2014 Triumph Speed Triple R Specifications

Name: 2014 Triumph Speed Triple R
Brand: Triumph

Sport • Specs last verified 13 July 2026

No images available

Tap to enlarge

2014 Triumph Speed Triple R Overview

For 2014, Triumph offers the Speed Triple R as a sport motorcycle with 1050 cc on tap. The 2014 Triumph Speed Triple R is built around a Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder engine, a compression ratio of 12.0:1. Out on the road, the Speed Triple R delivers 99 kW @ 9400 rpm of peak power and 111 Nm @ 7750rpm of torque. Flat out, it's quoted at 253.8 km/h/ 157.7 mph. In everyday use, the 2014 Speed Triple R tips the scales at 212 kg, carries a 17.5-litre fuel tank, offers a seat height of 825 mm and spans a 1435 mm wheelbase. That's roughly 9.3 kg heavier than the average sport motorcycle in our database. Every technical detail, from suspension travel to tyre sizes, is covered in the full 2014 Triumph Speed Triple R spec sheet below.

2014 Speed Triple R - Pros & Cons

Strengths

Strong power output: Peak output on the Speed Triple R is 99 kW @ 9400 rpm and 111 Nm @ 7750rpm of torque - strong numbers for what it is.
Fuel injection: No choke, no jetting, no altitude compensation to think about - fuel injection just works across a wider range of conditions than carburetion.

Considerations

Tall seat height: A 825 mm seat puts flat-footing out of reach for a lot of riders - sit on it in person before committing.
Chain final drive upkeep: A chain drivetrain is the most common setup in its class, but it's also the one that demands the most regular hands-on maintenance.

Wear Points & Servicing Notes

Cooling system servicing

With Liquid-cooled, thermal management is largely automatic, but the coolant has a service life of its own - replace it on the manufacturer's interval to protect the water passages and thermostat.

Fuelling & injector care

Fuelling on the Speed Triple R comes from Multipoint sequential electronic fuel injection with SAI. Cold starts and throttle response stay consistent across altitude and temperature, the main practical edge over a carbureted equivalent.

Brake disc and pad wear

2 x 320 mm Discs, 4 piston radial monoblock calipers, Brembo, switchable ABS up front provides the primary stopping power; inspect disc thickness and pad wear at each tyre change to catch scoring before it becomes a rotor replacement.

Suspension condition on used examples

Suspension duties are handled by Öhlins 43 mm NIX30 upside down forks with adjustable rebound and compression damping, up front and Öhlins TTX36 twin tube monoshock with rebound and compression damping at the rear. Weeping fork seals aren't a dealbreaker on a used bike, but they're a fair basis for negotiating price.

Final drive maintenance

Chain final drive on the Speed Triple R means routine lubing and tension checks are part of ownership - skip them and sprocket wear accelerates noticeably.

Frame & chassis check

The Aluminium beam twin-spar chassis holds up well with normal use; on a used bike it's still worth checking the head-stock and swingarm pivot area for impact damage or corrosion.

Speed Triple R - Buying & Maintenance Guide

What to check before buying

A pre-purchase check on the 2014 Triumph Speed Triple R should cover the same ground every time: service history, chain and sprocket condition, and any oil seepage around the casings. Start it from cold if you can - a well-kept Speed Triple R settles to a smooth idle within seconds.

Oil and filter changes

Oil changes are the cheapest insurance you can buy for a Speed Triple R's engine - keep to the manufacturer's interval rather than stretching it. Use the viscosity grade the manual specifies, not whatever's on sale.

Fuel system care

Injector systems like the Speed Triple R's hold up well with basic care - decent fuel, an occasional cleaner additive, and draining old fuel before any layup longer than three months.

2014 Triumph Speed Triple R - Frequently Asked Questions

What engine does the 2014 Triumph Speed Triple R have?

The 2014 Triumph Speed Triple R uses a Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder engine with 1050 cc of displacement. It is liquid-cooled.

What is the top speed of the 2014 Triumph Speed Triple R?

The 2014 Triumph Speed Triple R has a factory-quoted top speed of 253.8 km/h/ 157.7 mph. Real-world speeds vary depending on rider weight, conditions and state of tune.

How much does the 2014 Triumph Speed Triple R weigh?

The 2014 Triumph Speed Triple R weighs 212 kg. This is the manufacturer's wet figure.

How much power does the 2014 Triumph Speed Triple R make?

The 2014 Triumph Speed Triple R produces 99 kW @ 9400 rpm of power and 111 Nm @ 7750rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2014 Triumph Speed Triple R?

The 2014 Triumph Speed Triple R has a 17.5-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 291-350 km between stops.

Is the 2014 Triumph Speed Triple R suitable for shorter riders?

The 2014 Triumph Speed Triple R has a seat height of 825 mm. This is towards the tall end of the spectrum and will require most riders under 175 cm to tiptoe at stops.

What brakes does the 2014 Triumph Speed Triple R have?

The 2014 Triumph Speed Triple R uses 2 x 320 mm Discs, 4 piston radial monoblock calipers, Brembo, switchable ABS at the front and Single 255 mm disc, 2 piston caliper, Nissen, switchable ABS at the rear.

What tyre sizes does the 2014 Triumph Speed Triple R use?

The 2014 Triumph Speed Triple R runs 120/70 ZR 17 front and 190/55 ZR 17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2014 Triumph Speed Triple R have?

The 2014 Triumph Speed Triple R is fitted with a 6 Speed transmission.

Triumph Speed Triple R Spec Evolution

The Triumph Speed Triple R was produced across 6 model years (2012-2017). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification	2012	2013	2014	2015	2016	2017
Max Power	99 kW / 133 hp @ 9400 rpm	99 kW / 133 hp @ 9400 rpm	99 kW / 133 hp @ 9400 rpm	99 kW / 133 hp @ 9400 rpm	102.9 kW / 138 hp @ 9500 rpm	102.9 kW / 138 hp @ 9500 rpm
Wet Weight	212 kg / 466lbs	212 kg / 466 lbs	212 kg / 466 lbs	214 kg / 472 lbs	-	-
Dry Weight	-	-	-	186 kg / 410 lbs	192 kg / 423 lbs	192 kg / 423 lbs
Top Speed	253.8 km/h/ 157.7 mph	253.8 km/h/ 157.7 mph	253.8 km/h/ 157.7 mph	253.8 km/h / 157.7 mph	-	-
Seat Height	825 mm / 32.5 in	825 mm / 32.5 in	825 mm / 32.5 in	825 mm / 32.5in	825.5 mm / 32.5 in	825.5 mm / 32.5 in
Fuel Capacity	17.5 Litres / 4.6 US gal / 3.8 Imp gal	17.5 Litres / 4.6 US gal / 3.8 Imp gal	17.5 Litres / 4.6 US gal / 3.8 Imp gal	17.5 Litres / 4.6 US gal / 3.8 Imp gal	15.5 Litres / 4.1 US gal / 3.4 Imp gal	15.5 Litres / 4.1 US gal / 3.4 Imp gal
Frame Type	Aluminium beam twin-spar	Aluminium beam twin-spar	Aluminium beam twin-spar	Aluminium beam twin-spar, single sided swingarm, aluminium alloy	Aluminium beam twin-spar, single-sided swingarm, aluminium alloy with eccentric chain adjuster	Aluminium beam twin-spar, single-sided swingarm, aluminium alloy with eccentric chain adjuster
Displacement	1050 cc / 64.1 cub in	1050 cc / 64.1 cub in	1050 cc / 64.1 cub in	1050 cc / 64.1 cub in	1050 cc / 64.1 cu in	1050 cc / 64.1 cu in

Key Specifications

Engine

Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder

Power

99 kW / 133 hp @ 9400 rpm

Torque

111 Nm / 11.3 kgf-m / 82 ft.lbs @ 7750rpm

Top Speed

253.8 km/h/ 157.7 mph

Weight

212 kg / 466 lbs

Fuel Capacity

17.5 Litres / 4.6 US gal / 3.8 Imp gal

Full 2014 Triumph Speed Triple R Specifications

Year 2014

Make Model Triumph Speed Triple R

Seat Height 825 mm / 32.5 in

Wheelbase 1435 mm / 56.5in

Height without mirrors 1110mm / 43.7in

Length 2100 mm / 82.6in

Width (handlebars) 795 mm / 31.3in

Fuel Capacity 17.5 Litres / 4.6 US gal / 3.8 Imp gal

Wet Weight 212 kg / 466 lbs

Top Speed 253.8 km/h/ 157.7 mph

Max Power 99 kW / 133 hp @ 9400 rpm

Max Torque 111 Nm / 11.3 kgf-m / 82 ft.lbs @ 7750rpm

Standing Start ¼ Mile 11.3 sec

Displacement 1050 cc / 64.1 cub in

Engine Detail Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder

Bore x Stroke 79 x 71.4 mm

Compression Ratio 12.0:1

Cooling System Liquid-cooled

Engine Oil Specification 10W/40 Synthetic

Exhaust Stainless Steel 3 into 1 into 2, twin high level stainless steel silencers

Fuel Consumption 5.95 L/100 km / 16.8 km/l / 39.5 US mpg / 47.5 Imp mpg

Fuel Induction Multipoint sequential electronic fuel injection with SAI

Ignition Digital°inductive type via electronic engine management system

Starter Electric

Clutch Wet, multi-plate

Final Drive X ring chain

Transmission / Drive 6 Speed

Frame Type Aluminium beam twin-spar

Suspension - Front Öhlins 43 mm NIX30 upside down forks with adjustable rebound and compression damping,

Suspension - Rear Öhlins TTX36 twin tube monoshock with rebound and compression damping

Rake 22.8°

Trail 90.9 mm / 3.6 in

Wheel Travel - Front 120 mm / 4.7 in

Wheel Travel - Rear 130 mm / 5.1 in

Brakes - Front 2 x 320 mm Discs, 4 piston radial monoblock calipers, Brembo, switchable ABS

Brakes - Rear Single 255 mm disc, 2 piston caliper, Nissen, switchable ABS

Tyres - Front 120/70 ZR 17

Tyres - Rear 190/55 ZR 17

Wheels - Front Forged aluminium alloy 5 spoke, 17 x 3.5 in

Wheels - Rear Forged aluminium alloy 5 spoke, 17 x 6.0 in

Specifications are compiled from manufacturer documentation and cross-referenced technical sources, and corrected on an ongoing basis. Spot an error? Let us know.
