Key Specifications
Engine
Four stroke, single cylinder, reverse inclined, SOHC, 4 valves
Power
Sport & Track mode: 25.4 kW / 34 hp @ 9700 rpm Urban & Rain mode:19.2 kW / 25.8 hp @ 7600 rpm
Torque
Sport & Track mode: 27.3 Nm / 20.1 lb-ft @ 7700 rpm Urban & Rain mode: 25 Nm / 18.4 lb-ft @ 6700 rpm
Fuel Capacity
11 Litres / 2.9 US gal
Advertisement
Full 2025 TVS Apache RR 310 Specifications
Year
2025
Make Model
TVS Apache RR 310
Seat Height
810 mm / 32 in
Wheelbase
1365 mm / 53.7 in
Ground Clearance
180 mm / 7 in
Height
1135 mm / 44.7 in
Length
2001 mm / 78.8 in
Width
786 mm / 30.9 in
Wet Weight (kg)
174
Fuel Capacity
11 Litres / 2.9 US gal
Wet Weight
174 kg / 384 lbs
Displacement
312.2 cc / 19.1 cu in
Engine Detail
Four stroke, single cylinder, reverse inclined, SOHC, 4 valves
Bore x Stroke
80 x 62.1 mm
Compression Ratio
10.9:1
Cooling System
Liquid Cooled
Fuel Induction
Bosh electronic fuel injection, closed-loop
Ignition
Dynamically controlled integrated high energy
Starter
Electric
Clutch
Wet, multi-plate, RT slipper clutch optional
Transmission / Drive
6-Speed, constant-mesh
Frame Type
Steel Trellis, split chassis
Suspension - Front
41mm inverted cartridge telescopic fork
Suspension - Rear
2-arm aluminium die-cast swing-arm, mono tube floating piston gas assisted shock
Wheel Travel - Front
140 mm / 5.5 in
Wheel Travel - Rear
131 mm / 5.5 in
Brakes - Front
Single 300mm disc, 4 piston caliper, ABS
Brakes - Rear
Single 240mm disc, single piston caliper, ABS
Tyres - Front
110/70-ZR17 M/C 54W
Tyres - Rear
150/60-ZR17 M/C 66W
Wheels
5-Spoke, light alloy die-cast
Wheels - Front
3.0 x 17
Wheels - Rear
4.0 x 17
