Yamaha MT-125 Specs

2023 • 1 variants

Yamaha has built the MT-125, a naked bike, across 1 variant since 2023. Displacement comes in at 124.7 cc. Torque tops out at 12.4 Nm.

About the Yamaha MT-125

As a Naked bike motorcycle, the Yamaha MT-125 was offered from the 2015 through to the 2023 model year. The technical data presented here covers the complete specification range for this model, including all engine variants, chassis dimensions, suspension travel, brake specifications, and weight figures. This information is useful for prospective buyers, current owners, and mechanics working on the Yamaha MT-125.

Yamaha MT-125 by Year

2023 Yamaha MT-125 View specs →

Spec Evolution

How key specs changed across production years.

Specification	2015	2016	2017	2018	2019	2021	2022	2023
Oil Capacity (Quarts)	0.08 quarts	0.08 quarts	0.08 quarts	0.08 quarts	1.27 US quarts ↑	1.16 US quarts ↓	1.16 US quarts	1.16 US quarts
Oil Capacity (l)	1.20 litres	1.20 litres	1.20 litres	1.20 litres	1.20 litres	1.10 litres ↓	1.10 litres	1.10 litres
Displacement (cc)	124.70 cc	124.70 cc	124.70 cc	124.70 cc	124.7 cc	124.7 cc	124.7 cc	124.7 cc
Comments	-	ABS adds 2 kg.	ABS adds 2 kg.	-	-	-	-	Traction control.
CO2	-	-	49.4 CO2 g/km. (CO2 - Carbon dioxide emission)	49.4 CO2 g/km. (CO2 - Carbon dioxide emission)	49.4 CO2 g/km. (CO2 - Carbon dioxide emission)	49.4 CO2 g/km. (CO2 - Carbon dioxide emission)	48.7 CO2 g/km. (CO2 - Carbon dioxide emission) ↓	48.7 CO2 g/km. (CO2 - Carbon dioxide emission)
Frame Type	Steel Deltabox	Steel Deltabox	Steel Deltabox	Steel Deltabox	Steel Deltabox	Steel deltabox frame and aluminum swingarm	Steel deltabox frame and aluminum swingarm	Steel deltabox with aluminum swingarm
Wheelbase	1,355 mm / 53.3 in.	1,355 mm / 53.3 in.	1,355 mm / 53.3 in.	1,355 mm / 53.3 in.	1355 mm / 53.3 in. ↑	1355 mm / 53.3 in.	1325 mm / 52.2 in. ↓	1325 mm / 52.2 in.
Brakes - Front	Single disc	Single disc. Optional ABS.	Single disc. Optional ABS.	Single disc. Optional ABS.	Single disc. Optional ABS.	Single disc	Single disc	Single disc
Fuel Capacity	11.50 litres / 3.04 gallons	11.50 litres / 3.04 gallons	11.50 litres / 3.04 gallons	11.50 litres / 3.04 gallons	11.50 litres / 3.04 US gallons	10.00 litres / 2.64 US gallons ↓	11.00 litres / 2.91 US gallons ↑	11.00 litres / 2.91 US gallons
Brakes - Rear	Single disc	Single disc. Optional ABS.	Single disc. Optional ABS.	Single disc. Optional ABS.	Single disc. Optional ABS.	Single disc	Single disc	Single disc
Suspension - Front	Upside-down telescopic fork, 41 mm	Upside-down telescopic fork, 41 mm	Upside-down telescopic fork, 41 mm	Upside-down telescopic fork, 41 mm	Upside-down telescopic fork, 41 mm	Upside-down telescopic fork, 41 mm	Upside-down telescopic fork, 41 mm	Upside-down telescopic fork, 41 mm
Suspension - Rear	Linked monoshock with spring preload adjustment	Linked monoshock with spring preload adjustment	Linked monoshock with spring preload adjustment	Linked monoshock with spring preload adjustment	Linked monoshock with spring preload adjustment	Swingarm	Swingarm	Swingarm
Colours	Red, grey, blue	Silver, grey, blue	Silver, black, blue	Night Fluo, Black, Blue	Tech Black, Ice Fluo	Tech Black, Ice Fluo, Icon Blue	Tech Black, Cyan Storm, Icon Blue	Tech Black, Cyan Storm, Icon Blue
Clutch	Wet, multiple-disc coil spring	Wet, multiple-disc coil spring	Wet, multiple-disc coil spring	Wet, multiple-disc coil spring	Wet, multiple-disc coil spring	Assist and slipper clutch	Assist and slipper clutch	Assist and slipper clutch
Final Drive	Chain	Chain	Chain	Chain	Chain (final drive)	Chain (final drive)	Chain (final drive)	Chain (final drive)
Height	1,040 mm / 40.9 in.	1,040 mm / 40.9 in.	1,040 mm / 40.9 in.	1,040 mm / 40.9 in.	1040 mm / 40.9 in. ↑	1065 mm / 41.9 in. ↑	1065 mm / 41.9 in.	1065 mm / 41.9 in.
Length	1,955 mm / 77.0 in.	1,955 mm / 77.0 in.	1,955 mm / 77.0 in.	1,955 mm / 77.0 in.	1955 mm / 77.0 in. ↑	1960 mm / 77.2 in. ↑	1960 mm / 77.2 in.	1960 mm / 77.2 in.
Wet Weight	138.0 kg / 304.2 lbs	138.0 kg / 304.2 lbs	138.0 kg / 304.2 lbs	140.0 kg / 308.6 lbs ↑	140.0 kg / 308.6 lbs	140.0 kg / 308.6 lbs	142.0 kg / 313.1 lbs ↑	142.0 kg / 313.1 lbs
Width	740 mm / 29.1 in.	740 mm / 29.1 in.	740 mm / 29.1 in.	740 mm / 29.1 in.	740 mm / 29.1 in.	800 mm / 31.5 in. ↑	800 mm / 31.5 in.	800 mm / 31.5 in.
Rake	25.0°	25.0°	25.0°	25.0°	25.0°	26.0° ↑	26.0°	26.0°
Instrumentation	Digital LED	LCD instrument panel	LCD instrument panel	LCD instrument panel	LCD instrument panel	LCD instrument panel	LCD instrument panel	5’’ TFT display with smartphone connectivity
Lighting system	-	-	-	-	-	LED headlight	LED headlight	Dual eye positions lights; LED headlight
Fuel Consumption	-	-	2.13 litres/100 km (46.9 km/l or 110.43 mpg)	2.13 litres/100 km (46.9 km/l or 110.43 mpg)	2.13 litres/100 km (46.9 km/l or 110.43 mpg)	2.13 litres/100 km (46.9 km/l or 110.43 mpg)	2.10 litres/100 km (47.6 km/l or 112.01 mpg) ↓	2.10 litres/100 km (47.6 km/l or 112.01 mpg)
Trail	89 mm / 3.5 in.	89 mm / 3.5 in.	89 mm / 3.5 in.	89 mm / 3.5 in.	89 mm / 3.5 in.	95 mm / 3.7 in. ↑	95 mm / 3.7 in.	95 mm / 3.7 in.
Wheel Travel - Front	137 mm / 5.4 in.	137 mm / 5.4 in.	137 mm / 5.4 in.	137 mm / 5.4 in.	137 mm / 5.4 in.	130 mm / 5.1 in. ↓	130 mm / 5.1 in.	130 mm / 5.1 in.
Wheel Travel - Rear	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.	130 mm / 5.1 in.	114 mm / 4.5 in. ↓	110 mm / 4.3 in. ↓	110 mm / 4.3 in.
Max Torque	12.40 Nm (1.3 kgf-m or 9.1 ft.lbs) @ 6900 Revolutions	12.40 Nm (1.3 kgf-m or 9.1 ft.lbs) @ 6900 Revolutions	12.40 Nm (1.3 kgf-m or 9.1 ft.lbs) @ 6900 Revolutions	12.40 Nm (1.3 kgf-m or 9.1 ft.lbs) @ 6900 Revolutions	12.4 Nm (1.3 kgf-m or 9.1 ft.lbs) @ 8000 Revolutions	11.5 Nm (1.2 kgf-m or 8.5 ft.lbs) @ 8000 Revolutions ↓	11.5 Nm (1.2 kgf-m or 8.5 ft.lbs) @ 8000 Revolutions	11.5 Nm (1.2 kgf-m or 8.5 ft.lbs) @ 8000 Revolutions
