2017 Yamaha FZ16 Overview
Yamaha FZ16 is a sport motorcycle, displacing 153 cc. Power comes from a Single cylinder, four-stroke engine running Single Overhead Cams (SOHC) valve actuation, a compression ratio of 9.5:1. Bore and stroke come in at 58 x 57.9 mm. On the performance side, it delivers 14 Nm @ 6000 Revolutions of torque. On the road, the 2017 FZ16 tips the scales at 137 kg, carries a 12-litre fuel tank, offers a seat height of 800 mm and spans a 1,335 mm wheelbase. That's roughly 65.3 kg lighter than the average sport motorcycle in our database. The full 2017 Yamaha FZ16 spec sheet below covers every technical detail, from suspension travel to tyre sizes.
2017 FZ16 - Pros & Cons
Strengths
-
✓
Factory engineering: Yamaha built the FZ16 around a straightforward, purposeful specification rather than chasing any single standout feature.
Considerations
-
🔧
Carburetor fuelling: Expect to spend more time keeping the carbs in tune, especially after long storage periods or a change in altitude.
-
⛽
Modest fuel capacity: Range between stops is limited by the 12-litre tank - plan fuel stops accordingly on longer routes.
-
⚙️
Chain final drive upkeep: Budget time for routine chain maintenance - it's cheap to replace but needs consistent attention to avoid premature sprocket wear.
Wear Points & Servicing Notes
Carburetor maintenance
Carburetors on the FZ16 need periodic attention - pilot jets and float needles are the first parts to gum up after the bike sits, and the first thing to check if idle or throttle response degrades.
Valve clearance checks
With Single Overhead Cams (SOHC) valve gear, the FZ16 needs periodic clearance checks; caught early they're a cheap adjustment, left unchecked they accelerate valve seat wear.
Brake disc and pad wear
Braking up front comes from Single disc - solid stopping power, with disc and pad wear best checked on the same schedule as tyre changes.
Suspension condition on used examples
The FZ16's suspension runs Telescopic Hydraulic at the front. The rear uses Ajustable, Hydraulic Shock Absorber. Fork-seal condition and rear linkage play are the two things worth checking before buying used.
Final drive maintenance
The FZ16 uses chain final drive, which is cheap to replace but needs regular cleaning, lubrication and tension checks to get a full service life out of the sprockets.
Frame & chassis check
Built around a Diamond, the FZ16's chassis is straightforward to inspect: look for corrosion, cracks or repair welds around stress points like the head-stock and swingarm mounts.
Low-speed handling
137 kg keeps the FZ16 easy to move around in tight spaces, car parks and on the stand alike.
FZ16 - Buying & Maintenance Guide
What to check before buying
Before handing over money for a used 2017 Yamaha FZ16, cover the fundamentals: service book and oil change history, chain and sprocket wear, and any sign of oil weeping around the casings. Cold-starting it yourself tells you a lot - a healthy FZ16 should catch quickly and settle into a smooth idle.
Oil and filter changes
Nothing protects a FZ16's engine like disciplined oil changes - stay on the manufacturer's schedule (roughly every 6,000 km or annually). The sump holds 1.20 litres, so budget for that volume of quality motorcycle-specific engine oil. Match the viscosity grade to what the owner's manual specifies, not what's cheapest.
Carburetor upkeep
Deposits in the carbs are the usual culprit behind poor running on a stored FZ16 - strip and clean the float bowls before the first start. Pilot jets clog first and get overlooked most, so make a point of checking them.
Valve clearance service
Valve clearances are easy to overlook on a used FZ16 since a bike out of spec doesn't always feel obviously wrong - but the wear it causes is real. Ask the seller for documentation before assuming it's been done.
2017 Yamaha FZ16 - Frequently Asked Questions
What engine does the 2017 Yamaha FZ16 have?
The 2017 Yamaha FZ16 uses a Single cylinder, four-stroke engine with 153 cc of displacement.
How much does the 2017 Yamaha FZ16 weigh?
The 2017 Yamaha FZ16 weighs 137 kg. This is the manufacturer's wet figure.
How much power does the 2017 Yamaha FZ16 make?
The 2017 Yamaha FZ16 produces 14 Nm @ 6000 Revolutions of torque.
What is the fuel tank capacity of the 2017 Yamaha FZ16?
The 2017 Yamaha FZ16 has a 12-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 200-240 km between stops.
Is the 2017 Yamaha FZ16 suitable for shorter riders?
The 2017 Yamaha FZ16 has a seat height of 800 mm. This is a moderate seat height that suits a wide range of rider heights.
What brakes does the 2017 Yamaha FZ16 have?
The 2017 Yamaha FZ16 uses Single disc at the front and Expanding brake at the rear.
What tyre sizes does the 2017 Yamaha FZ16 use?
The 2017 Yamaha FZ16 runs 100/80-17 front and 140/60-17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.
How much oil does the 2017 Yamaha FZ16 take?
The 2017 Yamaha FZ16 takes 1.20 litres of engine oil at a full oil and filter change. Always verify against the dipstick or sight glass after filling.
Yamaha FZ16 Spec Evolution
The Yamaha FZ16 was produced across 4 model years (2008-2018). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.
| Specification |
2008 |
2011 |
2017 |
2018 |
| Wet Weight |
134.0 kg / 295.4 lbs |
137.0 kg / 302.0 lbs |
137.0 kg / 302.0 lbs |
137.0 kg / 302.0 lbs |
| Engine Type |
Single cylinder |
Single cylinder, four-stroke |
Single cylinder, four-stroke |
Single cylinder, four-stroke |
| Seat Height |
- |
790 mm / 31.1 in. |
800 mm / 31.5 in. |
800 mm / 31.5 in. |
| Fuel Control |
SOHC |
SOHC |
Single Overhead Cams (SOHC) |
Single Overhead Cams (SOHC) |
| Ground Clearance (in.) |
- |
9.7 inches |
6.3 inches |
6.3 inches |
| Ground Clearance (mm) |
- |
246 mm |
160 mm |
160 mm |
| Frame Type |
Macho |
Diamond |
Diamond |
Diamond |
| Brakes - Front |
Single disc |
Single disc |
Single disc |
Single disc. Hydraulic |
Key Specifications
Engine
Single cylinder, four-stroke
Power
Not published by manufacturer
Torque
14.00 Nm (1.4 kgf-m or 10.3 ft.lbs) @ 6000 Revolutions
Top Speed
Not published by manufacturer
Weight
137.0 kg / 302.0 lbs
Fuel Capacity
12.00 litres / 3.17 gallons
Advertisement
Full 2017 Yamaha FZ16 Specifications
Comments
Sold in India.
Colours
Red
Ground Clearance (in.)
6.3 inches
Ground Clearance (mm)
160 mm
Seat Height
800 mm / 31.5 in.
Wheelbase
1,335 mm / 52.6 in.
Height
1,975 mm / 77.8 in.
Length
1,975 mm / 77.8 in.
Width
1,975 mm / 77.8 in.
Oil Capacity (l)
1.20 litres
Oil Capacity (Quarts)
0.08 quarts
Dry Weight
126 kg / 277.8 lbs
Fuel Capacity
12.00 litres / 3.17 gallons
Wet Weight
137.0 kg / 302.0 lbs
Bore x Stroke (in,)
2.3 x 2.3 inches
Bore x Stroke (mm)
58.0 x 57.9 mm
Displacement (cc)
153.00 cc
Displacement (ci)
9.34 cubic inches
Engine Type
Single cylinder, four-stroke
Fuel Control
Single Overhead Cams (SOHC)
Fuel System
Carburettor
Compression Ratio
9.5:1
Engine Lubrication
Wet sump
Ignition
CDI
Starter
Electric
Clutch
Constant mesh wet multiplate
Final Drive
Chain
Gearbox
5-speed
Frame Type
Diamond
Suspension - Front
Telescopic Hydraulic
Suspension - Rear
Ajustable, Hydraulic Shock Absorber
Rake
26.0°
Trail
98 mm / 3.9 in.
Brakes - Rear Diameter (in.)
5.1 inches
Brakes - Rear Diameter (mm)
130 mm
Brakes - Front
Single disc
Brakes - Rear
Expanding brake (drum brake)
Tyres - Front
100/80-17
Tyres - Rear
140/60-17
Specifications are compiled from manufacturer documentation and cross-referenced
technical sources, and corrected on an ongoing basis.
