Key Specifications
Engine
Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder
Power
128.2 hp / 94.3 kW @ 9500 rpm
Torque
103 Nm / 75.9 lb-ft @ 6750 rpm
Fuel Capacity
15.7 litres / 4.1 US gal
Full 2026 KTM 990 RC-R Specifications
Year
2026
Make Model
KTM 990 RC-R
Seat Height
845 mm / 33.3 in
Wheelbase
1481 mm / 58.3 in
Ground Clearance
163 mm / 6.4 in
Wet Weight (kg)
195
Fuel Capacity
15.7 litres / 4.1 US gal
Wet Weight
195 kg 430 lbs
Displacement
947 cc / 57.8 cu-in
Engine Detail
Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder
Bore x Stroke
92.5 x 70.4 mm
Compression Ratio
13.5:1
Cooling System
Liquid cooled with water/oil heat exchanger
Emissions
EURO 5+
Engine Management
Bosch EMS with RBW
Fuel Induction
46mm DKK Dellorto throttle body
Lubrication
Forced oil lubrication with 2 oil pumps
Starter
Electric
Clutch
PASC slipper clutch, cable operated
Final Drive
Chain 520 X-ring, 16:43
Primary Drive
42:76
Transmission / Drive
6-Speed
Frame Type
Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Suspension - Front
WP APEX 48, open cartridge, compression & rebound (30 Clicks), preload (3 clicks)
Suspension - Rear
WP APEX - Monoshock, compression high-speed (3 turns) low-speed (30 clicks), rebound (30 clicks), preload (10 turns)
Wheel Travel - Front
147 mm / 5.8 in
Wheel Travel - Rear
134 mm / 5.3 in
Brakes - Front
2 x 320mm discs, radially mounted 4 piston caliper
Brakes - Rear
Single 240 mm disc, single piston caliper
ABS
Standard
Tyres - Front
120/70-ZR 17
Tyres - Rear
180/55-ZR 17
Wheels
Cast aluminium
Wheels - Front
3.5 x 17
Wheels - Rear
5.5 x 17
