Key Specifications
Engine
Single cylinder, four-stroke
Torque
10.0 Nm (1.0 kgf-m or 7.4 ft.lbs) @ 5500 Revolutions"
Fuel Capacity
5.20 litres
Advertisement
Full 2023 Suzuki Avenis Specifications
Comments
Sold in the Asia.
Colours
Pearl Mirage White/Metallic Matt Fibroin Grey, Metallic Matt Fibroin Grey/Metallic Lush Green
Warranty
Width (mm)
710 mm
Width (in.)
28.0 inches
Wheelbase (mm)
1265 mm
Wheelbase (in.)
49.8 inches
Storage
Seat Heigth -Alternate (mm)
Seat Heigth -Alternate (in.)
Seat Height (mm)
780 mm
Seat Height (in.)
30.7 inches
Length (mm)
1895 mm
Length (in.)
74.6 inches
Height (mm)
1175 mm
Height (in.)
46.3 inches
Ground Clearance (mm)
160 mm
Ground Clearance (in.)
6.3 inches
Wet Weight (lbs.)
Wet Weight (kg)
Weight balance - Rear
Weight balance - Front
Oil Capacity (Quarts)
1.06 US quarts
Oil Capacity (l)
1.00 litres
Fuel Capacity (l)
5.20 litres
Fuel Capacity (gal.)
1.37 US gallons
Dry Weight (lbs.)
235.9 pounds
Dry Weight (kg)
107
Coolant Capacity
Bore x Stroke (in,)
2.1 x 2.3 inches
Bore x Stroke (mm)
52.5 x 57.4 mm
Stroke
CO2
36.9 CO2 g/km. (CO2 - Carbon dioxide emission)
Displacement (cc)
124.0 cc
Displacement (ci)
7.57 cubic inches
Engine Type
Single cylinder, four-stroke
Fuel Control
Single Overhead Cams (SOHC)
Fuel Reserve (gal.)
Fuel Reserve (l)
Engine Detail
Fuel System
Injection
Compression Ratio
10.3:1
Emissions
Euro 5
Engine Lubrication
Wet sump
Exhaust
Fuel Consumption
1.59 litres/100 km (62.9 km/l or 147.94 mpg)
Idle Speed
Ignition
CDI Digital
Oil Filtration
Spark Plug
Starter
Electric & kick
Valve System
2
Chain Size
Clutch
CVT
Final Drive
Belt (final drive)
Gearbox
Automatic
Number of Chain Links
Primary Drive
Sprocket
Fork Tube Size (mm)
Fork Tube Size (in.)
Trail (in.)
Trail (mm)
Wheel Travel - Front (in.)
Wheel Travel - Front (mm)
Wheel Travel - Rear (in.)
Wheel Travel - Rear (mm)
Frame Type
Steel tube underbone
Suspension - Front
Telescopic, coil spring, oil damped
Suspension - Rear
Swingarm type, coil spring, oil damped
Rake
Seat
Instrumentation
Analogue
Lighting system
LED headlight
Brakes - Rear Diameter (mm)
Brakes - Rear Diameter (in.)
Brakes - Front Diameter (mm)
Brakes - Front Diameter (in.)
Brakes - Front
Single disc
Brakes - Rear
Expanding brake (drum brake)
Brake Fluid Type
Rims
Tyre Pressure - Front
Tyre Pressure - Rear
Tyres - Front
90/90-12
Tyres - Rear
