Suzuki DR-Z 400SM Specs

2009 - 2010 • 1 variants

The Suzuki DR-Z 400SM is a supermotard produced from 2009 to 2010 across 1 variant. It is powered by a four stroke, single cylinder, dohc, 4 valve displacing 396.00 cc. Peak power output is 39.7 hp. Peak torque is 39 Nm.

About the Suzuki DR-Z 400SM

The Suzuki DR-Z 400SM is a All-Round motorcycle from Suzuki, produced from 2005 to 2023. This page provides a comprehensive technical reference for the Suzuki DR-Z 400SM, covering all available specification data including engine configuration, displacement, power output, dimensions, weight, and chassis details. Use the year selector above to find specifications for a specific model year. All data is sourced from manufacturer specifications and is intended as a technical reference for riders, mechanics, and enthusiasts.

AdSense - 728Ã90

Suzuki DR-Z 400SM by Year

2010 Suzuki DR-Z 400SM View specs →

Spec Evolution

How key specs changed across production years.

Specification	2006	2008	2010	2012	2014	2016	2018	2019	2020	2021	2022	2023
CO2	-	-	-	58.0 CO2 g/km. (CO2 - Carbon dioxide emission)	30.9 CO2 g/km. (CO2 - Carbon dioxide emission) ↓	-	-	-	-	123.0 CO2 g/km. (CO2 - Carbon dioxide emission)	123.0 CO2 g/km. (CO2 - Carbon dioxide emission)	123.0 CO2 g/km. (CO2 - Carbon dioxide emission)
Displacement (cc)	398.00 cc	398.00 cc	396.00 cc ↓	-	398.00 cc	-	-	-	398.0 cc	398.0 cc	398.0 cc	398.0 cc
Displacement (ci)	24.29 cubic inches	24.29 cubic inches	24.16 cubic inches ↓	-	24.29 cubic inches	-	-	-	24.29 cubic inches	24.29 cubic inches	24.29 cubic inches	24.29 cubic inches
Ground Clearance (mm)	300 mm	260 mm ↓	260 mm	260 mm	260 mm	260 mm	260 mm	260 mm	260 mm	260 mm	260 mm	260 mm
Ground Clearance (in.)	11.8 inches	10.2 inches ↓	10.2 inches	10.2 inches	10.2 inches	10.2 inches	10.2 inches	10.2 inches	10.2 inches	10.2 inches	10.2 inches	10.2 inches
Fuel Control	DOHC	DOHC	DOHC	DOHC	DOHC	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)
Engine Type	Single cylinder	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke
Brakes - Rear Diameter (mm)	-	-	-	240 mm	200 mm ↓	240 mm ↑	240 mm	-	-	-	-	-
Brakes - Rear Diameter (in.)	-	-	-	9.4 inches	7.9 inches ↓	9.4 inches ↑	9.4 inches	-	-	-	-	-
Brakes - Front Diameter (mm)	-	-	-	300 mm	160 mm ↓	300 mm ↑	300 mm	-	-	-	-	-
Brakes - Front Diameter (in.)	-	-	-	11.8 inches	6.3 inches ↓	11.8 inches ↑	11.8 inches	-	-	-	-	-
Storage	-	-	-	20L	Luggage rack	-	-	-	-	-	-	-
Oil Capacity (l)	-	-	-	0.70 litres	0.80 litres ↑	-	-	-	-	-	-	-
Comments	-	-	-	-	Chinese ATV.	-	-	-	-	-	-	-
Frame Type	Chrome-moly steel frame, single front down tube	Http	Chrome-moly steel frame, single front down tube	Chrome-moly steel frame, single front down tube	Chrome-moly steel frame	Chrome-moly steel frame	Chrome-moly steel frame, single front down tube	Chrome-moly steel frame, single front down tube	Chrome-moly steel frame. Bolt-on aluminum sub-frame.	Chrome-moly steel frame. Bolt-on aluminum sub-frame.	Chrome-moly steel frame. Bolt-on aluminum sub-frame.	Chrome-moly steel frame. Bolt-on aluminum sub-frame.
Seat Height	890 mm / 35.0 in	890 mm / 35.0 in.	890 mm / 35.0 in	890 mm / 35.0 in	890 mm / 35.0 in.	890 mm / 35.0 in	890 mm / 35.0 in	890 mm / 35.0 in	890 mm / 35.0 in.	890 mm / 35.0 in.	890 mm / 35.0 in.	890 mm / 35.0 in.
Dry Weight	137 kg / 302 lbs	137 kg / 302 lbs	137 kg / 302 lbs	137 kg / 302 lbs	80 kg / 176.4 lbs ↓	137 kg / 302 lbs ↑	137 kg / 302 lbs	137 kg / 302 lbs	-	-	-	-
Brakes - Front	Single 300 mm floating disc, 2 piston caliper	Single 310 mm floating disc, 2 piston caliper ↑	Single disc	Single 310 mm floating disc, 2 piston caliper	Single 310 mm floating disc, 2 piston caliper	Single 310 mm floating disc, 2 piston caliper	Single 310 mm floating disc, 2 piston caliper	Single 310 mm floating disc, 2 piston caliper	Single disc. Floating rotor	Single disc. Floating rotor	Single disc. Floating rotor	Single disc. Floating rotor
Wheelbase	1460 mm / 57.5 in	1460 mm / 57.5 in	1,460 mm / 57.5 in. ↓	1460 mm / 57.5 in ↑	1460 mm / 57.5 in	1460 mm / 57.5 in	1460 mm / 57.5 in	1460 mm / 57.5 in	1460 mm / 57.5 in.	1460 mm / 57.5 in.	1460 mm / 57.5 in.	1460 mm / 57.5 in.
Brakes - Rear	Single 240mm disc, 1 piston caliper	Single disc	Single 240mm disc, 1 piston caliper	Single 240mm disc, 1 piston caliper	Single disc	Single disc	Single 240mm disc, 1 piston caliper	Single 240mm disc, 1 piston caliper	Single disc	Single disc	Single disc	Single disc
Fuel Capacity	10 Litres / 2.6 US gal / 2.2 Imp gal	10.00 litres / 2.64 gallons	10 Litres / 2.6 US gal / 2.2 Imp gal	10 Litres / 2.6 US gal / 2.2 Imp gal	9.84 litres / 2.60 gallons ↓	10 Litres / 2.6 US gal / 2.2 Imp gal ↑	10 Litres / 2.6 US gal / 2.2 Imp gal	10 Litres / 2.6 US gal / 2.2 Imp gal	10.00 litres / 2.64 US gallons	10.00 litres / 2.64 US gallons	10.00 litres / 2.64 US gallons	10.00 litres / 2.64 US gallons
Suspension - Front	Inverted telescopic, oil-damped, adjustable compression and rebound damping	Telescopic, 49 mm, oil-damped, 11-way compression damping, adjustable spring preload	Inverted telescopic, coil spring, oil damped	Telescopic, 49 mm, oil-damped, 11-way compression damping, adjustable spring preload	Telescopic, 49 mm, oil-damped, 11-way compression damping, adjustable spring preload	Inverted telescopic, coil spring, oil damped	Inverted telescopic, coil spring, oil damped	Telescopic, 49 mm, oil-damped, 11-way compression damping, adjustable spring preload	Showa inverted telescopic, coil spring, oil damped	Showa inverted telescopic, coil spring, oil damped	Inverted telescopic, coil spring, oil damped, adjustable damping force	Inverted telescopic, coil spring, oil damped, adjustable damping force
Suspension - Rear	Link-type, fully-adjustable spring preload, adjustable compression and rebound damping	Link-type, fully-adjustable spring preload, adjustable compression and rebound damping	Link-type, fully adjustable spring preload, 26-way compression damping	Link-type, fully adjustable spring preload, 26-way compression damping	Link-type, fully adjustable spring preload, 26-way compression damping	Link-type, fully adjustable spring preload, 26-way compression damping	Link type, coil spring, oil damped, adjustable spring preload	Link type, coil spring, oil damped, adjustable spring preload and damping force	Link type, coil spring, oil damped, adjustable spring preload	Link type, coil spring, oil damped, adjustable spring preload	Link type, coil spring, oil damped, adjustable spring preload	Link type, coil spring, oil damped, adjustable spring preload
Top Speed	145 km/h / 90 mph	145 km/h / 90 mph	145 km/h / 90 mph	145 km/h / 90 mph	45.0 km/h / 28.0 mph ↓	145 km/h / 90 mph ↑	145 km/h / 90 mph	145 km/h / 90 mph	-	-	-	-
Fuel System	Carburettor	Carburettor. MikuniT BSR36	Carburettor. Mikuni	Carburettor. Mikuni BSR36 CV-type. 6-liter airbox.	Carburettor. MIKUNI BSR36, single	Carburettor. Mikuni BSR36, single	Carburettor. Mikuni BSR36, single	Carburettor. Mikuni BSR36, single	Carburettor. Mikuni BSR36, single	Carburettor. Mikuni BSR36, single	Carburettor. Mikuni BSR36, single	Carburettor. Mikuni BSR36, single
Colours	Yellow, Black	Black, White	Black, White	Black, White	White/Black	Solid Special White/Solid Black	Solid Black	Solid Special White No.2 with Red or Solid White No.2 with Blue	Solid Iron Gray, Solid Special White No. 2 ↑	Solid Black, Solid Special White	Solid Special White	Grand Blue /Solid Black, Solid Special White
Clutch	Wet, multiple discs, cable operated	Wet, multiple discs, cable operated	Wet, multiple discs, cable operated	Wet, multiple discs, cable operated	Wet, multiple discs, cable operated	Wet, multiple discs, cable operated	Multi-plate, wet type, manual release	Wet, multiple discs, cable operated	Multi-plate, wet type, manual release. Magnesium-alloy.	Multi-plate, wet type, manual release. Magnesium-alloy.	Multi-plate, wet type, manual release. Magnesium-alloy.	Multi-plate, wet type, manual release. Magnesium-alloy.
Final Drive	Chain, #520	Chain	Chain	Chain, #520	Chain	Chain	Chain	Chain, RK520KZ0, 110 links	Chain (final drive)	Chain (final drive)	Chain (final drive)	Chain (final drive)
Height	1,185 mm / 46.7 in.	1,200 mm / 47.2 in. ↑	1,200 mm / 47.2 in.	1,125 mm / 44.3 in. ↓	-	1230 mm / 48.4 in	1230 mm / 48.4 in	1230 mm / 48.4 in	1200 mm / 47.2 in. ↓	1200 mm / 47.2 in.	1200 mm / 47.2 in.	1200 mm / 47.2 in.
Rims	-	-	-	Black-painted RK Excel 17´ aluminum rims and radial tires	-	Gold-anodized RK Excel aluminum rims with stainless steel spokes	Gold-anodized RK Excel aluminum rims with stainless steel spokes	Gold-anodized RK Excel aluminum rims with stainless steel spokes	Wide, blue or black anodized RK Excel aluminum rims with stainless steel spokes	Wide, blue or black anodized RK Excel aluminum rims with stainless steel spokes	-	-
Length	2,220 mm / 87.4 in.	2225 mm / 87.6 in ↑	2,225 mm / 87.6 in. ↓	2225 mm / 87.6 in ↑	2225 mm / 87.6 in	2,225 mm / 87.6 in. ↓	2225 mm / 87.6 in ↑	2225 mm / 87.6 in	2225 mm / 87.6 in.	2225 mm / 87.6 in.	2225 mm / 87.6 in.	2225 mm / 87.6 in.
Wet Weight	146 kg / 321 lbs	146 kg / 321 lbs	146 kg / 321 lbs	146 kg / 321 lbs	146.0 kg / 321.9 lbs	146 kg / 321 lbs	146 kg / 321 lbs	146 kg / 321 lbs	146.0 kg / 321.9 lbs	146.0 kg / 321.9 lbs	146.0 kg / 321.9 lbs	146.0 kg / 321.9 lbs
Warranty	-	-	-	12 month unlimited mileage limited warranty.	12 month unlimited mileage limited warranty.	12 month unlimited mileage limited warranty.	12 month unlimited mileage limited warranty.	12 month unlimited mileage limited warranty.	12 month unlimited mileage limited warranty.	12 month unlimited mileage limited warranty.	12 Month Limited Warranty	12 Month Limited Warranty
Tyres - Front	120/70-17	120/70-17	120/70-R17	120/70-17	120/70-17	120/70-17	120/70-17	120/70-17	120/70-17	120/70-R17	120/70-R17	120/70-R17
Engine Lubrication	Dry sump	Dry sump	-	Wet sump	Dry sump	Dry sump	Semi-dry sump	Semi-dry sump	Semi-dry sump	Semi-dry sump	Semi-dry-sump	Semi-dry-sump
Width	855 mm / 33.7 in.	855 mm / 33.7 in.	855 mm / 33.7 in.	855 mm / 33.7 in.	855 mm / 33.7 in.	855 mm / 33.7 in	855 mm / 33.7 in.	855 mm / 33.7 in	855 mm / 33.7 in.	855 mm / 33.7 in.	855 mm / 33.7 in.	855 mm / 33.7 in.
Tyres - Rear	140/70-17	140/70-17	140/70-R17	140/70-17	140/70-R17	140/70-17	140/70-17	140/70-17	-	-	-	-
Primary Drive	-	-	-	RK520KZO, 110 links	RK520KZO, 110 links	RK520KZO, 110 links	RK520KZO, 110 links	RK520KZO, 110 links	O-ring type drive	Chain, RK520KZ0, 110 links	Chain, RK520KZ0, 110 links	-
Instrumentation	-	-	-	Compact digital instrument cluster with speedometer, odometer, twin-trip meters with addition/subtraction capability, clock, timer and stopwatch functions.	-	-	-	-	Digital instrument cluster	Digital instrument cluster	Digital instrument cluster	Digital instrument cluster
Lighting system	-	-	-	On-road legal lighting with bright 60/55 watt H4 halogen headlight.	-	On-road legal lighting with bright 60/55 watt halogen headlight.	On-road legal lighting with bright 60/55 watt halogen headlight.	On-road legal lighting with bright 60/55 watt halogen headlight.	On-road legal lighting with bright 60/55 watt halogen headlight.	12V 60/55W (H4) ↓	12V 60/55W (H4)	12V 60/55W (H4)
Fuel Consumption	5.5 L/100 km / 18.2 km/l / 42.8 US mpg / 51.4 Imp mpg	5.5 L/100 km / 18.2 km/l / 42.8 US mpg / 51.4 Imp mpg	5.5 L/100 km / 18.2 km/l / 42.8 US mpg / 51.4 Imp mpg	5.5 L/100 km / 18.2 km/l / 42.8 US mpg / 51.4 Imp mpg	5.5 L/100 km / 18.2 km/l / 42.8 US mpg / 51.4 Imp mpg	5.5 L/100 km / 18.2 km/l / 42.8 US mpg / 51.4 Imp mpg	5.5 L/100 km / 18.2 km/l / 42.8 US mpg / 51.4 Imp mpg	5.5 L/100 km / 18.2 km/l / 42.8 US mpg / 51.4 Imp mpg	-	5.30 litres/100 km (18.9 km/l or 44.38 mpg)	5.30 litres/100 km (18.9 km/l or 44.38 mpg)	5.30 litres/100 km (18.9 km/l or 44.38 mpg)
Max Power	29.2 kW / 39.7 hp @ 8500 rpm (rear wheel: 24.9 kW / 33.4 hp	29.2 kW / 39.7 hp @ 8500 rpm (rear wheel: 24.9 kW / 33.4 hp	29.2 kW / 39.7 hp @ 8500 rpm (rear wheel: 24.9 kW / 33.4 hp	29.2 kW / 39.7 hp @ 8500 rpm (rear wheel: 24.9 kW / 33.4 hp	29.2 kW / 39.7 hp @ 8500 rpm (rear wheel: 24.9 kW / 33.4 hp	29.2 kW / 39.7 hp @ 8500 rpm	29.2 kW / 39.7 hp @ 8500 rpm	29.2 kW / 39.7 hp @ 8500 rpm	-	-	-	-
Wheel Travel - Front	-	-	-	260 mm / 10.2 in.	231 mm / 9.1 in. ↓	-	-	-	-	-	-	-
Ignition	Digital CDI	Digital/DC-CDI	Digital CDI	Digital CDI	Digital CDI	CDI	Digital CDI	Digital CDI	CDI	CDI	CDI	CDI
Lubrication	Dry sump	Dry sump	Dry sump	Dry sump	Dry sump	Dry sump	Dry sump	Semi-dry sump	-	-	-	-
