2023 Yamaha R1 Overview
The 2023 Yamaha R1 is a sport motorcycle built around 998 cc of displacement. Under the tank sits an In-line four, four-stroke engine running Double Overhead Cams/Twin Cam (DOHC) valve actuation, a compression ratio of 13.0:1. The bore and stroke measures 79 x 50.9 mm. 2023 Yamaha R1 delivers 112.4 Nm @ 11500 Revolutions of torque. From a practical standpoint, the 2023 R1 tips the scales at 203.2 kg, carries a 17.03-litre fuel tank, offers a seat height of 855 mm and spans a 1405 mm wheelbase. Scroll down for the complete 2023 Yamaha R1 spec sheet covering every technical detail from suspension travel to tyre sizes.
2023 R1 - Pros & Cons
Strengths
-
🔧
Fuel injection: The fuel injection system delivers crisp throttle response and reliable cold starts regardless of altitude or temperature.
Considerations
-
📏
Tall seat height: The 855 mm seat height will challenge shorter riders - tiptoeing at low speeds is something to factor into your decision.
-
⚙️
Chain final drive upkeep: Chain final drive needs regular cleaning, lubrication and tension checks to get full life out of the sprockets.
Wear Points & Servicing Notes
Fuelling & injector care
Fuelling comes from fuel injection. Systems like this are largely maintenance-free beyond keeping fuel quality decent and injectors clear - a fuel-system cleaner every service interval is cheap insurance.
Valve clearance checks
Double Overhead Cams/Twin Cam (DOHC) valve actuation on the R1 means clearances should be checked at the manufacturer's specified interval - they can tighten as mileage accumulates, and a light top-end tick is usually the first sign.
Brake disc and pad wear
The Double disc. ABS. Hydraulic. Four-piston calipers. front brake gives strong, progressive stopping power. Disc thickness and pad depth are worth checking at every tyre change, since worn pads can score the disc surface.
Suspension condition on used examples
Up front, the R1 runs 43mm KYB® inverted fork; fully adjustable and KYB® piggyback shock, fully adjustable at the rear. On a used example, check fork seals for weeping oil and test the rear linkage for play - seals are a relatively cheap fix but useful when negotiating price.
Final drive maintenance
Final drive is by chain - expect to clean and lube it every few hundred kilometres and check tension regularly; a neglected chain wears the sprockets faster than the chain itself.
Frame & chassis check
The frame is Aluminum Deltabox, diamond - worth a visual check for corrosion or impact damage around the head-stock and swingarm pivot on any used example, since frame damage is far costlier to fix than any service item.
R1 - Buying & Maintenance Guide
What to check before buying
When inspecting a used 2023 Yamaha R1, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained R1 should fire up cleanly and settle to a smooth idle within a few seconds.
Oil and filter changes
Regular oil changes are the single most important maintenance task on any R1. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. The sump holds 4.90 litres, so budget for that volume of quality motorcycle-specific engine oil. Always use the correct viscosity grade as specified in the owner's manual.
Fuel system care
The R1's fuel injection system is durable but benefits from quality fuel and the occasional use of a fuel-system cleaner additive. If the bike has been stored for more than three months, drain and replace the fuel to prevent varnish deposits in the injectors.
Valve clearance service
Check that valve clearances have been adjusted at the correct intervals on any used R1. A bike with clearances out of spec doesn't always feel obviously wrong - but tight clearances accelerate valve seat wear. Ask for service documentation proving it's been done.
2023 Yamaha R1 - Frequently Asked Questions
What engine does the 2023 Yamaha R1 have?
The 2023 Yamaha R1 uses an In-line four, four-stroke engine with 998 cc of displacement.
How much does the 2023 Yamaha R1 weigh?
The 2023 Yamaha R1 weighs 203.2 kg. This is the manufacturer's wet figure.
How much power does the 2023 Yamaha R1 make?
The 2023 Yamaha R1 produces 112.4 Nm @ 11500 Revolutions of torque.
What is the fuel tank capacity of the 2023 Yamaha R1?
The 2023 Yamaha R1 has a 17.03-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 283-340 km between stops.
Is the 2023 Yamaha R1 suitable for shorter riders?
The 2023 Yamaha R1 has a seat height of 855 mm. This is towards the tall end of the spectrum and will require most riders under 175 cm to tiptoe at stops.
What brakes does the 2023 Yamaha R1 have?
The 2023 Yamaha R1 uses Double disc. ABS. Hydraulic. Four-piston calipers. at the front and Single disc. ABS. at the rear.
What tyre sizes does the 2023 Yamaha R1 use?
The front tyre size on the 2023 Yamaha R1 is 120/70-ZR17.
How much oil does the 2023 Yamaha R1 take?
The 2023 Yamaha R1 takes 4.90 litres of engine oil at a full oil and filter change. Always verify against the dipstick or sight glass after filling.
Yamaha R1 Spec Evolution
The Yamaha R1 was produced across 3 model years (2021-2023). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.
| Specification |
2021 |
2022 |
2023 |
| Wet Weight |
201.0 kg / 443.1 lbs |
201.0 kg / 443.1 lbs |
203.2 kg / 448.0 lbs |
| Fuel Capacity |
17.00 litres / 4.49 US gallons |
17.00 litres / 4.49 US gallons |
17.03 litres / 4.50 US gallons |
| Comments |
- |
Ride-by-wire APSG throttle. Launch Control. |
Small windscreen. Power delivery modes. Traction Control. Slide control. Lift control. Launch control. |
| CO2 |
167.0 CO2 g/km. (CO2 - Carbon dioxide emission) |
167.0 CO2 g/km. (CO2 - Carbon dioxide emission) |
157.8 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Frame Type |
Diamond |
Aluminium Deltabox, Diamond |
Aluminum Deltabox, diamond |
| Brakes - Front |
Double disc. Hydraulic |
Double disc. Hydraulic |
Double disc. ABS. Hydraulic. Four-piston calipers. |
| Brakes - Rear |
Single disc. Hydraulic. |
Single disc. Hydraulic. |
Single disc. ABS. |
| Suspension - Front |
Telescopic fork |
KYB telescopic fork |
43mm KYB® inverted fork; fully adjustable |
Key Specifications
Engine
In-line four, four-stroke
Power
Not published by manufacturer
Torque
112.4 Nm (11.5 kgf-m or 82.9 ft.lbs) @ 11500 Revolutions
Top Speed
Not published by manufacturer
Weight
203.2 kg / 448.0 lbs
Fuel Capacity
17.03 litres / 4.50 US gallons
Advertisement
Full 2023 Yamaha R1 Specifications
Comments
Small windscreen. Power delivery modes. Traction Control. Slide control. Lift control. Launch control.
Colours
Icon Blue, Yamaha Black
Warranty
1 Year Limited Factory Warranty
Ground Clearance (mm)
130 mm
Ground Clearance (in.)
5.1 inches
Seat Height
855 mm / 33.7 in.
Wheelbase
1405 mm / 55.3 in.
Height
1166 mm / 45.9 in.
Length
2055 mm / 80.9 in.
Width
691 mm / 27.2 in.
Oil Capacity (Quarts)
5.18 US quarts
Oil Capacity (l)
4.90 litres
Fuel Capacity
17.03 litres / 4.50 US gallons
Wet Weight
203.2 kg / 448.0 lbs
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Engine Type
In-line four, four-stroke
Displacement (ci)
60.90 cubic inches
Displacement (cc)
998.0 cc
CO2
157.8 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
79.0 x 50.9 mm
Bore x Stroke (in,)
3.1 x 2.0 inches
Engine Detail
Crossplane crankshaft technology. Titanium intake valves.
Fuel System
Injection. Fuel Injection with YCC-T and YCC-I
Compression Ratio
13.0:1
Engine Lubrication
Wet sump
Exhaust
Titanium Exhaust
Fuel Consumption
6.80 litres/100 km (14.7 km/l or 34.59 mpg)
Ignition
TCI: Transistor Controlled Ignition
Starter
Electric
Valve System
4
Clutch
Multiplate assist and slipper clutch
Final Drive
Chain (final drive)
Gearbox
6-speed
Frame Type
Aluminum Deltabox, diamond
Suspension - Front
43mm KYB® inverted fork; fully adjustable
Suspension - Rear
KYB® piggyback shock, fully adjustable
Rake
24.0°
Trail
102 mm / 4.0 in.
Wheel Travel - Front
119 mm / 4.7 in.
Wheel Travel - Rear
119 mm / 4.7 in.
Instrumentation
Colour TFT.
Lighting system
All-LED Lighting
Brakes - Front
Double disc. ABS. Hydraulic. Four-piston calipers.
Brakes - Rear
Single disc. ABS.
Rims
Bridgestone Battlax Street RS11 tires. Blue rims.
Tyres - Front
120/70-ZR17
Specifications are compiled from manufacturer documentation and cross-referenced
technical sources, and corrected on an ongoing basis.
