Seat Height
|
860 mm / 33.5 in | 860 mm / 33.5 in | 849 mm / 33.4 in - adjustable 869 mm / 34.2 in ↓ | 849 mm / 33.4 in |
|
Dry Weight
|
215 kg / 473.9 lbs | 215 kg / 473.9 lbs | 220 kg / 485 lbs ↑ | 220 kg / 485 lbs |
|
Frame Type
|
Tubular space frame made from chrome molybdenum steel, powder-coated | Tubular space frame made from chrome molybdenum steel, powder-coated | Chromium-Molybdenum-Steel trellis frame, powder coated, aluminium, powder coated sub-frame | Tubular space frame made from chrome molybdenum steel, powder-coated |
|
Brakes - Front
|
2 x 320 mm floating disc, Brembo four-piston brake calipers | 2 x 320 mm floating disc, Brembo four-piston brake calipers | 2 x 320 mm disc Brembo four-piston, radially mounted caliper | 2 x 320 mm floating disc, Brembo four-piston brake calipers |
|
Wheelbase
|
1560±15 mm / 61.4 in | 1560±15 mm / 61.4 in | 1557±15 mm / 61.2 in ↓ | 1580 mm / 62.2 in ↑ |
|
Engine Detail
|
Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder | Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder | Four stroke, 75° V-twin cylinder, DOHC, 4 valves per cylinder | Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder |
|
Ground Clearance
|
220 mm / 8.7 in | 220 mm / 8.7 in | 223 mm / 8.7 in ↑ | 223 mm / 8.7 in |
|
Brakes - Rear
|
Single 267 mm disc, Brembo two-piston brake caliper | Single 267 mm disc, Brembo two-piston brake caliper | Single 267 mm disc, Brembo two-piston, fixed caliper | Single 267 mm disc, Brembo two-piston brake caliper |
|
Suspension - Front
|
WP Semi-active Suspension USD ø 48 mm | WP Semi-active Suspension USD ø 48 mm | 48 mm WP APEX Semi-Active Technology USD forks - Pro package optional | 48 mm WP SAT (semi-active technology) Upside-Down forks |
|
Suspension - Rear
|
Shock absorber WP Semi-active Suspension PDS Monoshock | Shock absorber WP Semi-active Suspension PDS Monoshock | WP SAT (semi-active technology) shock absorber, electronically regulated preload | WP SAT (semi-active technology) shock absorber |
|
ABS
|
Bosch 9ME combined ABS, incl. cornering ABS and offroad mode, disengageable | Bosch 9ME combined ABS, incl. cornering ABS and offroad mode, disengageable | Bosch 10.3ME Combined-ABS - incl. Cornering-ABS and offroad mode, disenengageable ↑ | Bosch 10.3ME Combined-ABS (incl. Cornering-ABS and offroad mode) |
|
Clutch
|
PASC anti-hopping clutch/ hydraulically operated | PASC anti-hopping clutch/ hydraulically operated | PASC anti-hopping clutch, hydraulically operated | PASC anti-hopping clutch/ hydraulically operated |
|
Final Drive
|
Chain 5/8 x 5/16" X Ring | Chain 5/8 x 5/16" X Ring | Chain 525 X-Ring ↑ | Chain 525 X Ring |
|
Emissions
|
- | - | EURO5 | Euro 5 |
|
Engine Management
|
Keihin EMS with RBW and cruise control, double ignition | Keihin EMS with RBW and cruise control, double ignition | - | Keihin EMS with RBW and ACC (adaptive cruise control), double ignition, MTC (lean-angle sensitive, 4 modes, disengageable) |
|
Steering Head Angle
|
64° | 64° | 65.3° ↑ | 65.3° |
|
Max Power
|
118 kW / 160 hp @ 8750 rpm | 118 kW / 160 hp @ 8750 rpm | 118 kW / 160 hp @ 9000 rpm | 118 kW / 160 hp @ 9000 rpm |
|
Max Torque
|
140 Nm / 103.7 lb-ft @ 6750rpm | 140 Nm / 103.7 lb-ft @ 6750rpm | 138 Nm / 101.7 lb-ft @ 6500 rpm ↓ | 138 Nm / 101.7 lb-ft @ 6500 rpm |
