Key Specifications
Engine
Four stroke, single cylinder, DOHC, 4 valve
Power
43 hp / 32 kW @ 9000 rpm
Torque
37 Nm / 27.3 lb-ft @ 7000 rpm
Fuel Capacity
9.5 Litres / 2.5 US gal
Advertisement
Full 2019 Husqvarna Vitpilen 401 Specifications
Year
2018 - 19
Make Model
Husqvarna Vitpilen 401
Seat Height
835 mm / 32.8 in
Wheelbase
1357 ± 15.5 mm / 53.4 in
Ground Clearance
170 mm / 6.7 in
Fuel Capacity
9.5 Litres / 2.5 US gal
Wet Weight
150kg / 330.6 lbs
Displacement
373.2 cc / 22.8 cu-in
Engine Detail
Four stroke, single cylinder, DOHC, 4 valve
Bore x Stroke
89 x 60 mm
Compression Ratio
12.6:1
Cooling System
Liquid cooled
Engine Management
Bosch EMS
Exhaust
Stainless steel/ Aluminum silencer with regulated catalytic converter
Fuel Induction
Fuel injection
Ignition
Digital CDI
Lubrication
Wet sump
Starter
Electric
Clutch
PASC antihopping clutch, mechanically operated
Final Drive
Chain, X-Ring 5/8 x 1/4″
Primary Drive Ratios
30:80
Secondary Drive Ratio
15:45
Transmission / Drive
6 Speed
Frame Type
Steel trellis frame, powder coated
Suspension - Front
43mm WP upside-down forks
Suspension - Rear
WP monoshock
Clamp Offset - Triple
32 mm / 1.8 in
Rake
25°
Steering Head Angle
65 °
Trail
95 mm / 3.7 in
Wheel Travel - Front
142 mm / 5.5 in
Wheel Travel - Rear
150 mm / 5.9 in
Brakes - Front
Single 320mm disc, 4 piston floating calliper
Brakes - Rear
Single 230mm disc 1 piston floating calliper
ABS
Bosch 9M+ two-channel ABS (disengageable)
Tyres - Front
110/70 - 17 Pirelli Scorpion Rally STR
Tyres - Rear
150/60 - 17 Pirelli Scorpion Rally STR
Wheels - Front
Wire-spoked w/ aluminum rims 3.00 x 17
Wheels - Rear
Wire-spoked w/ aluminum rims 4.00 x 17
