weight 179.0 kg / 394.6 lbs

Max Torque 29.0 Nm (3.0 kgf-m or 21.4 ft.lbs) @ 5750 Revolutions

Bore x Stroke (in,) 2.8 x 3.0 inches

Bore x Stroke (mm) 70.0 x 75.9 mm

Displacement (cc) 292.0 cc

Displacement (ci) 17.82 cubic inches

Engine Type Single cylinder, four-stroke

Fuel Control Single Overhead Cams (SOHC)

Fuel System Injection

Compression Ratio 10.9:1

Ignition TCI

Starter Electric

Valve System 4

Final Drive Belt (final drive)

Gearbox Automatic

Primary Drive V-Belt Automatic

Frame Type Underbone

Suspension - Front Telescopic forks

Suspension - Rear Unit Swing

Wheel Travel - Front 110 mm / 4.3 in.

Wheel Travel - Rear 84 mm / 3.3 in.

Lighting system LED front and rear lights

Brakes - Front Single disc. Hydraulic. ABS.

Brakes - Rear Single disc. Hydraulic. ABS.

Rims Dunlop® Scoot Smart tyres

Tyres - Front 120/70-15

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
