Kawasaki Z 1000 ABS Specs

2015 • 1 variants

The Kawasaki Z 1000 ABS is a naked bike produced from 2015 across 1 variant. It is powered by a four stroke, transverse four cylinder, dohc, 4 valve per cylinder. displacing 953.00 cc. Peak power output is 142 hp. Peak torque is 111 Nm.

About the Kawasaki Z 1000 ABS

The Kawasaki Z 1000 ABS is a Naked bike motorcycle from Kawasaki, produced from 2007 to 2016. This page provides a comprehensive technical reference for the Kawasaki Z 1000 ABS, covering all available specification data including engine configuration, displacement, power output, dimensions, weight, and chassis details. Use the year selector above to find specifications for a specific model year. All data is sourced from manufacturer specifications and is intended as a technical reference for riders, mechanics, and enthusiasts.

AdSense - 728Ã90

Kawasaki Z 1000 ABS by Year

2015 Kawasaki Z 1000 ABS View specs →

Spec Evolution

How key specs changed across production years.

Specification	2007	2013	2014	2015	2016
Ground Clearance (mm)	-	-	236 mm	125 mm ↓	125 mm
Ground Clearance (in.)	-	-	9.3 inches	4.9 inches ↓	4.9 inches
Fuel Control	DOHC	-	DOHC	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)
Brakes - Front Diameter (mm)	300 mm	-	310 mm	310 mm	310 mm
Brakes - Front Diameter (in.)	11.8 inches	-	12.2 inches	12.2 inches	12.2 inches
Bore x Stroke (mm)	77.2 x 50.9 mm	-	-	-	77.0 x 56.0 mm
Bore x Stroke (in,)	3.0 x 2.0 inches	-	-	-	3.0 x 2.2 inches
Seat Height	820 mm / 32.3 in.	815.3 mm / 32.1 in. ↓	815.3 mm / 32.1 in.	815.3 mm / 32.1 in.	815 mm / 32.1 in. ↓
Frame Type	Tubular backbone (with engine sub-frame), high-tensile steel	Aluminum Backbone	Aluminum Backbone	Aluminum Backbone	Aluminum backbone
Displacement	-	1043 cc / 63.7 cu-in	1043 cc / 63.7 cu-in	1043 cc / 63.6 cu-in	-
Wheelbase	1,455 mm / 57.3 in.	1440 mm / 56.5 in. ↑	1440 mm / 56.5 in.	1440 mm / 56.5 in.	1,435 mm / 56.5 in. ↓
Brakes - Front	Double disc. Dual semi-floating 300 mm petal discs	2x 310mm discs etal-type rotors with radial-mount 4 piston monobloc calipers and ABS ↓	2x 310mm discs etal-type rotors with radial-mount 4 piston monobloc calipers and ABS	2x 310mm discs etal-type rotors with radial-mount 4 piston monobloc calipers and ABS	Double disc. ABS. Floating discs.
Engine Detail	-	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder	-
Fuel Capacity	18.50 litres / 4.89 gallons	19.8 Litres / 5.2 US gal ↑	17 Litres / 4.5 US gal ↓	17 Litres / 4.5 US gal	17.00 litres / 4.49 gallons
Brakes - Rear	Single disc. Single 250 mm petal disc	Single 250mm disc petal-type rotor with 1 piston caliper and ABS	Single 250mm disc petal-type rotor with 1 piston caliper and ABS	Single 250mm disc petal-type rotor with 1 piston caliper and ABS	Single disc. ABS
Suspension - Front	41 mm inverted fork with stepless rebound damping and spring preload adjustability	41 mm inverted SFF-BP fork with stepless compression and rebound damping and spring preload adjustability	41 mm inverted SFF-BP fork with stepless compression and rebound damping and spring preload adjustability	41 mm inverted SFF-BP fork with stepless compression and rebound damping and spring preload adjustability	41 mm inverted fork with stepless compression and rebound damping and spring preload adjustability
Suspension - Rear	Bottom-Link Uni-Trak with gas-charged shock, stepless rebound damping and spring preload adjustability	Horizontal monoshock with stepless rebound damping, remotely adjustable spring preload	Horizontal monoshock with stepless rebound damping, remotely adjustable spring preload	Horizontal monoshock with stepless rebound damping, remotely adjustable spring preload	Horizontal monoshock with stepless rebound damping, adjustable spring preload
Fuel System	Injection. Fuel injection: 36 mm x 4 (Keihin) with oval sub-throttles	-	Injection. DFI with four 38mm Keihin throttle bodies, oval sub-throttles	Injection	Injection
Colours	-	-	Golden Blazed Green/Metallic Graphite Gray	Golden Blazed Green/Metallic Spark Black	Golden Blazed Green/Metallic Spark Black
Final Drive	Chain	X-ring chain	X-ring chain	X-ring chain	Chain
Height	1,065 mm / 41.9 in.	1054 mm / 41.5 in ↑	1054 mm / 41.5 in	1054 mm / 41.5 in	1,055 mm / 41.5 in. ↓
Length	2,090 mm / 82.3 in.	790 mm / 31.1 in ↑	2045 mm / 80.5 in ↑	2045 mm / 80.5 in	2,045 mm / 80.5 in. ↓
Wet Weight	-	220 kg - 221 kg ABS / 487.3 lbs	220 kg - 221 kg ABS / 487.3 lbs	221 kg / 487.3 lbs ↑	223.0 kg / 491.6 lbs ↑
Compression Ratio	11.2:1	11.8:1 ↑	11.8:1	11.8:1	11.8:1
Gear Ratios	-	1st 2.600 (39/15) 2nd 1.950 (39/20) 3rd 1.600 (24/15) 4th 1.389 (25/18) 5th 1.238 (26/21) 6th 1.136 (25/22)	1st 2.600 (39/15) 2nd 1.950 (39/20) 3rd 1.600 (24/15) 4th 1.389 (25/18) 5th 1.238 (26/21) 6th 1.107 (31/28)	1st 2.600 (39/15) 2nd 1.950 (39/20) 3rd 1.600 (24/15) 4th 1.389 (25/18) 5th 1.238 (26/21) 6th 1.107 (31/28)	-
Tyres - Front	120/70-17	120/70 -R17	120/70 -R17	120/70 -R17	120/70-ZR17
Width	780 mm / 30.7 in.	790 mm / 31.1 in ↑	790 mm / 31.1 in	790 mm / 31.1 in	790 mm / 31.1 in.
Tyres - Rear	190/50-17	190/50 ZR17	190/50 ZR17	190/50 ZR17	190/50-ZR17
Primary Drive	-	-	Sealed Chain	X-Ring Chain	X-Ring Chain
Rake	24.5°	24.5°	24.5°	24.5°	24.5°
Trail	103 mm / 4.1 in.	103 mm / 4.0 in	103 mm / 4.0 in	103 mm / 4.0 in	104 mm / 4.1 in. ↑
Wheel Travel - Front	41 mm / 1.6 in.	130 mm / 4.7 in ↑	120 mm / 4.7 in ↓	120 mm / 4.7 in	-
Ignition	Digital	TCBI with digital advance / electric	TCBI with digital advance / electric	TCBI with digital advance / electric	Digital
Max Torque	98.70 Nm (10.1 kgf-m or 72.8 ft.lbs) @ 82000	111 Nm / 11.3 kgf-m @ 7300 rpm ↑	111 Nm / 11.3 kgf-m @ 7300 rpm	111 Nm / 11.3 kgf.m @ 7300 rpm	111.00 Nm (11.3 kgf-m or 81.9 ft.lbs) @ 7300 Revolutions
Valve System	16	-	4	4	4
