Key Specifications
Fuel Capacity
1.08 gallons
Advertisement
Full 2003 Suzuki JR80 Specifications
Ground Clearance (in.)
7.7 inches
Ground Clearance (mm)
195 mm
Height (in.)
36.0 inches
Height (mm)
915 mm
Length (in.)
60.6 inches
Length (mm)
1,540 mm
Seat Height (in.)
27.0 inches
Seat Height (mm)
685 mm
Wheelbase (in.)
41.3 inches
Wheelbase (mm)
1,050 mm
Width (in.)
28.7 inches
Width (mm)
730 mm
Dry Weight (kg)
58
Dry Weight (lbs.)
127.9 pounds
Fuel Capacity (gal.)
1.08 gallons
Fuel Capacity (l)
4.10 litres
Bore x Stroke (in,)
1.9 x 1.7 inches
Bore x Stroke (mm)
49.0 x 42.0 mm
Displacement (cc)
79.00 cc
Displacement (ci)
4.82 cubic inches
Engine Type
Single cylinder
Stroke
2
Fuel System
Carburettor
Compression Ratio
6.8:1
Final Drive
Chain
Gearbox
5-speed
Brakes - Front
Expanding brake (drum brake)
Brakes - Rear
Expanding brake (drum brake)
Tyres - Front
2.50-14-4pr
Tyres - Rear
3.00-12-4pr
